AXISP14andAXISQ19CameraSeries

AXISP1455-LENetworkCamera

AXISP1455-LE29mmNetworkCamera

AXISP1465-LE-3LicensePateVerierKit

AXISP1467-LEBuetCamera

AXISP1468-LEBuetCamera

AXISQ1951-EThermaCamera

AXISQ1952-EThermaCamera

AXISQ1961-TEThermaCamera

Repaintinginstructions

AXISP14andAXISQ19CameraSeries

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

AXISP14andAXISQ19CameraSeries

Repainttheproduct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartsthatwillberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

•Toavoidunwantedreections,masktheinsideoftheweathershieldbeforeyoupaint.

Pretreatmentofparts

Dependingonthepartmaterialandtypeofcoatingappliedatfactory,pretreatmentmightbenecessaryforthenewcoatingto

adherewell.Beforeyouapplyanewcoating,werecommendthefollowingpretreatment:

1.Ifnecessary,roughenupthesurfacewithalightsandpaperorsimilartoincreaseadhesion.Alternatively,removethe

originalcoatingdowntobasematerial.

2.Cleanthepartsproperlytoremoveoil,grease,anddust.

3.Ifnecessary,applyaprimerlayersuitableforthespecicmaterialtoincreaseadhesiontotheparts.Foroutdoorproducts,

werecommendaprimertoimprovecorrosionresistance.

Werecommendpretreatmentofpartsmadeofthefollowingmaterials:

•powdercoated

•wetpainted

•anodised

•chromated

•stainlesssteel

•othermetal

•plastic

AXISP14andAXISQ19CameraSeries

Repainttheproduct

Disassemby

1Backplate

2Bottombasecover

3Cameraunit

4Holer

5Weathershiel

6Li

1.Removethebottombasecover.

2.Removethelidfromthebottombasecover.

3.Removetheweathershield.

4.Removetheholderfromtheweathershield.

AXISP14andAXISQ19CameraSeries

Repainttheproduct

7Lockscrew

8Screw

9Armcover

10Pin

5.Removethelockscrew,thescrewsandthearmcover.

6.Removethepin.

AXISP14andAXISQ19CameraSeries

Repainttheproduct

Masking

1.Makesureallnecessarypreparationsofthecameraunithasbeenmade.SeePreparationsonpage3.

2.Maskallscrewandscrewholes.

3.Masktheentiretopsurfaceofthebottombasecover.

4.Masktheentirebottomsurfaceofthebottombasecover.

5.Maskthebackofthelid.

6.Masktheundersideoftheweathershield.

7.Masktheholder.

8.Masktheinsideofthearmcover.

9.Maskeverythingbetweenthefootandtheballjoint.

10.Masktheslotsfortheweathershield.

11.Maskthefrontofthecamera.

Repainting

1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

2.Letthepaintdry.

3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

4.Whenthepaintisdry,removethemasking.

AXISP14andAXISQ19CameraSeries

Repainttheproduct

Reassemby

1.Placethepinintherecessinthearm.

2.Attachthearmcover,thefourscrewsandthelockscrew.Donottightenthelockscrew.Tightenthefourscrewswith1

Nm(0.7lbft)tighteningtorue.

3.Attachtheweathershield.

4.Reassemblethecamera.Tightenthescrewswith1.2Nm(0.9lbft)tighteningtorue.

RepaintinginstructionsVer.M8.1

AXISP14andAXISQ19CameraSeriesDate:July2023

©AxisCommunicationsAB,2021-2023Partno.T10168119
