Badger Basket 12024 Kurzanleitung zur Einrichtung

1.0/0518/TG

Media Room Furniture Set

for 18 inch Dolls

Assembly and Use Instructions. Adult Assembly Required.

Read all instructions before use. This manual is part of the product

and must be saved for future reference.

VERSION CODE*:

1.0/0518/TG

* Model and Version numbers are needed

if replacement parts are requested

MODEL NUMBER*:

12024 -

Gray/White

Badger Basket, PO Box 227, Edgar, WI 54426-0227 USA • Web: www.badgerbasket.com

U.S. Based Customer Service Toll-Free (Mon-Thurs 7:00 AM-4:00 PM CST): 1-800-236-1310

Phone: 715-352-2311 • Fax: 715-352-3163

FOR REPLACEMENT PARTS:

http://www.badgerbasket.com/parts

1.0/0518/TG

CARE INSTRUCTIONS:

Frame can be wiped clean with a damp cloth and mild soap and dry thoroughly. Spot clean or

hand wash fabric as needed with cold water and mild detergent and allow to air dry. Spot clean

baskets with cold water and mild detergent and air dry. Never immerse the baskets in water.

WARNING

ADULT ASSEMBLY REQUIRED. DUE TO THE PRESENCE

OF SMALL PARTS AND SHARP POINTS DURING

ASSEMBLY, KEEP OUT OF REACH OF CHILDREN UNTIL

ASSEMBLY IS COMPLETE.

BEFORE YOU BEGIN ASSEMBLY:

Check all parts. If anything is missing or not

satisfactory, please DO NOT call the store

or return the product to them. Please go online to:

http://www.badgerbasket.com/parts

Most problems are resolved

without you needing to leave home.

When emailing or calling us, please have this

instruction manual, your product model number,

and your Version Code ready.

Your Model Number is: 12024

Your Version Code is: 1.0/0518/TG

WARNING - CAUTION

READ ALL INSTRUCTIONS before use of this

product. Use only the parts provided by Badger

Basket. Keep instructions for future use.

Do not use the product if it is damaged or broken. Periodically inspect the product to

ensure all parts remain tight. This item is a toy for dolls only. It is never to be used

for real infants or pets. No product is a substitute for adult supervision. Always

supervise your child during play. For children ages three (3) years and older.

Never sit on or stand on the toy.

A8x1

① ②

③ ④

A1x1 A2x1 A3x3 A4x1 A5x1 A6x1

SA6

Sx15

TALL SHELF

LEFT

TALL SHELF

WIDE PANEL

TALL SHELF

NARROW PANEL

TALL SHELF

RAIL

SCREW

STORAGE BASKET

AND BOTTOM

TALL SHELF

RIGHT

TALL SHELF

BACK

TOOL REQUIRED(NOT INCLUDED)

4x40mm

Sx10

① ②

③ ④

B1x1 B2x1 B3x2 B4x1 B5x1 B6x1

A8x1

TOOL REQUIRED(NOT INCLUDED)

4x40mm

SHORT SHELF

LEFT

SHORT SHELF

WIDE PANEL

SHORT SHELF

NARROW PANEL

SHORT SHELF

RAIL

SCREW

STORAGE BASKET

AND BOTTOM

SHORT SHELF

RIGHT

SHORT SHELF

BACK

Sx13

① ②

③④

C1x1 C2x1 C3x1 C4x2 C5x2 C6x1

C7x1 C8x1

TOOL REQUIRED(NOT INCLUDED)

SCREW

CABINET LEFT

CABINET RIGHT

CABINET BOTTOM

CABINET DIVIDER

CABINET DOOR

CABINET TOP

CABINET BACK

CABINET SHELF

4x40mm

Sx8

①

②

D1x2 D2x1 D3x1

4x40mm

TOOL REQUIRED

(NOT INCLUDED)

SCREWTABLE LEG TABLE TOP TABLE BOTTOM

Tx4

① ②

③ ④

E1x1 E2x1 E3x1 E4x1 E5x1 E6x1 E7x1

Sx8

E8x1

TOOL REQUIRED(NOT INCLUDED)

4x40mm

BOLT

COUCH RIGHT

COUCH LEFT

COUCH FRONT

LEG

COUCH REAR

LEG

COUCH SEAT

COUCH ARM

COUCH BACK

COUCH CUSHION

AND PILLOW SET

SCREW

4x16mm

Ux1

GRIP TAPE

Tx4

① ②

③ ④

F1x1 F2x1 F3x1 F4x1 F5x1 F6x1 F7x1

Sx8

F8x1

TOOL REQUIRED(NOT INCLUDED)

BOLT

CHAISE RIGHT

CHAISE LEFT

CHAISE FRONT

LEG

CHAISE REAR

LEG

CHAISE SEAT

CHAISE ARM

CHAISE BACK

CHAISE CUSHION

SCREW

4x40mm

4x16m m

Ux1

GRIP TAPE
