INSTRUCTIONS

For The Safe Use And Enjoyment

Of Your New Side Burner and/or

Folding Shelves

Cordon Bleu side burner

and/or folding shelves

Tools required:

2 adjustable spanners

1 phillips head screwdriver

WELCOME TO THE WORLD OF BARBEQUES

GALORE OUTDOOR COOKING

Code:MC2CDFSL or MC2CDFFL

If you also purchased a Cordon

Bleu barbeque, these instructions

are included with the barbeque

manual. Its simpler to follow the

barbeque instructions right through

instead of using this manual.

Safety First

Congratulations On Your Purchase

IF YOU HAVE PURCHASED A SIDE BURNER

ustralia has an excellent safety record when it comes to gas appliances. This re ects both

the high quality of appliances sold, as well as growing consumer awareness about safe

practice. We urge you to follow the guidelines below together with these instructions for

safe use, to prevent overheating and to produce great cooking results.

•The side burner is an outdoor appliance only . Under no circumstances should it be used indoors.

•The side burner has not been approved for marine use.

•Do not perform any servicing on the side burner yourself. This includes internal adjustment of the

regulator and gas valves. Servicing can only be carried out by authorised technicians.

•It is important that you install your side burner exactly as described in these instructions. In particular

you should keep the side burner clear of combustible material, and you should check for leaks whenever

a new connection is made.

•Do not store chemicals or

•Do not place articles on or against, or enclose this appliance.

•The side burner gets extremely hot while in use. Keep children away from the appliance until it has

cooled to normal temperatures.

•It is a good idea to tie back long hair and loose clothing while cooking in case of unexpected ups.

•NEVER leave a side burner unattended with the burner on. Always switch off all barbeque burners and

cylinders when the appliance is not in use.

•Follow all manufacturer’s instructions to periodically check for gas leaks.

Thank you and congratulations for choosing this quality side product as part of your outdoor

entertaining world.

By following these instructions for safe and easy operation, you will enjoy years of satisfying, trouble-

free outdoor cooking.

And

Please skip straight to Step 1 if you did not purchase a side burner.

when you’re fully up and running, you can visit your retailer for some great accessories and

cooking tips to make your experience even more rewarding.

r rst....

Most importantly, you must observe the clearances listed on the data sticker on your barbeque.

It will tell you how close you can put the appliance to combustible surfaces (wood, gyprock, trees, wooden

fences etc). If you don’t follow these clearances, there is a chance that nearby surfaces will heat up and catch

If you purchased your barbeque in a cart, you don’t need to be concerned with side clearances. The

barbeque-cart combination has been laboratory tested, and complies with relevant Australian Standards.

•Keep the barbeque and side burner sheltered from the wind. Wind interferes with the ames and can

prevent your barbeque or side burner from heating up properly and can even damage some components.

•Make sure the surface is level. This is safer, and makes cooking easier.

•Don’t put the babeque or side burner too close to windows or anywhere else where cooking smoke is likely

to cause problem.

Where To Put Your Barbeque

Any enclosure with walls on

all sides, but at least one

permanent opening at ground

level, and no overhead cover.

Within a partial enclosure

that includes an overhead

cover and no more than

two walls.

Within a partial enclosure that includes an overhead cover and

more than two walls, the following shall apply:

•At least 25% of the total wall area is completely open; and

•At least 30% of the remaining wall area is open and

unrestricted.

In the case of balconies, at least 20% of the total of the side,

back and front wall areas shall be and remain open and

unrestricted.

Putting Your Side Burner In An Enclosure

This appliance must only be used in an above ground, open air situation with natural ventilation, without

stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural

convection. Any enclosure in which the appliance is used must comply with one of the following:

Assembling Your Side Burner

Checking The Gas Type

IMPORTANT! Before assembling the side burner, you should ensure it is suited to

the same gas type as your barbeque.

Check the gas type sticker on both your barbecue and side burner. If your barbeque or side burner is

suited

to LPG, it should have a red printed sticker on the side saying “UNIVERSAL LPG”; you should

ensure your side burner has a similar red printed sticker.

If your main barbecue is set up for natural gas, it should have a white sticker on the side saying

“NATURAL GAS ONLY”. In this case, your side burner will also need to be converted for use with

natural gas, using the conversion kit (part no. NGCJCDB) available at your nearest Barbeques

Galore store. Gas type conversions must be done by a licensed gas tter or authorised service

agent.

It is extremely dangerous to use the barbeque with the wrong type of gas. Fire or explosion

may result.

1 x side shelf + 1 side burner

2 x side shelves

4 x 30mm long screws

(2 for each folding shelf)

7 x 15mm short screws

1 x pair of side table bracket sets

(2 for each folding shelf)

STEP 2: Check You Have All The Parts

These instructions cover the assembly of a side shelf and side burner to the Cordon Bleu

L-series range of barbeques.

It is important to note that this side burner attaches only to the right side of the barbeque.

These instructions illustrate a right handed side burner connection.

STEP 1: Prepare For Assembly

Start by unpacking the side burner, and placing it on a smooth, surface. Be careful not to

damage the stainless steel or enamel If there is any protective on the side burner,

it should be removed at the end of the assembly process . Remove and thoughtfully dispose

of all packing materials.

MC2CDFSL

2 x locking nuts and bolts

(2 for each folding shelf)

Assembling Your Side Burner

STEP 3: Attach The Folding Side

Shelf Brackets

Screw the side table bracket sets to the left side of the

barbeque using 4pcs 30mm long and the 2pcs

WHATYOU NEED

4 x 30mm long screws

Remove the 4 screws on the left side of the barbeque

as shown.

Attach the side shelf to the left side of the

barbeque as shown.

STEP 4: Attach The Side Shelf

Remove these screws

a. Hook the vertical shelf into place horizontal

Lift

position

Assembling Your Side Burner

If the folding feature is not required, the shelf can be securely locked into the horizontal position

using the locking nut and bolt as shown.

WHATYOU NEED

2 x locking nuts and bolts

(2 for each folding shelf)

If you have 2 side shelves (no side burner) repeat for the other side.

WHATYOU NEED

STEP 5: Attach The Side Burner (if purchased)

Assembling Your Side Burner

7 x 15mm short screws

Remove the 4 screws on the right side of the

barbeque as shown.

Remove these screws

Screw 6pcs

15mm short screws into the right

side of the barbeque as shown.

Do not screw in all the way – leave a 5mm gap to

allow you to hang the side burner in the next step.

Attach the side burner to the right side of the

barbeque as shown.

The keyhole shaped holes in the side burner t over

the screws which were used in the previous step.

Push the side burner over the screws and then

press the shelf downwards until the screws lock

into the narrow part of the keyhole. The shelf should

now line up neatly with the barbeque.

Tighten the six screws.

15mm short screws

Use 1pcs 15mm short screw which was

removed from the barbeque in the

previous step, and thread it through the

side shelf and back into the front corner

hole in the barbeque control panel as

shown

Follow the next steps to connect the side burner to the gas supply.

Note: This view shows

underneath the side shelf.

STEP 6 Connect the corrugated gas pipe

Side burner to barbeque

connecting corrugated pipe

Take out the tray

Disconnect the

gas tube cap

Connector the ripple

pipe to the barbecue.

Connecting The Gas

The side burner corrugated gas pipe will already

be connected to the side burner.You need to

connect the other end to the barbeque.

IMPORTANT:

Use a spanner to tighten

are caused by connections which are

only hand tightened. Before turnning

the gas on, refer to your barbeque

instructions for directions on leak test

and general gas safety.

a. Remove the grease channelling tray and use

two spanners to

disconnect the cap from the

manifold outlet (one spanner to hold manifold,

the other to loosen the cap)

b. Thread the corrugated pipe from the

side burner through the bbq as shown

c. Connect the corrugated pipe to the manifold,

using two spanners ( one spanner to hold the

manifold, the other to tighten the pipe tting)

d. Adjust the corrugated hose so that it is neat

and out of the way.

Side Burner Trivet

Open the lid of the side burner. Push the longer

prongs of the trivet into the holes in the side burner

body. The trivet should sit securely in place without

moving.

Before proceeding, it is important that you leak test all gas line s

and connections on the barbeque. Make sure all the barbeque

and side burner control knobs are OFF.

If you have a portable gas cylinder, turn the cylinder ON by rotating the

knob anti-clockwise. If you have a wall connection, ensure the bayonet

tting is connected.

Spray or pour soapy water (about the same concentration as washing

up water) along the gas line including:

•The gas connection at the inlet of the barbeque and side burner

•The gas hose or copper piping or corrugated pipe, including any

joints or bends in the piping.

•The gas connection at the gas cylinder or the wall connection.

If bubbles appear, there is a gas leak.

If the leak is at a connection, tighten and retest. If the leak is anywhere

else, or if you cannot resolve the leak, do not proceed.

•If you have a portable gas cylinder, turn the gas cylinder off and

consult your retailer.

•If you have a bayonet connection, remove the hose from the wall

ting and consult your retailer.

You can also check for leaks using a gas safety gauge, available at your

Barbeques Galore store.This provides an easier and more convenient

way to check for leaks.

Leak Testing

Connecting The Gas

The knobs have three basic positions:

OFF, HI and LO . You can achieve any

height between LO and HI by

rotating the side burner control knob

between these positions.

Controlling The Flames

Lighting Your Side Burner

burner on high burner on low

Light the side burner in the same way as for your main barbeque

Make sure that the gas is turned on at the cylinder, or that gas is available

to the barbeque. Also, ensure the side burner lid is up whenever the side

burner is in use..

Automatic Ignition: Push the knob IN and turn anticlockwise to the HI

position. Hold the knob in until the burner ignites. You may need to push

and turn the knob several times before ignition.

Manual Ignition:You can light the side burner manually by holding a lit

match next to the burner, then turning the burner control knob to HI .

Lighting The Side Burner

If the burner doesn’t light rst go, return the knob to the OFF position and try a couple more times. If the

burner still does not light, turn the burner OFF, wait a few minutes to allow the gas to disperse before trying

again. If satisfactory operation cannot be achieved, consult your retailer before proceeding.

Note carefully: Failure to follow the lighting procedures correctly can lead to a hazardous condition.

If You Hav

Turning Off

To turn the side burner OFF, it is best to turn off the cylinder rst, and allow all the

gas left in the hose to burn off. This will only take a couple of seconds. Then turn

OFF the burner controls. If your barbeque is connected to natural gas or piped LPG,

you can simply turn the burner controls OFF.

It’s okay to leave the cylinder connected to your barbeque while it’s not in use，but

keep the cylinder valve turned OFF.

Note carefully: Failure to follow these shutdown procedures correctly can lead to

a hazardous condition.

OFF

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Barbeques Galore Grill Handbücher

Barbeques Galore

Barbeques Galore BEEFMASTER V Series Bedienerhandbuch

Barbeques Galore

Barbeques Galore Grand Turbo YN662AGLP Bedienungsanleitung

Barbeques Galore

Barbeques Galore KET57 Bedienungsanleitung

Barbeques Galore

Barbeques Galore Turbo STS Bedienungsanleitung

Barbeques Galore

Barbeques Galore Ziegler & Brown TURBO BABERQUE Bedienungsanleitung

Barbeques Galore

Barbeques Galore MC2CBL Bedienerhandbuch

Barbeques Galore

Barbeques Galore Y0662LP Bedienungsanleitung

Barbeques Galore

Barbeques Galore downunder G2DLK Bedienungsanleitung

Barbeques Galore

Barbeques Galore Grand Turbo B4019LP Bedienungsanleitung

Barbeques Galore

Barbeques Galore UN2616ACT Bedienungsanleitung

Barbeques Galore

Barbeques Galore Turbo CG3TCBN Bedienungsanleitung

Barbeques Galore

Barbeques Galore DISCOVERER G4DISL Bedienungsanleitung

Barbeques Galore

Barbeques Galore Grand Turbo B3808ALP Bedienungsanleitung

Barbeques Galore

Barbeques Galore Turbo BTH2616ALP Bedienungsanleitung

Barbeques Galore

Barbeques Galore CDBL Bedienungsanleitung

Barbeques Galore

Barbeques Galore Grand Turbo B3816ALP Bedienungsanleitung

Barbeques Galore

Barbeques Galore Discoverer Island Bedienungsanleitung

Barbeques Galore

Barbeques Galore G2CBL Bedienerhandbuch

Barbeques Galore

Barbeques Galore EDV27-BQ Bedienungsanleitung

Barbeques Galore

Barbeques Galore ALFRESCO BG229SB-G Bedienerhandbuch

Barbeques Galore

Barbeques Galore Connoisseur 0 Bedienungsanleitung

Barbeques Galore

Barbeques Galore ALFRESCO Series Bedienerhandbuch

Barbeques Galore

Barbeques Galore G5CPBIQ Bedienungsanleitung

Barbeques Galore

Barbeques Galore STS2611ALP Bedienungsanleitung

Beliebte Grill Handbücher anderer Marken

Orbegozo

Orbegozo GR 2300 Bedienungsanleitung

bora

bora PT11 Bedienungsanleitung

Klarstein

Klarstein 10031664 Bedienungsanleitung

Garland

Garland MWE3W Bedienungsanleitung

Char-Broil

Char-Broil 463722714 Bedienungsanleitung

Nexgrill

Nexgrill 720-0830HK Bedienungsanleitung

Kenmore

Kenmore 415.16123800 Bedienungsanleitung

Camp Chef

Camp Chef PG24CLAU Bedienungsanleitung

Tucker Barbecues

Tucker Barbecues GTR Series Montageanleitung

Monogram

Monogram ZGG540NCP1SS Bedienungsanleitung

Equipex

Equipex Sodir Savoy Bedienungsanleitung

Gaggenau

Gaggenau VR 414 610 Bedienungsanleitung

Miele

Miele KM 408-1 Bedienungsanleitung

George Foreman

George Foreman GGR50B Bedienungsanleitung

AOG

AOG T series Bedienungsanleitung

Gorenje

Gorenje TG2000CB Bedienungsanleitung

Weber

Weber Genesis Silver-B Permamount NG 051701 Bedienungsanleitung

Glen

Glen SA 3037 Bedienungsanleitung
