Barco FLM HD20 Betriebsanleitung

FLMHD20

20,000 lumens, 1080p HD, 3chip DLP projector

Barco's FLMHD20 is an ultrabright, durable

projector with full HD pictureinpicture

capabilities. It is a perfect fit for any large

venuethatrequiresextrabrightnesstoshow

clear, crisp images in a luminous

environment.

Powerfulprojectionforlargevenues

Thanks to the FLMHD20's 20,000 lumens light output, it can display

widescreen,highcontrastimagesofsuperiorqualityeveninvenueswithlots

ofambientlight.Throughitssuperiorvideoprocessingandpictureinpicture

capabilities,youcanmakeyourpresentationsmoreinteractiveandenergizing

withouttheneedforextraperipherals.

Mostsilentprojectorinitsclass

The FLMHD20's liquid cooling technology cuts noise levels to a minimum,

making it one of the most silent projectors in its class. The FLM is also

equipped with a sealed optical engine that prevents dust, smoke or other

environmentalcontaminationfromaffectingitsimagequality.

Technicalspecifications FLMHD20

Projectortype FullHD3chipDLPdigitalprojector

Technology 0.95"DMD™x3

Resolution 1,920x1,080

Brightness 20,000centerlumens/19,000ANSIlumens

Contrastratio 2,100:1/2,700:1(highcontrastmode)

Brightnessuniformity 90%

AspectRatio 16:9

ScenergiX Horizontalandverticaledgeblending

Lenstype TLD+

Lenses 0.73:1;1.2:1;1.251.6:1;1.52.0:1;2.02.8:1;2.84.5:1;4.57.5:1;7.511.5:1

Opticallensshift Vertical:10%to+110%;Horizontal:50%to+50%(onzoomlenses)

Colorcorrection P7

Lamps 3kWxenon

Lamplifetime 1,000hours

Transportwithlamp Yes

Lamphouse,quickreplace Yes

Customerbulbreplace Yes

Lampwarranty(fieldreplace/factoryreplace) 90days,500hours/prorata750hours

SealedDLP™core Standard

Opticaldowser Standard

Pictureinpicture Twosourcessimultaneously

Orientation tableceilingside(portrait)vertical

DMX512 Optional

WARP Presetvalues+custom

Integratedwebserver N/A

CLO(constantlightoutput) Standard

3Dready(optional) PassiveInfitec

Inputs DVI(HDCP);5BNCRGBHV(RGBS/RGsB,YUVCS/SOY,Compositevideo,SVideo):

SDI/HDSDI

OptionalInputs DVI(HDCP);5BNCRGBHV(RGBS/RGsB,YUVCS/SOY,Compositevideo,SVideo);

SDI/HDSDI

InputResolutions FromNTSCuptoUXGA(1,600x1,200)incl.HD(1,920x1,080)

Max.pixelclock 165MHz

Softwaretools ProjectorToolset

Control XLRwired+IR,RS232

Networkconnection 10/100baseT,RJ45connection

Powerrequirements 220240V/5060Hz

Max.powerconsumption 3700W

Noiselevel(typicalat25°C/77°F) 58dB(A)

Operationalambienttemperature 040°C/32°104°F

Operationalhumidity 080%(noncondens)

DissipationBTU max12,625BTU/h

Dimensions(WxLxH) 707x1,025x548mm/27.83x40.35x21.57inches

Weight 99kg(218.25lbs)

ShippingDimensions (LxWxH)1,200x980x760mm/47.24x38.58x29.92inches

ShippingWeightfromFactory 151kg(333lbs)

Technicalspecifications FLMHD20

Standardaccessories Powercord,wireless/XLRwiredruggedremotecontrol

Certifications CompliantwithUL1950andEN60950complieswithFCCrules&regulations,part

15ClassAandCEEN55022ClassA,RoHS

Warranty 2years

Generatedon:19Dec2013

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
