Barco R813307K Bedienungsanleitung
BARCO PROJECTION SYSTEMS
Date:08032001
INSTALLATION MANUAL
KIT LCD + X-CUBE for R6*00 & SIM6 PROJECTORS
R813307K & R814577K
Art. No.: R5976148Rev: 01
LCD + X-CUBE
6*00 Kit
Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, March 2001.
All rights reserved.
Trademarks are the rights of their respective owners.
BARCO n.v./Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Tel : +32/56/368211
Fax : +32/56/351651
Visite Barco at the web : http://www.barco.com
Printed in Belgium
BARCO 3 Projection Systems
Safety
Who This procedure is intended for use only by qualified ser ice technicians who ha e been
trained and authorized by BARCO !
Hot Surface Switch the projector to stand by and let it cool down for at least 15 minutes before
starting with the LCD + X-Cube replacement.
Risk of Electrical
Shock
Power down the projector and unplug the power cord from the wall outlet.
Once the projector is cooled down and the power is off, continue with the replacement
procedure.
Antistatic
Protection Steps
Wear a wrist band which is connected to the ground while handling the static sensiti e
parts.
Sensitive Device LCD panels are ery sensiti e de ices. Obser e full precautions for handling electro-
static de ices. Do not touch the glass surface. Hold only by the surrounding metal
parts.
Contents
Safety ................................................................................................................................... 3
Access to the X-CUBE+LCD unit ...................................................................................... 5
Removing the X-CUBE+LCD Unit .....................................................................................
Disassembling the X-CUBE+LCD Unit ............................................................................. 8
Disassembling the X-CUBE+LCD Unit (Continued) ....................................................... 9
Assembling the X-CUBE+LCD Unit ................................................................................ 10
Assembling the X-CUBE+LCD Unit (Continued) .......................................................... 11
Mounting the X-CUBE+LCD unit..................................................................................... 12
Re-installing the covers and the lens ............................................................................ 13
BARCO 4 Projection Systems
Contents of the Kit
Type The kit contains a LCD + X-Cu e to e mounted in a R6*00 or a SIM6 series projector.
Attention ! LCD panels are very sensitive devices. O serve full precautions for handling electro-
static devices. Do not touch the glass surface and the anti-reflective coating. Hold only
y the surrounding metal parts.
Antistatic
Protection Steps
Wear a wrist and which is connected to the ground while handling the static sensitive
parts.
Part Listing The following parts are included in the kit :
Kit: R813307K R6300 & RSIM6 R9040100)
Kit: R814577K R6400 & RSIM6 R9040110)
R813307
R5976148
1X-CUBE+LCD R6300
MAN INS X-CUBE+LCD R6*00 & SIM6
Part Num er Description Indication
R814577
R5976148
1X-CUBE+LCD R6400
MAN INS X-CUBE+LCD R6*00 & SIM6
Part Num er Description Indication
Illustration of the
Kit
BARCO 5 Projection Systems
Access to the X-CUBE+LCD unit
Removing the
Lens
To remove the lens, follow the next proced re:
1
2
3
4
1
2
2
Open the lens cover by pivoting it backwards and nhook
it.
Loosen the fixation screws of the motor part and pivote it
pwards.
Open both lens locks by p lling them backwards.
Take the lens o t of the lens ho se.
Step Action Image
To be contin ed on next page.
Necessary Parts None
Necessary Tools Screwdriver 8 mm.
Illustrations on
Removing the
Lens
Image 2
Image 1
Lens lockings
Motor part
Fixation screws
For the R6*00: The lens has to be removed and the top cover has te be removed.
For the RSIM6: There is no need to remove the lens, j st the top cover has te be
removed (see next page).
What has to be
done
BARCO 6 Projection Systems
Access to the X-CUBE+LCD unit (Continued)
Removing the
Top Cover
1
2
3
1
2
P ll o t the 3 r bber cover pieces, covering the cover
screws.
T rn o t the 3 cover screws.
Take off the top cover.
Step Action Image
To remove the top cover, follow the next proced re:
Illustrations on
Top Cover
Removal
Image 1
Image 2
Image 3
BARCO 7 Projection Systems
Removing the X-CUBE+LCD Unit
What has to be
done
The X-Cube+LCD unit has to be ta en out of the projector.
Necessary Tools Screwdriver 8 mm.
Electrical
disconnection of
the X-Cube.
Before removing the X-Cube, it must be electrically disconnected from the driver board.
Follow the next procedure:
1
2
3
Press very carefully on both sides of the
cable loc to unloc .
Pull out the cable.
Disconnect the power connection on top of
the Analog Buffer.
Step Action Illustration
Press to lock
Press to unlock
Connector
connector
cable
Necessary Parts None
Illustration
Cable connectors
Removing the X-
Cube BufferUnit
To remove the LCD + X-cube unit together with the Analog Buffer unit, follow the next
procedure:
1
2
1
1
Loosen both fixation screws on the base of the X-cube
using a Philips screwdriver with a shaft of minimum 150
mm.
Ta e out the unit from the main frame very carefully.
Step Action Image
Power connector
BARCO 8 Projection Systems
Disassembling the X-CUBE+LCD Unit
What has to be
done
The X-Cube+LCD unit has to be isassemble (Separating the LCD analog buffer).
Necessary Tools Screw river 8 mm.
Nut river 5.5
Philips screw river
Electrical
disconnection of
the X-Cube.
Before isassembling the X-Cube unit, the LCD panels must be electrically iscon-
necte from the Analog buffer. Follow the next proce ure:
1
2
Press very carefully on both si es of the
cable lock to unlock.
Pull out the cable (see image 1).
Step Action Illustration
Press to lock
Press to unlock
Connector
connector
cable
Necessary Parts None
Tip While removing the screws an the parts, arrange them on a row to fin them again in
the correct assembling or er.
To be continue on next page.
Illustration Remove X-Cube Unit
BARCO 9 Projection Systems
Disassembling
the X-cube unit
To isassemble the X-cube unit, follow the next proce ure:
1
2
3
4
5
1
1
2
2
3
Turn out the 4 fixing screws with Philips screw river.
Take off the unit.
Turn out the 4 fixing screws with a nut river or flat screw-
river.
Take off the metal unit hol er.
Turn out the 4 spacers an remove the washers
Step Action Image
Disassembling the X-CUBE+LCD Unit (Continued)
Illustration
Image 1
Image 2
Image 3
BARCO 10 Projection Systems
Assembling the X-CUBE+LCD Unit
What has to be
done
The X-Cube+LCD unit h s to be re- ssembled.
Necessary Tools Screwdriver 8 mm.
Nutdriver 5.5
Philips screwdriver
Necessary Parts New X-Cube+LCD unit
Assembling the
X-cube Assembly
To ssemble the X-cube ssembly, follow the next procedure:
1
2
3
4
5
1
2
3
Turn in the 4 sp cers on the X-Cube.
Put the met l unit holder on the inserted sp cers.
Secure the position of the met l pl te with 4 screws nd
w sher, using nutdriver or fl t screwdriver.
Put the An log buffer unit on the sp cers of the support
pl te.
Secure the position with the 4 fix tion screws (Philips
screwdriver).
Step Action Im ge
To be continued on next p ge.
Illustration
Im ge 1 Im ge 2
Im ge 3
