QUICKSTART GUIDE

BATmode S / S+

Set Up and First Start Up

SAFETY INSTRUCTIONS

Please read these safety instrucons carefully before startup your

BATmode system! !

Only use power supplies authorized by bat bioacousctechnology.

Avoid excessive mechanic strain on the BATmode-System, especially on

plugs and connectors if cables are connected to the BATmode or the antenna

and microphone disc. Strong vibraons, shaking or dropping may damage system parts.

Ensure a safe and stable mounng of the BATmode and the corresponding discs.

Dropping can harm persons, property or the BATmode-system.

Ensure that nobody can stumble on installed and connected wires.

Stumbling can harm persons and damage system parts.

Only use accessories supplied or authorized by bat bioacousctechnology.

The use of unauthorized accessories may damage the device.

Please contact our support if the BATmode-System shows any damage or does not work

properly. Do not open system parts and try to repair damage by yourself or through unauthorized

personnel. This will cause the loss of warranty.

Table of Contents

SAFETY INSTRUCTIONS ................................................................

Learn about your device ...................................................................

LED Status Indicators .......................................................................

Antenna Disc and UltraSoundGate ...................................................

Microphones .....................................................................................

Connect ...........................................................................................

Remote Access via WIFI .................................................................

Remote Access via LAN ..................................................................

First Start Up ...................................................................................

Mobile Set Up ..................................................................................

Daily Status SMS..............................................................................

Remote SMS ...................................................................................

Set Up .............................................................................................

Installation .......................................................................................

myBAT ............................................................................................ 20

Learn about your device

- Front View BATmode S/S+ -

mode

BAT S+

- Back View BATmode S/S+ -

WWAN

19V

WIFI

On-/Oﬀ-Switch

Mobile Service LED

WIFI-Hotspot LED (only BATmode S+)

Power LED

Status LED

SIM-Card Slot (Mini-SIM)

USB-Port for UltraSoundGate (monitored)

USB 2.0-Port e.g. for keyboard and mouse

Temperature Sensor Input (only BATmode S+)

Precipitaon Sensor Input (only BATmode S+)

Cellular Antenna Connector

Heang Output

Power Supply

Minidisplay Port

LAN Connector

USB 3.0-Ports e.g. for Backup-Sck

Kensington-Lock

WIFI Antenna Connector (only BATmode S+)

2 3 4 5 6 7 8 9 10

12 13 14 15 16 17

How to interpret the LED status indicators of your BATmode correctly:

LED Status Indicators

Power LED (orange)

Oﬀ

Device on

Device oﬀ

WIFI Hotspot LED (green)

Oﬀ

WIFI-Hotspot on

WIFI-Hotspot oﬀ

Status LED (blue)

Oﬀ BATcontrol not started

Monitoring stopped,

BATcontrol on

Mobile Service LED (green)

Single blinking

Mobile connecon connected

Registered to mobile network

Blinking Monitoring started

Double blinking SIM locked, SIM not recognized,

no mobile service connecon

- Antenna Disc (only BATmode S+) -

- UltraSoundGate 116Hnbm -

WIFI Antenna Connector

Temperature Sensor Connector

Cellular Antenna Connector

BATmode S Systems do not use an Antenna

Disc. Instead, please connect the enclosed magnec

base antenna for mobile connecon to the cellular

antenna connector of the BATmode S.

Microphone XLR Connector

USB-2.0 Interface

Antenna Disc and UltraSoundGate

Microphones

- Front View -

Reference Signal Speaker Connector (UltraSoundGate)

Microphone XLR Connector (UltraSoundGate)

Screws for removing the mounng plate

Reference Signal Speaker

Microphone Capsule

The Microphone Disc GM50 can either be used with

the enclosed mounng plate or with an oponal

tripod.

Microphone Disc GM50

Be careful not to touch the microphone capsule and to

protect it from moisture!

- Back View -

To connect the microphone and the reference signal

of the GM50 speaker please use the Y-XLR

microphone cable.

GM50

- Front View -

Microphone XLR Connector (UltraSoundGate)

Heang Connector

Windscreen made of foam

Reference Signal Speaker

Microphone Capsule

Do not remove the windscreen foam,

as this has an essenal inﬂuence on the

calibraon of your microphone disc!

Microphone Disc GM90

Be careful not to touch the microphone capsule and to

protect it from moisture!

- Back View -

Microphones

Tower Microphone TM10

Microphone XLR Connector (UltraSoundGate)

Microphone Capsule

Oponally available movable tripod for

tower wall mounng

Be careful not to touch the microphone capsule and to

protect it from moisture!

Tower Microphone TM20

Microphone XLR Connector (UltraSoundGate)

Microphone Capsule and Reference Signal

Speaker

Oponally available movable tripod for

tower wall mounng

1 2 3

4 5 6

Connect

- BATmode S+ -

How to connect all components of your BATmode S+ System correctly:

- Antenna Disc -

- Microphone -

- UltraSoundGate 116Hnbm -

- Monitor -

- Keyboard / Mouse -

- Precipitaon Sensor -

- Backup-Sck -

Please follow the manual

of the precipitaon sensor

Depending on the selected microphone,

the heang can be omied

Oponal and not included in delivery scope

mode

BAT S+

WWAN

19V

WIFI - Power Adapter -
