Baumatic BHC605 Bedienungsanleitung

BHC605

60cm touch control

ceramic hob

User Manual for your Baumatic

BHC605

60 cm Front touch control

4 zone ceramic hob.

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

DD 31/10/08

Contents

Environmental note 4

Important safety information 5 – 8

Specifications 8 – 10

Ceramichoblayout 9

Control panel layout 10

Using the ceramic hob 10 - 14

Beforefirstuse 10

Touchcontrols 10

Switchingthehobtopon 11

Switching on a zone and setting a power level 11

Switchingoffazone 11

Switchingoffthehob 12

Residualheatindicator 12

Locking the hob top 13

The hob timer 13 – 14

Setting a countdown time 14

Safetycut-off 15

Hobguidelines 15 – 16

Cleaning and maintenance 17 - 18

Cleaning the ceramic hob top 17

Aftereachuse 17

Cleaningtable 17

Using a ceramic hob scraper 18

Using a specialist ceramic hob cleaner 18

Installation 18 - 24

Positioning 19

Unpacking the appliance 19

Installing the appliance 20 – 21

Electricalconnection 22

Connecting the mains supply cable 22 - 23

Replacing the mains supply cable 24

My appliance isn’t working correctly 24 - 25

Contactdetails 26

Environmental note

oBaumatic uses are environmentally

friendly and can be recycled.

oall packaging material with due regard for the

environment.

The packaging materials that

Please discard

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If yo

are unsure of any of the information contained in t u

his

ooklet, please contact the Baumatic Advice Line.

old use and for

oin

ient temperature of the

on at

oof this temperature limit, will be the liability of

uarantee. The foregoing does not

f Baumatic Ltd.

old not use this appliance to store items on or as a work

ept away

oService

G neral Information

This appliance is designed for domestic househothe cooking and frying of domestic foodstuffs.

IMPORTANT: The adjacent furniture and all materials used

the installation must be able to withstand a minimum

temperature of 85°C above the amb

room it is located in, whilst in use.

Certain types of vinyl or laminate kitchen furniture are

particularly prone to heat damage or discolouratio

temperatures below the guidelines given above.

Any damage caused by the appliance being installed in

contravention

the owner.

Your new appliance is guaranteed against electrical or

mechanical defects, subject to certain exclusions that are noted

in Baumatic’s Conditions Of G

affect your statutory rights.

The use of this appliance for any other purpose or in any other

environment without the express agreement o

will invalidate any warranty or liability claim.

You shou

surface.

oNo modifications to the appliance are permitted by Baumatic Ltd.

You should not store or place flammable or highly flammable

liquids/materials on top of or near the appliance. Items made

from aluminium, plastic or plastic film should also be k

from the appliance, as they may fuse to the surface.

Repairs may only be carried out by Baumatic

Engineers or their authorised service agent.

hild Safety

ny time. During and after use, all

surfaces will become hot.

ose ensure that they are kept under close supervision

at all times.

old only be allowed to utilise the appliance

when supervised.

eneral Safety

Baumatic strongly recommend that babies and young children

are prevented from being near to the appliance and not allowe

to touch the appliance at a

If it is necessary for younger family members to be in the

kitchen, plea

Older children shou

be installed and connected by a

suitably qualified person.

The appliance should only

rfaces

ild the appliance into, meet with the relevant

standards.

Care should be taken to ensure that the units and work su

that you bu

s supply. Otherwise there is the risk of electric

shock occurring.

uring use

If you notice any scratches, splits or cracks in the ceramic glass,

you should immediately switch off the appliance and disconnect

it from your main

ob surface when it

is delivered should be removed before use.

Any film or stickers that are present on the h

appliance, otherwise

there is a risk of burns being caused.

with the hob surface when it is hot or any hot

cookware.

g with fat and oil the appliance should

not be left unattended.

Care should be used when utilising the

You should not allow the electrical connection cables to com

into contact

If fat and oil overheats, then it can ignite extremely quickly. For

this reason, when cookin

sure that all of the cooking zones are switched off after

use.

Make

leaning

Cleaning of the hob should be carried out on a regular basis.

oshould be disconnected from the mains and allowed to cool.

ousing this appliance and when

following the cleaning procedure.

ohigh pressure

cleaning equipment to clean the appliance.

ection of this booklet that refers to

stallation.

oesult of improper

use or installation of this appliance.

eclaration of conformity

This appliance complies with the following European Directives:

MC Directive inclusive of

9/109/EEC dated 25/01/1992 Materials that can touch food.

oertified

must be used by a trained person for domestic purposes only.

o avoid damaging your appliance

The ceramic glass can be damaged by objects falling onto it.

oglass edge can be damaged by knocks from

cookware.

omay scratch the ceramic surface if they are dragged across it.

IMPORTANT: Before attempting to clean the appliance, it

Great care should be taken whilst

You should not use a steam jet or any other

Installation

This appliance must be correctly installed by a

suitably qualified person, strictly in accordance

with the manufacturer’s instructions. Please see

the specific s

Baumatic Ltd. declines any responsibility for injury or

damage, to person or property, as a r

-73/23/EEC dated 19/02/1973 Low Voltage Directive.

-89/336/EEC dated 03/05/1989 E

Amending Directive 92/31/EEC.

-93/68/EEC dated 22/07/1993 CE Marking Directive.

-8

The manufacturer declares that the hob is built using c

materials and requires the appliance to be installed in

accordance with the standards currently in force. This appliance

The ceramic

Cast iron and cast aluminium cookware with damaged bases

oPans should be lifted on and off the hob surface and not

dragged.

oCooking zones should not be switched on without cookware

placed on it. Also the cookware should not be empty.

Specifications

Product dimensions: Aperture dimensions:

Height: 520 mm Height: 490 mm

Width: 590 mm Width: 560 mm

Depth: 52 mm

Product specifications:

o2 x 1.80 kW hyperspeed zones (diametre 180 mm)

o2 x 1.20 kW hyperspeed zones (diametre 145 mm)

oFront touch control operation

o4 individual residual heat indicators

oSafety lock

oTimer

Standard accessories

oCeramic hob scraper

Electrical details

Rated Voltage: 230 Vac 50 Hz

Supply Connection: 30 A (double pole switched fused

outlet with 3mm contact gap)

Max Rated Inputs: 6 kW

Mains Supply Lead: 3 core x 4 mm² (not supplied)

For future reference please record the following information which can

be found on the rating plate and the date of purchase which can be

found on your sales invoice. The rating plate of your hob is located on

the underneath of the appliance. Therefore it is a good idea to record

this information before you install your appliance.

Model Number ……………………………….

Serial Number ……………………………….

Date of Purchase ……………………………….

Ceramic hob surface layout

1) 1.20 kW hyperspeed zones (diametre 145 mm)

2) 1.80 kW hyperspeed zones (diametre 180 mm)

Control panel layout

1. Safety lock button

2. Cooking zone minus button

3. Cooking zone indicator

4. Cooking zone plus button

5. Timer minus button

6. Timer display

7. Timer button

8. Timer plus button

9. ON/OFF button

Using the ceramic hob

Before first use

IMPORTANT: You should clean the ceramic hob surface (see

“Cleaning and maintenance” section).

oYou should switch on one cooking zone at a time, for 5 minutes

at the maximum setting. This will help to eliminate any new

smell that exists and evaporate any humidity that has formed on

the heating elements during transit.

oDo not burn off more than one zone at once.

oYou must place a saucepan filled half full with cold water on

each zone as you burn it off.

Touch controls

oAll operations are performed by means of the touch controls that

can be found on the control panel.

oEach touch control has a visual display that corresponds to it.
