Technical Specifications

Version 1.1 January 2004

POWERPLAY

PRO HA4600

ENGLISH

POWERPLAY PRO HA4600

HA4600

POWERPLAY PRO

Professional multi-purpose headphone amplifier system for stage and studio applications

sFour totally independent high-power stereo amplifiers in one rack space

sFour independent input/au sections provide up to four stereo mi es

sStereo au input for each channel allows you to mi in any additional instrument or sound source

sUltra-musical 2-band EQ per channel for effective sound adaptation

sHighest sonic quality even at ma imum volume

sOutput level control per channel

sMono / stereo switch per channel for more fle ibility

sLeft & right mute switches per channel allow two different mi es in mono mode

sOne front and two rear outputs 1/4" TRS per channel

sAccurate 8-digit LED output meter per channel

sFront panel direct input connector for easy connection of any source

sParalleled main outputs allow cascading of several headphone amplifiers

sServo-balanced, gold-plated XLR and 1/4" TRS inputs and outputs

sUltra low-noise 4580 operational amplifiers for outstanding audio performance

sHigh-quality detented ALPS potentiometers and illuminated switches

sHigh-quality components and e ceptionally rugged construction for long life and durability

sShielded toroidal power transformer for minimal noise interference

sDesigned in Germany. Manufactured under the ISO9000 certified management system

POWERPLAY PRO HA4600

SPECIFICATIONS

AUDIO INPUTS

MAIN-Input

Connectors XLR- and 1/4" TRS

Type HF-f ltered, servo-balanced nput

Impedance 40 kΩ balanced, 20 kΩ unbalanced

Max. nput level +21 dBu balanced and unbalanced

CMRR typ cally 40 dB, >55 dB @ 1 kHz

AUX IN- and DIRECT IN-Input

Connectors 1/4" TRS (t p = left, r ng = r ght, sleeve = ground)

Type unbalanced

Impedance >15 kΩ unbalanced

Max. nput level +21 dBu unbalanced

CMRR typ cally 40 dB, >50 dB @ 1 kHz

AUDIO OUTPUTS

Connectors XLR- and 1/4" TRS

Type balanced / unbalanced

Impedance depends on the nput mpedance

Max. output level +21 dBu balanced and unbalanced

SYSTEM SPECIFICATIONS

Frequency response 10 Hz to 100 kHz, +/-3 dB

No se >99 dBu, unwe ghted, 22 Hz to 22 kHz (>95 dB @ +4 dBu)

D stort on (THD) 0.005 % typ. @ +4 dBu, 1 kHz, Ga n 1

POWER AMPLIFIER

Max. output power +26 dBm

M n. output mpedance 100 Ω

FUNCTION CONTROLS

Input level var able

Balance per channel M x between Aux and Ma n s gnals

Output level per channel var able

FUNCTION SWITCHES

Left mute mutes the left s gnal of the respect ve channel

R ght mute mutes the r ght s gnal of the respect ve channel

Mono sw tches th s channel to mono

DISPLAYS

Input level 4-d g t LED-d splay: -24/-12/0/+12 dBu

Output level 8-d g t LED-d splay: -24/-18/-12/-6/0/+6/+12 dBu/CLIP

POWER SUPPLY

Ma ns voltage USA/Canada 120 V~, 60 Hz

U.K./Austral a 240 V~, 50 Hz

Europe 230 V~, 50 Hz

general export model 120 / 230 V~, 50 - 60 Hz

Power consumpt on 40 W

Fuses 100 - 120 V~: T 630 mA H

200 - 240 V~: T 315 mA H

Ma ns connect on standard IEC receptacle

DIMENSIONS AND WEIGHT

D mens ons approx. 1 ¾" (44.5 mm) * 19" (482.6 mm) * 8 ½" (217 mm)

We ght approx. 2,7 kg

Sh pp ng we ght approx. 3,5 kg

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time

to time to e isting products without prior notice. Specifications and appearance may differ from those listed or illustrated.

POWERPLAY PRO HA4600

Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time

of printing. The names of companies, institutions or publications pictured or mentioned and their respective logos are registered

trademarks of their respective owners. Their use neither constitutes a claim of the trademarks by BEHR NGER® nor affiliation of

the trademark owners with BEHR NGER®. BEHR NGER® accepts no liability for any loss which may be suffered by any person

who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications

depicted may vary slightly from product. No part of this book may be reproduced or transmitted in any form or by any means,

electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written

permission of BEHR NGER Spezielle Studiotechnik GmbH. BEHR NGER® is a registered trademark.

BEHR NGER Spezielle Studiotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38,

47877 Willich-Münchheide , Germany

Tel. +49 2154 9206 0, Fax +49 2154 9206 4903
