of respective manufacturers listed. 54g is a trademark of Broadcom Corporation in the U.S.

and other countries. Apple, AirPort, Mac, Mac OS, and AppleTalk are trademarks of Apple

Computer, Inc., registered in the U.S. and other countries.

P74845uk

High-Speed Mode

Wireless G USB

Network Adapter

Belkin Corporation

501 West Walnut Street,

Compton, CA 90220-5221

USA

+1 310 898 1100

+1 310 898 1111 fax

Belkin Ltd.

Express Business Park

Shipton Way, Rushden

NN10 6GL, United Kingdom

+44 (0) 1933 35 2000

+44 (0) 1933 31 2000 fax

Belkin B.V.

Boeing Avenue 333

1119 PH Schiphol-Rijk

The Netherlands

+31 (0) 20 654 7300

+31 (0) 20 654 7349 fax

Belkin GmbH

Hanebergstraße 2

80637 Munich

Germany

+49 (0) 89 143405 0

+49 (0) 89 143405 100 fax

Belkin SAS

5 Rue du Petit Robinson

3ème étage, 78350 Jouy en Josas

France

+33 (0) 1 34 58 14 00

+33 (0) 1 39 46 62 89 fax

Belkin Nordic

Knarrarnäsgatan 7

164 40 Kista

Sweden

+46 (0) 8 5229 1870

+46 (0) 8 5229 1874 fax

Belkin Tech Support

Europe: 00 800 223 55 460

F5D7051

User Manual

High-Speed Mode

Wireless G USB

Network Adapter

Connect your desktop or notebook

computer to a wireless network

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Benefits of a Home Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Advantages of setting up a Belkin Wireless Network . . . . . . . . . . 1

Placement of your Wireless Networking

Hardware for Optimal Performance . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Factors for Placement and Setup . . . . . . . . . . . . . . . . . 2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Applications and Advantages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Product Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2 Knowing your Wireless USB Network Adapter . . . . . . . . . . . . . 8

3 Installing and Setting Up the USB Network Adapter . . . . . . . . 9

Step 1: Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Step 2: Connect your USB Adapter to your PC. . . . . . . . . . . 10

Step 3: Let Windows Finish the Installation . . . . . . . . . . . . . . 11

4 Uninstalling the Software and Drivers. . . . . . . . . . . . . . . . . . . 13

5 Using the Belkin Wireless LAN Monitor Utility . . . . . . . . . . . . 14

6 Securing your Wireless Network . . . . . . . . . . . . . . . . . . . . . . . 26

7 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Table of Contents

Thank you for purchasing the High-Speed Mode Wireless G USB Network

Adapter (the Adapter). Now you can take advantage of this great new

technology and gain the freedom you need around the home or office

without using cables. The Wireless USB Network Adapter works like a

conventional network adapter, but without the wires. The easy installation

and setup will have you networking wirelessly in minutes. Please be sure

to read through this User Manual completely, and pay special attention

to the section entitled “Placement of your Wireless Networking Hardware

for Optimal Performance” on page 2. By following our simple setup

instructions your Belkin Home Network will allow you to:

• Share one high-speed Internet connection

with all the computers in your home

• Share resources, such as files, and hard drives

among all the connected computers in your home

• Share a single printer with the entire family

• Share documents, music, video, and digital pictures

• Store, retrieve, and copy files from one computer to another

• Simultaneously play games online, check Internet e-mail,and chat

Here are some of the advantages

of setting up a Belkin Wireless Network:

• Mobility – you’ll no longer need a dedicated “computer room”—

now you can work on a networked laptop or desktop computer

anywhere within your wireless range

• Easy installation – Belkin Easy Installation Wizard makes

setup simple

• Flexibility – set up and access printers, computers, and other

networking devices from anywhere in your home

• Easy Expansion – the wide range of Belkin networking products

let you expand your network to include devices such as printers

and gaming consoles

• No cabling required – you can spare the expense and hassle of

retrofitting Ethernet cabling throughout the home or office

• Widespread industry acceptance – choose from a wide range

of interoperable networking products

section

Introduction

Placement of your Wireless Networking Hardware for

Optimal Performance

Your wireless connection will be stronger the closer your computer

is to your Wireless Router (or Access Point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the

same way, your wireless connection and performance will degrade

somewhat as the distance between your Wireless Router (or Access

Point) and connected devices increases. This may or may not be

noticeable to you. As you move further from your Wireless Router

or Access Point, connection speed may decrease. Factors that can

weaken signals simply by getting in the way of your network’s radio

waves are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might be

related to range or obstruction factors, try moving the computer to a

position between five and ten feet from the Wireless Router, in order

to see if distance is the problem. If difficulties persist even at close

range, please contact Belkin Technical Support.

IMPORTANT FACTORS FOR PLACEMENT AND SETUP

Note: While some of the items listed below can affect network

performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating at

its maximum effectiveness, this checklist may help.

1. Placement of your Wireless Networking Hardware

Place your Wireless Router (or Access Point), the central connection

point of your network, as close as possible to the center of your

wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients” (i.e., computers enabled by Belkin Wireless Notebook Network

Cards, Wireless Desktop Network Cards, and Wireless USB Adapters):

• Ensure that your Wireless Router (or Access Point) networking

antennas are parallel to each other, and are positioned vertically

(toward the ceiling). If your Wireless Router (or Access Point)

itself is positioned vertically, point the antennas as much as

possible in an upward direction.

Introduction

• In multistory homes, place the Wireless Router (or Access Point)

on a floor that is as close to the center of the home as possible.

This may mean placing the Router on an upper floor.

• Try not to place the Wireless Router (or Access Point) near a

cordless 2.4GHz phone.

2. Avoid Obstacles and Interference

Avoid placing your Wireless Router or Access Point near devices that

may emit radio “noise”, such as microwave ovens. Dense objects that

can inhibit Wireless communication can include:

• Refrigerators

• Washers and/or dryers

• Metal cabinets

• Large aquariums

• Metallic-based UV tinted windows

If your wireless signal seems weak in some spots, make sure that

objects such as these are not blocking the signal’s path (between your

computers and Wireless Router or Access Point)

3. Cordless Phone Placement

If the performance of your wireless network is impaired after attending

to the above issues, and you have a cordless phone:

• Try moving cordless phones away from Wireless Routers (or

Access Points) and your wireless-enabled computers

• Unplug and remove the battery from any cordless phone that

operates on the 2.4GHz band (check manufacturers information).

If this fixes the problem, your phone may be interfering.

• If your phone supports channel selection, change the channel

on the phone to the furthest channel from your wireless network,

as possible. For example, change the phone to channel 1 and

move your Wireless Router to channel 11. See your phone’s user

manual for detailed instructions.

• If necessary, consider switching to a 900MHz or 5GHz

cordless phone.

Introduction

section

4. Choose the “quietest” channel for your wireless network

In locations where homes or offices are close together, such as

apartment buildings or office complexes, there may be wireless

networks nearby that can conflict with yours. Use the Site Survey

capabilities of your Wireless LAN Utility to locate any other wireless

networks (see page 16 of this manual), and move your Wireless Router

(or Access Point) and computers to a channel as far away from other

networks as possible.

Experiment with more than one of the available channels, in order to

find the clearest connection and avoid interference from neighboring

cordless phones or other wireless devices.

5. Secure connections, VPNs, and AOL

Secure connections are connections that typically require a user name

and password, and are used where security is important. Secure

connections include:

• Virtual Private Network (VPN) connections, often used to connect

remotely to an office network

• The “Bring Your Own Access” program from America Online

(AOL), which lets you use AOL through broadband provided by

another cable or DSL service

• Most on-line banking websites

• Many commercial websites which require a user name and

password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the VPN or

AOL software, or by re-logging into the secure web site.

A second alternative is to change your computer’s power

management settings so it does not go to sleep; however, this may

not be appropriate for portable computers. To change your power

management setting under Windows, see the “Power Options” item in

the Control Panel.

Introduction

If you continue to have difficulty with Secure Connection, VPNs and

AOL please review steps 1-4 above to be sure you have addressed

these issues.

These guidelines should allow you to cover the maximum possible

area with your Wireless Router. Should you need to cover an even

wider area, please go to the networking product section on (www.

belkin.com/networking) for more details on (Belkin’s Wireless Range

Extender/Access Point).

For more information regarding our networking products, visit our website

at www.belkin.com/networking or call our Technical Support.

Introduction

section

Features

The Adapter complies with the IEEE 802.11g standard in order

to communicate with other 802.11g and 802.11b-compliant

wireless devices.

• 2.4GHz ISM (Industrial, Science, and Medical) band operation

• Integrated, easy-to-use profile manager for storing multiple

wireless network settings for work, school, home, or any

other setup

• USB 2.0 interface, for Plug-and-Play installation and convenience

in virtually any desktop or notebook computer

• WPA security (Windows XP only), 64-bit WEP or 128-bit Encryption

• Wireless access to networked resources

• Support for both infrastructure and ad-hoc (peer-to-peer)

networking modes

• Easy installation and use

• LED link/activity indicator

• Desktop stand allows you to position your Adapter for optimal

wireless performance

Applications and Advantages

• Wireless roaming with a laptop around the home or office

Offers the freedom of networking—without cables.

• Compatible with 802.11b

802.11g wireless LAN solutions are backward-compatible with

existing Wi-Fi (802.11b) products and with other 802.11g products.

• Difficult-to-wire environments

Enables networking in buildings with solid or finished walls, or

open areas where wiring is difficult to install.

• Frequently changing environments

Adapts easily in offices or environments that frequently rearrange

or change locations.

Introduction

• Temporary LANs for special projects or peak time

Sets up temporary networks such as at trade shows, exhibitions,

and constructions sites, which need networks on a short-term

basis; also companies who need additional workstations for a

peak activity period.

• SOHO (Small Office/Home Office) networking needs

Provides the easy and quick small network installation SOHO

users need.

Product Specifications

Host Interface: USB 2.0 (This product is compatible with

the USB 1.1 and USB 2.0 specification.

To achieve maximum networking speeds

(54Mbps), this device must be connected to

a USB 2.0 host port on a PC. Connection of

this device to a USB 1.1 host port will yield

a maximum of 11Mbps networking speed.)

Power Consumption: 500mA (max)

Certification: FCC Class B, CE Mark, C-Tick

Operating Temperature: 32–131° F (0–55° C)

Storage Temperature: -13–158° F (-25–70° C)

Typical Operating Range: Up to 200’*

System Requirements

• PC with one available USB port

• Windows® 2000 or XP

*Distance and connection speeds will vary depending on your networking environment

Package Contents

• High-Speed Mode Belkin Wireless USB

Network Adapter with Desktop Stand

• Quick Installation Guide

• Installation Software CD

• User Manual

Introduction

section

Andere Handbücher für F5D7051

Inhaltsverzeichnis

Andere Belkin Adapter Handbücher

Belkin

Belkin F9L1106V2 Bedienungsanleitung

Belkin

Belkin F5D7050ceE Bedienungsanleitung

Belkin

Belkin F5U208 Bedienungsanleitung

Belkin

Belkin F1D084Eea Bedienungsanleitung

Belkin

Belkin Wireless Gplus Notebook Card Bedienungsanleitung

Belkin

Belkin F5D4073 Bedienungsanleitung

Belkin

Belkin Network Adapror Bedienungsanleitung

Belkin

Belkin F5U003 Bedienungsanleitung

Belkin

Belkin VideoBus II F5U208-MAC Bedienungsanleitung

Belkin

Belkin F8T013UK Bedienungsanleitung

Belkin

Belkin USB ADB Adapter F5U118-UNV Bedienungsanleitung

Belkin

Belkin N Wireless Bedienungsanleitung

Belkin

Belkin MP0006 Bedienungsanleitung

Belkin

Belkin F8T001 Bedienungsanleitung

Belkin

Belkin Powerline AV Networking Adapters Bedienungsanleitung

Belkin

Belkin F4U047-RS Bedienungsanleitung

Belkin

Belkin F8T031 - Bluetooth Wireless USB Printer Adapter Print... Bedienungsanleitung

Belkin

Belkin PUREIAV RemoteTV 5GHz Wireless TV Adapter Bedienungsanleitung

Belkin

Belkin F5U004 Bedienungsanleitung

Belkin

Belkin F5U103 Bedienungsanleitung

Belkin

Belkin F5D9050 Bedienungsanleitung

Belkin

Belkin F5U103 Bedienungsanleitung

Belkin

Belkin SmartBeam F5F500 Bedienungsanleitung

Belkin

Belkin PM01146EA-A F5D4047V2 Bedienungsanleitung

Beliebte Adapter Handbücher anderer Marken

PCB Piezotronics

PCB Piezotronics 090B274 Bedienungsanleitung

Auvidea

Auvidea J20 Produkthandbuch

Gossen MetraWatt

Gossen MetraWatt AT3-III E Bedienungsanleitung

Akribis

Akribis ITF-21-BISS-MIT Bedienungsanleitung

Tenda

Tenda W54U Bedienungsanleitung

ROHO

ROHO AGILITY Bedienungsanleitung

PROLiNK

PROLiNK WN2001 Bedienungsanleitung

Hawking

Hawking HUF2 Bedienungsanleitung

Airlink101

Airlink101 AWLC4030 Bedienungsanleitung

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Bedienungsanleitung

Philips

Philips SWA4554S/10 Bedienungsanleitung

JVC

JVC TS-C9D2B Gebrauchsanweisung

NETGEAR

NETGEAR A6100 Bedienungsanleitung

D-Link

D-Link DWA-121 Bedienungsanleitung

Philips

Philips SWA2037 Bedienungsanleitung

Basalte

Basalte 0610-20 Bedienungsanleitung

Yealink

Yealink EHS40 Bedienungsanleitung

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Bedienungsanleitung
