Belkin TuneCast Auto Bedienungsanleitung

User Manual

TuneCast™ Auto for iPod®

P75019ea_F8V7101ea_man.indd 1 15/8/06 10:14:37 am

User Manual

TuneCast™ Auto for iPod®

P75019ea_F8V7101ea_man.indd 2 15/8/06 10:14:37 am

User Manual

TuneCast™ Auto for iPod®

P75019ea_F8V7101ea_man.indd 3 15/8/06 10:14:38 am

P75019ea_F8V7101ea_man.indd 4 15/8/06 10:14:38 am

Congratulations and thank you for purchasing the innovative TuneCast Auto from

Belkin. This product is designed to power, charge, and transmit audio from your iPod to

your car stereo. Please review this User Manual carefully, so that you can be sure you’ll

get the most from your TuneCast Auto, virtually anywhere you go.

Introduction

Tunecast Auto is Certified

and conforms to EN 301 357

and CPT REC 70-03

P75019ea_F8V7101ea_man.indd 5 15/8/06 10:14:38 am

1. For AUDIO and POWER: Plug the dock connector into your iPod and the

cigarette-lighter adapter into your car’s cigarette-lighter outlet. Press the I or II

button to activate when the transmitter goes into sleep mode.

2. For MOUNTING: Use multi-mount socket and mount with adhesive backing to

attach your TuneCast Auto to any smooth surface.

Note: To conserve power, the TuneCast Auto will automatically turn off when there is no input audio signal for

approximately 30 seconds.

3. Tune your car stereo frequency to a channel with a

weak broadcast signal. The ideal channel is one that

is not picking up a signal from a radio station, or is

doing so weakly.

4. Press the or button on the TuneCast Auto to select

the transmission frequency chosen in step 3, on your

car for broadcast. Press and hold either button for

fast-forward or backward tuning.

Setup Instructions

P75019ea_F8V7101ea_man.indd 6 15/8/06 10:14:38 am

5. Your TuneCast Auto can memorize up to two different frequencies so you can

recall them quickly later.

a. Select the desired frequency using the or buttons.

b. Press and hold the MI or MII button for two seconds.

When the MI or MII icon blinks, release the button.

6. Adjust the volume on your iPod to a medium level.

7. Adjust the volume of your FM radio to the desired listening level.*

* Due to characteristics of FM transmission, you will experience better sound quality by adjusting the volume on your car

stereo when necessary, and by leaving your iPod volume at a medium level.

Setup Instructions

FM frequency display

Memory slot indicator

Memory I/II buttons

UP/DOWN tuning buttons

P75019ea_F8V7101ea_man.indd 7 15/8/06 10:14:39 am

This equipment has been tested and found to be compliant with the requirements

of the R&TTE Directive. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Information

P75019ea_F8V7101ea_man.indd 8 15/8/06 10:14:39 am

Warranty

Belkin Corporation Limited 3-Year Warranty

Belkin Corporation warrants this product against defects in materials and workmanship for its

warranty period. If a defect is discovered, Belkin will, at its option, repair or replace the product at no

charge provided it is returned during the warranty period, with transportation charges prepaid, to the

authorized Belkin dealer from whom you purchased the product. Proof of purchase may be required.

This warranty does not apply if the product has been damaged by accident, abuse, misuse, or

misapplication; if the product has been modified without written permission of Belkin; or if any

Belkin serial number has been removed or defaced.

THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,

WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY AND

ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE.

No Belkin dealer, agent, or employee is authorized to make any modification, extension, or addition

to this warranty.

BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING

FROM ANY BREACH OF WARRANTY, OR ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED TO,

LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING, ANY

PROGRAM OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.

Tunecast Auto is Compliant with

and conforms to EN 301 357, EN 301 489 -9

and CEPT REC 70-03 Annex 13 as a

Class 2 device

At 3 March 2006 this device may be used in : Germany, Switzerland and Iceland please see national

legislation or Recommendation 70-03 implementation table for current position http://www.ero.dk/

0673

P75019ea_F8V7101ea_man.indd 9 15/8/06 10:14:39 am

Belkin Ltd.

Express Business Park, Shipton Way

Rushden, NN10 6GL, United Kingdom

+44 (0) 1933 35 2000

+44 (0) 1933 31 2000 fax

Belkin B.V.

Boeing Avenue 333

1119 PH Schiphol-Rijk, Netherlands

+31 (0) 20 654 7300

+31 (0) 20 654 7349 fax

Belkin GmbH

Hanebergstrasse 2

80637 Munich, Germany

+49 (0) 89 143405 0

+49 (0) 89 143405 100 fax

Belkin SAS

130 rue de Silly

92100 Boulogne-Billancourt, France

+33 (0) 1 41 03 14 40

+33 (0) 1 41 31 01 72 fax

Tech Support

Europe: 00 800 223 55 460

All trade names are registered trademarks of respective manufacturers listed.

iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.

F8V7101ea P75019ea

Manuel de l’utilisateur

TuneCast™ Auto pour iPod®

P75019ea_F8V7101ea_man.indd 10 15/8/06 10:14:39 am
