Belkin F8H1500 Bedienungsanleitung
Belkin Components
G700 Portable PDA Keyboard
User Guide
For Pocket PC OS Handhelds
P74050
Index
Introduction ..............................................................................................2
Features and Specifications ....................................................................3
Operating the G700 Keyboard
Opening the Keyboard............................................................................4
Closing the Keyboard..............................................................................5
On-Keyboard Charging ..........................................................................6
Installation and Operation
Installing the G700 Keyboard Driver ......................................................7
Enabling the Driver ................................................................................9
Connecting and Removing the PDA......................................................10
Customizing Keyboard Settings ................................................................11
Application and Combination Keys ..........................................................13
Assigning Hot Keys ..................................................................................15
Frequently Asked Questions ....................................................................16
FCC/CE/Warranty Statement....................................................................17
2
Introduction
Congratulations! You have just purchased the definitive tool to extend your
handheld’s capabilities. The Belkin G700 Portable PDA Keyboard will give
you an easy and convenient way to add data to your Pocket PC handheld.
Designed for the mobile professional, the G700 weighs in at only seven
ounces and closes to a size compact enough to fit easily into a coat pocket.
For our complete selection of PDA accessories and mobile enhancements,
please visit us at belkin.com.
3
Features and Specifications
• Easy connection compatibility with your
Pocket PC OS device
• Standard QWERTY keyboard layout
• Shortcut keys for faster operation
• Ultra-portable design
• Pass-through charging capability
Opened: 9.85” x 6.97” x 2.88”
(250mm x 177mm x 73mm)
Closed: 5.83” x 3.78” x .65”)
(148mm x 96mm x 16.6mm)
Weight: 7 ounces (198.4g)
Temperature Endurance: 70º C (158º F)
Power Consumption:
In Operation: 1mA
In Sleep Mode: 1
µ
A
4
Operating the Keyboard
Opening the Keyboard
1. Open the keyboard by pressing the button.
2. Raise the lid and stand so that they are
fully extended.
3. Flip up the keyboard connector stand to its full
upright position.
4. Pull out the left and right section of the keyboard until the middle
section pops up.
5-6. Push the left, then the right section of the
keyboard together.
5
Operating the Keyboard (continued)
Closing the Keyboard
1. Gently pull the left and then the right section of the keyboard apart.
2. Push the left and right section of the keyboard forward the center of the
keyboard. The middle section will automatically move down and make
room for the left and right sections. DO NOT push down on the
middle section.
3. Flip down the keyboard connector head until it lays flat within the
keyboard.
4. Pull the lid and stand together.
5. Press the lid together with the upper frame.
6. Gently press down on the cover until it snaps in the closed position.
6
Operating the Keyboard (continued)
On-Keyboard Charging
The G700 keyboard is designed with an electronic circuit that accepts AC
power. The power receptacle is located on the side of the keyboard.
A plug adapter is included with your G700 keyboard. This adapter attaches
to your PDA’s AC power adapter, allowing you to charge your PDA directly
while using the keyboard.
Note: Your PDA must be equipped with rechargeable batteries as standard
equipment. This feature is not compatible with aftermarket recharging
products.
Installing the G700 Keyboard Driver
Before Installation
1. Disable any other keyboard applications that you have installed on your
Pocket PC handheld.
(Refer to the user guide included with your Pocket PC handheld for
instructions on this.)
2. You must have 50Kb of available memory to install
the driver.
Install the Driver
1. Connect the Pocket PC handheld to a computer using
the docking cradle or cable.
2. Establish a connection between the computer and the Pocket PC
handheld using Microsoft ActiveSync®software, then back up the data on
your Pocket PC handheld. (Refer to the user guide included with your
Pocket PC handheld for instructions on this.)
7
Installation and Operation
3. Insert the CD into an optical drive on the computer.
4. Software installation begins automatically. Follow the on-screen
instructions to install the software.
If installation does not begin automatically, select
“Start > Run” from the “Start” menu on your desktop or notebook
computer. In the dialog box, enter “X:\Setup” where X is the letter of
your optical drive. Select “OK”. Follow the on-screen instructions to
complete the installation.
5. After the software is installed, disconnect the Pocket PC handheld from
the docking cradle or cable.
6. Reset the Pocket PC handheld for two seconds. This allows the device to
recognize the keyboard software. For more information on performing a
reset, refer to
the user guide included with your Pocket PC handheld.
Enabling the Driver
1. Turn on the Pocket PC Handheld.
2. Select “Start > Programs”.
8
Installation and Operation (continued)
3. Select the “Belkin G700 Keyboard” icon.
4. Add a check mark in the check box in front of “Enable Keyboard”.
Installation and Operation (continued)
9
6700
