Belkin Keyboard Folio Bedienungsanleitung

registered trademarks of respective

manufacturers listed.

de commerce sont des marques

déposées de leurs fabricants respectifs.

nombres comerciales son marcas

comerciales registradas de los

respectivos fabricantes enumerados.

belkin.com

8820tt01040 Rev. B00 • F5L104tt / F5L115tt

Belkin Tech Support

US: http://www.belkin.com/support

Quick Install Guide

Thank you for purchasing the Belkin

Keyboard Folio, a Bluetooth®keyboard

accessory to be used with tablet devices.

Keyboard Folio

1. Folio

2. Tablet pocket

3. Detents for adjustable stand feature

4. Bluetooth®keyboard

5. Status LED

6. Charging port (micro-USB)

7. Bluetooth®pair button

Product Overview

Quick Install Guide

Package Contents

1. Keyboard Folio

2. Quick Install Guide

3. USB to Micro-USB Charging Cable

Contents may vary in different areas.

Quick Installation Guide

Keyboard Folio

Thank yo u for purchasi ng the Belkin Keyboard Folio, a Bluetooth®keybo ard accesso ry

to be used with iPad d evices.

Keyboard Folio

Setup

Insert tablet into tablet pocket ensuring correct orientation.

Fold keyboard away under tablet pocket to ensure tablet

screen is protected when folio is folded up.

Quick Install Guide

Stand Positions

The Keyboard Folio can be adjusted to several different angles using the detents in the folio.

Keyboard Folio

Charging the Keyboard

The Keyboard Folio contains an internal battery that is charged using the supplied USB to

USB-Micro cable. Connect the USB end to an appropriate USB power source (e.g., laptop,

desktop, USB wall charger, etc.). Connect the micro-USB end into the Keyboard Folio. When

the keyboard is plugged into a USB source, the Charge Status amber LED comes ON for

about 30 seconds and stays ON for as long as the battery is charging. When the battery is

fully charged, the Charge Status amber LED turns OFF.

The Keyboard Folio has been designed to be operational even when the battery is empty, as

long as it is connected via the USB to USB-Micro cable to an appropriate USB power source.

While it is charging, the Keyboard Folio will be fully operational whether the switch is set to an

on or off position.

Pairing the Keyboard

The Keyboard Folio connects to your tablet via Bluetooth technology.

Before using the Keyboard Folio, you must first pair it with your Bluetooth wireless-

technology-enabled tablet. Pairing is necessary for two Bluetooth devices to connect to each

other wirelessly. After creating a paired link, you do not need to repeat the pairing process; the

Keyboard Folio automatically links to the tablet when both devices are switched on. Pairing

must be performed every time you want to use the Keyboard Folio with a different tablet. If the

Keyboard Folio is not paired, the status LED will flash blue.

Quick Install Guide

To initiate pairing between the Keyboard Folio and tablet, ensure that they are in

close proximity:

For iPad 2:

1. Go to the Home screen on your iPad 2 and tap on “Settings > General > Bluetooth.”

2. Turn Bluetooth to “On.”

3. Turn on the Keyboard Folio and press and hold the “pair” key.

4. The Status LED will flash blue on the keyboard and the Keyboard Folio will show up under

“Devices” on the tablet. Select “Belkin Bluetooth Keyboard.”

5. A code will appear on the iPad 2 screen. Enter this code followed by the “Enter” key using

the keyboard of the Keyboard Folio.

6. When pairing is complete, the iPad 2 will notify you that the pairing was successful. The

Keyboard Folio will then be paired to your iPad 2.

7. If, after 60 seconds, pairing fails, you will have to repeat the steps above. You can view the

status from the screen of the iPad 2.

8. You can now use the Keyboard Folio to type onto your iPad 2.

Keyboard Folio

For Samsung Galaxy:

1. Go to the Home screen on your Samung Galaxy, and locate and tap on

“Settings > Wireless and Networks > Bluetooth.”

2. Turn Bluetooth to “On” by tapping on it.

3. Then choose “Bluetooth settings > Scan devices.”

4. Turn on the keyboard and press and hold the “pair” key.

5. The Status LED will flash blue on the keyboard and the keyboard will show up

under “Bluetooth Settings > Find Nearby Devices > Found Devices.” Select “Belkin

Bluetooth Keyboard.”

6. A code will appear on the Samsung Galaxy screen. Enter this code followed by the “Enter”

key using the keyboard.

7. When pairing is complete, the Samsung Galaxy will notify you that the pairing was

successful. The keyboard will then be paired to your Samsung Galaxy.

8. If after 60 seconds pairing fails, you will have to repeat the steps above. You can view the

status from the screen of the Samsung Galaxy.

9. You can now use the keyboard to type onto your Samsung Galaxy.

Quick Install Guide

Using the Keyboard

The Keyboard Folio is designed to prolong battery life and will enter into battery-saving

mode under prolonged inactivity. To wake the keyboard, press any button. The Status LED will

flash blue while the connection is being reestablished, and will be solid blue for two seconds

when the connection is successfully established. The Status LED then turns off during

ongoing operation.
