Belkin F5U302 - Wireless USB Hub Bedienungsanleitung

Make sure you have the

following package contents:

Package Contents 1 Setup for XP Users 3Setup for XP Users 2

Wireless

USB Hub

Mini-USB Cable

(A to Mini-B)

Adapter Stand

(optional)

Wireless USB

Adapter

Quick

Installation

Guide

Installation

Power

Supply

1. Insert the Belkin driver-installation CD into your CD-ROM drive.

After a few moments, the setup application should appear on

your computer screen.

Note: If the setup application does not appear, double-click “My

Computer”, and then click your CD-drive icon. This will load the

setup-applications main page.

2. Click “Install driver” and follow the prompts to complete the

software-install process.

3. a. Connect the power supply to the Hub.

b. Attach the mini-USB cable to the mini-USB port on the side of the Hub

and the other end to your computer’s built-in USB port (Fig. 1). This will

allow your computer to recognize the Hub.

4. Wait approximately one minute for security to become enabled. A

prompt will indicate that the security setup is complete (Fig. 2).

Fig. 2

5. Once this process is complete, unplug and remove the mini-USB cable from the

Hub and computer. This cable is needed only on the first installation. Store the USB

cable for another computer installation if desired.

6. Connect the Wireless USB Adapter to your computer’s USB port.

Windows will automatically find and load drivers to complete installation (Fig. 3).

Fig. 3

7. Plug your USB devices into the Hub and access them wirelessly (Fig. 4).

Setup for XP Users

(A)

Connect the

power supply

(B)

Connect

mini-USB cable

Fig. 1

Fig. 4

Up to 30 ft. in the same room

Laptop setup or desktop

Now you can print, play music, scan, download photos and burn CDs from anywhere

in the same room, up to 30 feet away, without the hassle of connecting cables. With

the Belkin Wireless USB Hub, you have the freedom to roam and stay connected.

F5U302

Belkin Tech Support

US: 800-223-5546, ext. 2263

310-898-1100, ext. 2263

UK: 0845 607 77 87

Australia: 1800 235 546

New Zealand: 0800 235 546

Singapore: 65 64857620

Europe: www.belkin.com/support

of respective manufacturers listed. Windows Vista is either a registered trademark or

trademark of Microsoft Corporation in the United States and/or other countries. P7542 8-A

Wireless USB Hub

Start Here

Quick Installation Guide

Wireless USB Hub

This guide will lead you through the basic steps

needed to install the Belkin Wireless USB Hub.

For further information or greater detail regarding

installation, please refer to the Belkin User Manual for

this product.

Setup for Windows Vista Users 5 Setup for Windows Vista Users 6

1. Insert the Belkin driver-installation CD into your CD-ROM drive. After a few

moments, the setup application should appear on your computer screen.

Note: If the setup application does not appear, double-click “My

Computer”, and then click your CD-drive icon. This will load the

setup-applications main page.

2. Click “Install driver” and follow the prompts to complete the

software-install process.

3. Double-click the “Wireless USB Control Center” icon found in the

Windows system tray, found at the bottom-right corner of the

Windows desktop.

4. a. Connect the power supply to the Hub.

b. Attach the mini-USB cable to the mini-USB port on the side of the Hub

and the other end to your computer’s built-in USB port (Fig. 1). This will

allow your computer to recognize the Hub.

5. Wait approximately one minute for security to become enabled. A

prompt will indicate that the security setup is complete (Fig. 2).

Fig. 2

6. Once this process is complete, connect the Wireless USB Adapter

to your computer’s USB port. Windows will automatically find and load

drivers to complete installation (Fig. 3).

Fig. 3

7. You can now plug your USB devices into the Hub and access them

wirelessly (Fig. 4).

Setup for Windows Vista™ Users

(A)

Connect the

power supply

(B)

Connect

mini-USB cable

Fig. 1

Fig. 4

Up to 30 ft. in the same room

Laptop setup or desktop
