Belkin Tech Support

US: 310-898-1100, ext. 2263

800-223-5546, ext. 2263

UK: 0845 607 77 87

Australia: 1800 235 546

New Zealand: 0800 235 546

Singapore: 800 616 1790

Europe: www.belkin.com/support

Belkin International, Inc.

501 West Walnut Street

Los Angeles, CA 90220, USA

310-898-1100

310-898-1111 fax

Belkin Ltd.

Express Business Park, Shipton Way

Rushden, NN10 6GL, United Kingdom

+44 (0) 1933 35 2000

+44 (0) 1933 31 2000 fax

respective manufacturers listed. Windows and Windows Vista are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other countries. P75358-B

Belkin B.V.

Boeing Avenue 333

1119 PH Schiphol-Rijk, The Netherlands

+31 (0) 20 654 7300

+31 (0) 20 654 7349 fax

Belkin Ltd.

4 Pioneer Avenue

Tuggerah Business Park

Tuggerah, NSW 2259, Australia

+61 (0) 2 4350 4600

+61 (0) 2 4350 4700 fax

In-Desk

USB Hub

In-Desk

USB Hub

User Manual

F5U402-02IN/F5U402-03IN

1. Introduction ...................................................................... 1

Features ........................................................................ 2

Package Contents ......................................................... 2

Technical Specifications ................................................ 3

2. Installation ....................................................................... 4

3. Information ...................................................................... 5

Table of Contents

Congratulations and thank you for purchasing the In-Desk

USB Hub. The Hub provides four downstream USB ports

that offer backward-compatible, Plug-and-Play connectivity

with all USB devices, including USB 1.1 (low- and full-speed)

and USB 2.0 (high-speed) devices. This includes such

peripherals as scanners, printers, mass-storage devices, and

high-resolution cameras. The Hub is self-powered, which

allows the cascading of devices with additional hubs so that

up to 127 USB devices may be connected to a single port.

The Hub fits into an included 2- or 3-inch mounting ring, for

discreet placement into your desk.

Note: If your desk does not have a pre-drilled hole in it, you

can drill one yourself using a 2- or 3-inch hole saw (requires

separate purchase, not from Belkin).

Note: When the Hub is connected to a USB 1.1 host

controller, the maximum USB 1.1 bandwidth of 12Mbps

must be shared by all four ports.

Introduction

Features

• USB specification 2.0 (data rate 1.5/12/480Mbps)

• Backward-compatible with USB Specification 1.1 (data rate

1.5/12Mbps)

• Compatibility with Windows® 98SE, Me, 2000, XP,

and VistaTM

• Approved by USB Implementers Forum (USB-IF)

• Plug-and-Play connectivity

• Hot-swapping capability

• Over-current detection and protection

• Multiple mounting-ring sizes for different desks (3" and 2")

Package Includes

• In-Desk USB Hub

• Mounting Ring

• Power Adapter

• USB 2.0 Cable

• User Manual

Note: Mount Ring (Grommet) Caps, Belkin part numbers

F5U402-02IN-GRC and F5U402-03IN-GRC, may be used for cable

management and to cover mounting-ring opening when Hub is not

present (not included).

Technical Specifications

Upstream Ports: 1

Downstream Ports: 4

Per-Port Voltage: DC +5V

Per-Port Current: 500mA (max) (self-powered mode)

Power Mode: Self-powered/bus-powered

Operating Temperature: 5° C ~ 40° C

Storage Temperature: -20° C ~ 60° C

Enclosure: ABS

Power Supply: Output: DC 5V, 2.5A

Plug Size: 3.5mm (outer)

1.0mm (center)

Plug Polarity: Center positive

Main-Power LED

Color Definitions Off: Not operational

Green: Operational

Port-Status LED

Color Definitions Off: Not operational

Green: Operational

Introduction

IMPORTANT NOTE: Please do not connect any USB devices to

the Hub until instructed to do so in step 5 of this installation

procedure.

1. Insert the mounting ring into the desk.

2. Plug the included power adapter into a wall outlet or surge

suppressor, running its cable through the mounting ring. Do not

plug it into the Hub yet.

3. Plug the flat end of the USB device cable into the downstream

port of your computer or another hub; and run the USB cable

through the mounting ring.

4. Now, plug in the power cable’s connector to the power jack on the

rear of the Hub.

Note: You can use the Hub without the power supply when

connecting low-power devices such as keyboards and mice.

5. Plug the square end of the USB device cable into the upstream

port on the rear of the Hub.

6. Place the Hub into the mounting ring.

Important Note: The Hub must be connected to a USB 2.0-

compliant host in order to function in high-speed mode (480Mbps

data rate). If the Hub is connected to a USB 1.1-compliant host, it will

operate only in low- or full-speed mode (1.5Mbps/12Mbps).

7. Windows will now detect your Hub and install the required driver.

(The Windows “Install New Hardware Wizard” may prompt you to

provide your Windows Installation CD to complete the

driver-installation process.)

Important Note: Hi-Speed USB 2.0 hub drivers are included with

most USB 2.0 PCI upgrade cards and are pre-installed along with

the PCI-card drivers. If you purchased an upgrade card prior to the

advent of Hi-Speed USB 2.0 hub support, please check with your

PCI-card vendor for an updated USB 2.0 driver.

8. Plug the USB-A connector of the USB device or additional hub

into any of the In-Desk USB Hub’s downstream ports.

Important Note: When moving a device from one port to another, it

may be necessary to reinstall the USB drivers for that device.

Installation

Information

CE Declaration of Conformity

We, Belkin International, Inc., declare under our sole responsibility

that the F5U402-02IN/F5U402-03IN, to which this declaration relates,

are in conformity with Generic Emissions Standard EN55022:1998

Class B, EN50081-1, and with Generic Immunity Standard

EN50082-1:1992.

Belkin International, Inc., Limited Lifetime Product Warranty

What this warranty covers.

Belkin International, Inc., warrants to the original purchaser of this

Belkin product that the product shall be free of defects in design,

assembly, material, or workmanship.

What the period of coverage is.

Belkin International, Inc., warrants the Belkin product for the lifetime

of the product.

What will we do to correct problems?

Product Warranty.

Belkin will repair or replace, at its option, any defective product free

of charge (except for shipping charges for the product).

FCC Statement

DECLARATION OF CONFORMITY WITH FCC RULES FOR

ELECTROMAGNETIC COMPATIBILITY

We, Belkin International, Inc., of 501 West Walnut Street, Compton, CA

90220, declare under our sole responsibility that the products:

F5U402-02IN/F5U402-03IN

to which this declaration relates:

Comply with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference

that may cause undesired operation. This equipment may only be operated

indoors. Operation outdoors is in violation of 47 U.S.C. 301 and could subject

the operator to serious legal penalties.

Information

What is not covered by this warranty?

All above warranties are null and void if the Belkin product is not

provided to Belkin International, Inc., for inspection upon Belkin’s

request at the sole expense of the purchaser, or if Belkin International,

Inc., determines that the Belkin product has been improperly installed,

altered in any way, or tampered with. The Belkin Product Warranty

does not protect against acts of God (other than lightning) such as

flood, earthquake, war, vandalism, theft, normal-use wear and tear,

erosion, depletion, obsolescence, abuse, damage due to low voltage

disturbances (i.e. brownouts or sags), non-authorized program, or

system equipment modification or alteration.

How to get service.

To get service for your Belkin product you must take the

following steps:

1. Contact Belkin International, Inc., at 501 W. Walnut St.,

Compton CA 90220, Attn: Customer Service, or call

(800)-223-5546, within 15 days of the Occurrence.

Be prepared to provide the following information:

a. The part number of the Belkin product.

b. Where you purchased the product.

c. When you purchased the product.

d. Copy of original receipt.

2. Your Belkin Customer Service Representative will then instruct

you on how to forward your receipt and Belkin product and how

to proceed with your claim.

Belkin International, Inc., reserves the right to review the damaged

Belkin product. All costs of shipping the Belkin product to Belkin

International, Inc., for inspection shall be borne solely by the

purchaser. If Belkin determines, in its sole discretion, that it is

impractical to ship the damaged equipment to Belkin International,

Inc., Belkin may designate, in its sole discretion, an equipment repair

facility to inspect and estimate the cost to repair such equipment.

The cost, if any, of shipping the equipment to and from such repair

facility and of such estimate shall be borne solely by the purchaser.

Damaged equipment must remain available for inspection until the

claim is finalized. Whenever claims are settled, Belkin International,

Inc., reserves the right to be subrogated under any existing insurance

policies the purchaser may have.

How state law relates to the warranty.

THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN

INTERNATIONAL, INC., THERE ARE NO OTHER WARRANTIES,

EXPRESSED OR, EXCEPT AS REQUIRED BY LAW, IMPLIED,

INCLUDING THE IMPLIED WARRANTY OR CONDITION OF

QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE

LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.

Some states do not allow limitations on how long an implied

warranty lasts, so the above limitations may not apply to you.

IN NO EVENT SHALL BELKIN INTERNATIONAL, INC., BE LIABLE

FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL

OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED TO, LOST

BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF

ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY

OF SUCH DAMAGES.

This warranty gives you specific legal rights, and you may also have

other rights, which may vary from state to state. Some states do not

allow the exclusion or limitation of incidental, consequential, or other

damages, so the above limitations may not apply to you.

Information

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Belkin Schalten Handbücher

Belkin

Belkin KVM for Mac mini Bedienungsanleitung

Belkin

Belkin FSU234ea Bedienungsanleitung

Belkin

Belkin F1DN204MOD-PP-4 Bedienungsanleitung

Belkin

Belkin OMNIVIEW PRO3 F1DA208ZEA Bedienungsanleitung

Belkin

Belkin F1DN108C Bedienungsanleitung

Belkin

Belkin 2-Port KVM Switch Bedienungsanleitung

Belkin

Belkin OmniView F1DG102P Bedienungsanleitung

Belkin

Belkin F5L009EA Gebrauchsanweisung

Belkin

Belkin F5U302 - Wireless USB Hub Bedienungsanleitung

Belkin

Belkin USB Desk Hub Bedienungsanleitung

Belkin

Belkin F1U400 - 4x4 USB Peripheral Switch Sharing Bedienungsanleitung

Belkin

Belkin F5U302 - Wireless USB Hub Bedienungsanleitung

Belkin

Belkin F5U403 Bedienungsanleitung

Belkin

Belkin P74081-A, F5U217 Bedienungsanleitung

Belkin

Belkin OMNIVIEW F1DN102D Bedienungsanleitung

Belkin

Belkin Secure KVM - NIAP PP4.0 Service-Handbuch

Belkin

Belkin F5U271 Bedienungsanleitung

Belkin

Belkin F5U234 Bedienungsanleitung

Belkin

Belkin F1DN104P-3 Bedienungsanleitung

Belkin

Belkin OmniView F1DB102P2ea Bedienungsanleitung

Belkin

Belkin OmniView F1DJ102P-B Bedienungsanleitung

Belkin

Belkin F1DG102D Bedienungsanleitung

Belkin

Belkin OmniView F1D074 Bedienungsanleitung

Belkin

Belkin OmniView Pro Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
