N13102 Operations User Manual

Table of contents

CHAPTER 1. SAFETY INSTRUCTIONS............................................................................................................ 3

CHAPTER 2. OVERVIEW................................................................................................................................... 5

2.1. OVERVIEW OF BEWARD N13102............................................................................................................. 5

2.1.1. N13102 Features ............................................................................................................................................. 6

2.1.2. The N13102 Specifications .............................................................................................................................. 6

2.1.3. Package Contents ............................................................................................................................................ 7

2.1.4. Default Settings ............................................................................................................................................... 7

2.2. PURPOSE OF USER MANUAL ..................................................................................................................... 8

2.3. MINIMUM SYSTEM REQUIREMENTS ............................................................................................................ 8

CHAPTER 3. USING THIRD PARTY CLIENTS ................................................................................................. 9

3.1. PLAYING 3GPVIDEO................................................................................................................................. 9

3.2. PLAYING STREAMING VIDEO IN 2.5G NETWORKS OVER WAP...................................................................... 9

3.3. PLAYING STREAMING VIDEO IN 2.5G NETWORKS VIA BROWSER.................................................................. 9

3.4. PLAYING STREAMING VIDEO VIATHIRD PARTY SOFTWARE........................................................................... 9

3.4.1. Playing H.264 Video ...................................................................................................................................... 10

3.4.2. Playing MPEG-4 Video ................................................................................................................................... 10

3.4.3. Playing MJPEG Video..................................................................................................................................... 10

3.4.4. Getting a JPEG Image .................................................................................................................................... 10

CHAPTER 4. MANAGING THE IP CAMERA VIA INTERNET EXPLORER.....................................................11

4.1. INSTALLING ACTIVEXCONTROLS.............................................................................................................. 12

CHAPTER 5. MAIN MENU................................................................................................................................ 16

5.1. LIVE VIEW .............................................................................................................................................. 16

5.1.1. [Snapshot] Button.......................................................................................................................................... 16

5.1.2. [Fullscreen] Button ........................................................................................................................................ 17

5.1.3. [Open Digital Zoom] Button .......................................................................................................................... 17

5.1.4. Video Control Buttons.................................................................................................................................... 18

5.1.5. Audio Control Buttons ................................................................................................................................... 18

5.2. SETTING MENU....................................................................................................................................... 19

5.3. CLIENT SETTING ..................................................................................................................................... 21

5.3.1. Mode ............................................................................................................................................................. 22

5.3.2. View Size........................................................................................................................................................ 22

5.3.3. Video Buffer................................................................................................................................................... 22

5.4. IMAGE SETUP ......................................................................................................................................... 22

5.4.1. Brightness...................................................................................................................................................... 23

5.4.2. Contrast ......................................................................................................................................................... 23

5.4.3. Saturation...................................................................................................................................................... 23

5.4.4. Sharpness ...................................................................................................................................................... 23

5.4.5. Exposure ........................................................................................................................................................ 23

5.4.6. Default........................................................................................................................................................... 23

CHAPTER 6. SETTING: SYSTEM.................................................................................................................... 24

6.1 INFORMATION........................................................................................................................................... 24

6.2. DATE/TIME ............................................................................................................................................. 24

6.3.ACCOUNT ............................................................................................................................................... 26

6.4. SYSTEM LOG.......................................................................................................................................... 28

6.5. INITIALIZE ............................................................................................................................................... 29

CHAPTER 7. SETTING: CAMERA................................................................................................................... 31

7.1. GENERAL ............................................................................................................................................... 31

7.2. PROFILE 1.............................................................................................................................................. 33

7.3. PROFILE 2.............................................................................................................................................. 35

7.4.ADVANCED.............................................................................................................................................. 36

7.5. PLAYBACK .............................................................................................................................................. 38

CHAPTER 8. SETTING: NETWORK................................................................................................................ 41

8.1. INFORMATION.......................................................................................................................................... 41

8.2. PPPOE(POINT-TO-POINT PROTOCOL OVER ETHERNET)........................................................................... 42

8.3. DDNS (DYNAMIC DNS).......................................................................................................................... 44

8.4. UPNP(UNIVERSAL PLUGAND PLAY)........................................................................................................ 45

Table of contents

N13102 Operations User Manual

8.5. IPNOTIFICATION ..................................................................................................................................... 46

CHAPTER 9. SETTING: EVENTS.................................................................................................................... 48

9.1. FTP CLIENT ........................................................................................................................................... 48

9.1.1. General .......................................................................................................................................................... 48

9.1.2. Alarm Sending ............................................................................................................................................... 50

9.1.3. Periodical Sending ......................................................................................................................................... 52

9.2. SMTP.................................................................................................................................................... 54

9.2.1. General .......................................................................................................................................................... 55

9.2.2. Alarm Sending ............................................................................................................................................... 56

9.2.3. Periodical Sending ......................................................................................................................................... 59

9.3. NETWORK STORAGE................................................................................................................................ 60

9.3.1. General .......................................................................................................................................................... 61

9.3.2. Alarm Sending ............................................................................................................................................... 63

9.3.3. Periodical recording....................................................................................................................................... 66

9.4. MEMORY CARD....................................................................................................................................... 68

9.4.1. General .......................................................................................................................................................... 68

9.4.2. Alarm Sending ............................................................................................................................................... 72

9.4.3. Periodical Sending ......................................................................................................................................... 74

9.4.4. Backup ........................................................................................................................................................... 76

9.5. MOTION DETECTION................................................................................................................................ 77

9.6.AUDIO DETECTION .................................................................................................................................. 79

9.7. SCHEDULE.............................................................................................................................................. 80

APPENDIX ........................................................................................................................................................ 82

APPENDIXA. BITRATE VALUES........................................................................................................................ 82

APPENDIX B. REQUIRED DISK SPACE.............................................................................................................. 86

APPENDIX C. REQUESTS FOR IMAGES FROM IPCAMERA. ................................................................................ 89

APPENDIX D. PORT VALUES ........................................................................................................................... 91

APPENDIX E. FACTORY DEFAULTS................................................................................................................... 92

APPENDIX F. GLOSSARY................................................................................................................................. 93

Chapter 1. Safety Instructions

N13102 Operations User Manual

Chapter 1. Safety Instructions

Before using this product

This camera complies with all safety rules. However, improper use of any electric device

can be a cause of fire and bring to property damage. Before you start using this camera, please

study this user manual carefully.

IMPORTANT!

Use accessories recommended by the manufacturer only. Use of the improper accessories may cause

camera’s breakdown.

Follow the operating instructions

Do not use and store this camera in severe environment:

avoid extremely low or high ambient temperatures (the camera’s operating temperature

is 0°C to +40°C)

avoid exposure to direct sunlight and do not locate the camera near any heat sources

avoid exposure to high humidity

do not locate the camera near any electrical appliances which can be electromagnetic

transmitters

avoid exposure to high vibration

IMPORTANT!

In case of malfunction of the product, please contact your local dealer for technical assistance.

In case of:

detection of a strange smell or smoke

penetration of any liquid or foreign objects into the camera

the camera has been dropped or damaged

Do the following:

unplug the power cord and disconnect all other cords from the camera

contact our Service Center. You can find contact information on our website:

http://www.beward.eu/.

Transportation

Ttransport the camera carefully, using the original box and protective packing.

Chapter 1. Safety Instructions

N13102 Operations User Manual

Ventilation

To prevent overheating of the device, keep free air circulation in the area where the camera

is located.

Cleaning

Use a soft, dry cloth for cleaning camera’s external surfaces. It is acceptable to use some

detergent for removing persistent dirt, but not the volatile cleaners such as the alcohol-containing

solvents, benzene and so on, because of the risk to damage the camera’s housing.

Chapter 2. Overview

N13102 Operations User Manual

Chapter 2. Overview

2.1. Overview of BEWARD N13102

BEWARD N13102 is a high-quality compact megapixel IP camera (Pic. 2.1) with built-in

microphone, megapixel CMOS sensor, 10x digital zoom and recording to memory card.

Pic. 2.1

BEWARD N13102 allows watching the real time image via a web browser from anywhere in

the world. You can always hear and see what is happening in your home, office, or cottage and

even talk to your employees or relatives. Unlike the ordinary web cameras, the N13102 does not

require a computer that is always turned on; you need to simply connect it to a network. Besides,

the camera can be connected to a network via 10/100BASE-TX Ethernet

Compact enough to fit in the palm of your hand, the N13102 delivers crisp and clear images

using the built-in high sensitivity CMOS sensor and advanced signal processing techniques.

The camera delivers video at 15 frames per second at 1280х1024 resolution and up to 30

frames per second at 640х480, previously only seen in professional CCD cameras.

The N13102 features a built-in microphone and supports external speakers, allowing two-

way audio communication and offering both video surveillance and listening in on an area as well

as communication with individuals.

The camera supports SD memory cards so that the camera can record files to the memory

card when there is no wired connection with the camera. Also, when the memory card space is full,

the camera overwrites the old files by the new ones.

BEWARD N13102 offers a cost-effective solution for professional indoor security

surveillance and remote monitoring over a local network or the Internet. The camera is suitable for

building a surveillance system in houses as well as small and medium-sized enterprises.

Chapter 2. Overview

N13102 Operations User Manual

The N13102 supports dual streaming, an MPEG4 streaming and a user defined streaming

(H.264, Motion JPEG or 3GPP compression is available). Such streaming options allow combining

high-quality image and optimum bandwidth usage. H.264 provides high frame rate even in limited-

bandwidth networks; MJPEG allows obtaining high-quality images; MPEG4 is a standard on video

and audio coding supported by many applications; 3GPP allows viewing camera’s stream on a cell

phone or any other mobile device that supports 3GPP format, e.g. smart phones, PDA (iPhone

supported as well).

The built-in motion detection can trigger an alarm and start recording when the camera

detects motion. Besides, it can notify you when an alarm is triggered.

The N13102 supports IP Multicast, RTSP, RTP, and many other network protocols. The

support for 802.1p and Dynamic DNS protocols allows the camera to be easily used with various

Internet service providers. The camera supports HTTPS and SSL protocols, which allow secure

video transmission. These protocols are even used to manage bank accounts.

The N13102 comes with everything you need to quickly set up your camera and start using

it. User manuals and surveillance software in English are included. The N13102 is easy to use and

set up.

2.1.1. N13102 Features

Optimal solution concerning price and quality

High-quality image

SD memory cards support

Professional surveillance software included (16 channels)

1/4'' progressive scan CMOS image sensor

Multi-format H.264/MPEG-4/M-JPEG streaming

Playing recorded files with the player integrated in the web interface

Built-in microphone

3.5 mm audio jack out for external speakers

Two-way audio

Built-in multi-zone motion detection and audio detection

Sending of image or video via e-mail and to FTP

Recording to network attached storage (including to a shared folder on a computer

running Windows or Linux installed)

10x digital zoom

2.1.2. The N13102 Specifications

Image sensor: 1/4" progressive scan CMOS

Chapter 2. Overview

N13102 Operations User Manual

Lens: M12 interchangeable, f4.5 mm, F1.9 (angle of view: 47°(pan))

Resolution: 1280х1024, 1280х720, 640х480, 320х240, 160х120

Sensitivity: 0.5 lux @ F1.9

Shutter: electronic, 1/4 to 1/17780 seconds

Frame rate: up to 30 frames per second at 640х480 and lower; up to 15 frames per

second at 1280х1024, 1280х720

Video encoding: H.264, MPEG-4 or MJPEG

Built-in microphone

Supported protocols: Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DDNS,

NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA RTSP

Power: 12 V, 1 A DC

Operating temperature: 0 to +50°С

Operating humidity: 20-80% (non-condensing)

ONVIF v1.02 support

2.1.3. Package Contents

IP camera N13102 (M12, f4.5 mm, F1.9 pre-installed lens)

Power supply 12 V, 1 A DC

Bracket and mounting kit

Patch cord (1 m length)

CD with user manuals and software

Quick installation guide

Package

2.1.4. Default Settings

IP address: 192.168.0.99

Subnet mask: 255.255.255.0

Gateway: 192.168.0.1

Username: admin

Password: admin

HTTP port: 80

RTSP port: 554

Chapter 2. Overview

N13102 Operations User Manual

2.2. Purpose of User Manual

BEWARD N13102 features a web server, network interface and can be connected to the

Ethernet directly.

The camera image can be viewed via a web browser or free Beward software, which comes

with this camera. Besides, the live image can be viewed over mobile networks, via stream players,

over the Internet remotely, etc.

This User manual provides information on camera’s web interface, setting it up to connect

to a network so that the camera can be managed by using a built-in web server as well as by

software.

Despite some BEWARD IPS options are not available (see BEWARD IPS Operations User

Manual) when you are managing the camera by a web browser or mobile device, it allows viewing

camera image from any location in the world, though. Moreover, you can view it on any device

such as a laptop, cell phone, PDA, etc. This User manual provides detailed information of

managing the N13102 without using extra software.

2.3. Minimum System Requirements

Verify that your computer meets the system requirements listed on the camera packaging.

If your computer does not meet these requirements IP camera may not work correctly.

Item

Requirements

CPU

2.8 GHz Pentium 4 (or equivalent AMD)

Video Card

256 MB (or equivalent integrated video card)

RAM

1 GB

Operating System

Windows 2000, XP, Vista, Windows 7, Mac OS X Leopard (32 bit)

Web Browser

Internet Explorer 8.0 or later

NOTE:

1. If you cannot play records, please install Xvid codec or VLC freeware player

(http://www.videolan.org/vlc/).

2. For correct program operation, you may need to update some Windows components (.Net Framework,

Windows Media Player, Enhance ActiveX Security).

Chapter 3. Using Third Party Clients

N13102 Operations User Manual

Chapter 3. Using Third Party Clients

The N13102 supports RTSP/RTP streaming.

RTSP (Real Time Transfer Protocol) is a network control protocol designed for use in

entertainment and communications systems to control streaming media servers. The protocol is

used for establishing and controlling media sessions between end points. Clients of media servers

issue VCR-like commands, such as play and pause, to facilitate real-time control of playback of

media files from the server.

NOTE:

You can play RTSP stream with any supported video player (Real Player, VLC, Quick Time, etc).

3.1. Playing 3GP Video

You can view camera image on a computer as well as a mobile device such as cell phones,

smart phones, PDA, etc (iPhone supported as well). You can configure the stream to be viewed on

a mobile device at SETTING ― Camera ― Profile 2 and select 3GPP format in the [Streaming]

drop-down menu.

If your phone does not support streaming video, type «rtsp://<IP>:<PORT>/video.3gp»in

a streaming player installed in your phone to view the 3GP video. <IP> means public IP address of

your camera, <PORT> means RTSP port (default value is 554). Example:

rtsp://100.10.10.1:554/video.3gp.

3.2. Playing Streaming Video in 2.5G Networks over WAP

If your phone is used on a 2.5G network, type «http://<IP>/mobile.wml»in the WAP

browser’s address bar to the view video over WAP. <IP> means public IP address of your camera.

3.3. Playing Streaming Video in 2.5G Networks via Browser

If your phone is used on a 2.5G network, type «http://<IP>/mobile.htm»in the browser’s

address bar to view the video. <IP> means public IP address of your camera.

3.4. Playing Streaming Video via Third Party Software

If your computer (or cell phone, smart phone, etc) is connected to high-speed Internet or

you need to view streaming video in other formats, you can use real time RTSP players such as

VLC, Quick Time, Real Player, etc.

NOTE:

Connection speed to the camera depends on the bandwidth.

Inhaltsverzeichnis

Andere Beward IP-Kamera Handbücher

Beward

Beward N13103 Bedienungsanleitung

Beward

Beward N35110 Bedienungsanleitung

Beward

Beward N6603 Bedienungsanleitung

Beward

Beward N13100 Bedienungsanleitung

Beward

Beward N120 Bedienungsanleitung

Beward

Beward N1250 Bedienungsanleitung

Beward

Beward N 1000 Bedienungsanleitung

Beward

Beward N6603 Bedienungsanleitung

Beward

Beward N6601 Bedienungsanleitung

Beward

Beward N6601 Bedienungsanleitung

Beward

Beward N300 Bedienungsanleitung

Beward

Beward N300 Bedienungsanleitung

Beward

Beward N 1000 Bedienungsanleitung

Beward

Beward N13201 Bedienungsanleitung

Beward

Beward N37210 Bedienungsanleitung

Beliebte IP-Kamera Handbücher anderer Marken

FLIR

FLIR Exx series Bedienungsanleitung

Avigilon

Avigilon H4A-BO1-IR Bedienungsanleitung

Digital Watchdog

Digital Watchdog DWCA-C128-64 Bedienungsanleitung

ShareTech

ShareTech AV1 Bedienungsanleitung

Ezviz

Ezviz C6C Bedienungsanleitung

Melchioni

Melchioni UCAM 2015 Bedienungsanleitung

Geutebruck

Geutebruck G-Cam/ESD-4630 Bedienungsanleitung

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Bedienungsanleitung

Mitel

Mitel 6800i Series Service-Handbuch

Vitek

Vitek VTC-IR403-212NP Bedienungsanleitung

THOMSON

THOMSON DSC - 323W Bedienungsanleitung

AVer

AVer FB2027 Bedienungsanleitung

ENFORCER

ENFORCER EV-T5105-N2SQ Bedienungsanleitung

Wansview

Wansview NC543 Bedienungsanleitung

Eneo

Eneo MCB-64A0003M0A Bedienungsanleitung

deView electronics

deView electronics CBDNI36F Bedienungsanleitung

Swann

Swann SwannEye Bedienungsanleitung

LevelOne

LevelOne IP CamSecure Bedienungsanleitung
