Beyerdynamic M Series Bedienungsanleitung

M Series PRO X

Wired microphones

M 70 PRO X

M 90 PRO X

USER MANUAL

English

14/22

Safety inructions .................................................................................................................. 15

Intended use ............................................................................................................................................................... 15

Liability........................................................................................................................................................................... 15

Product descriptions......................................................................................................................... 16

M70PROX....................................................................................................................................................................16

M90PROX....................................................................................................................................................................18

Inallation and commissioning.................................................................................................... 20

Attaching the microphone .................................................................................................................................20

Connecting the microphone..............................................................................................................................20

Aligning the microphone .....................................................................................................................................20

Disposal............................................................................................................................................... 20

Troubleshooting................................................................................................................................ 20

Service.................................................................................................................................................. 21

Fuher information ........................................................................................................................... 21

Cleaning............................................................................................................................................... 21

Warranty.............................................................................................................................................. 21

Compliance......................................................................................................................................... 21

15/22Safety inructions

Thank you for choosing a product from beyerdynamic.

This user manual contains impoant information about using your product.

Links with fuher information on the use of microphones or headphones from

beyerdynamic can be found under “Fuher information” on page21.

Safety inructions

•Please read this user manual and the safety inructions carefully and completely before

using the product.

•Do not give the product to anyone else without the user manual.

•Do not use the product if it is damaged.

•Please observe the relevant country-specific regulations before using the product.

•Take care to lay the connection cable in such a way that no one can trip over it and

damage the product.

•Repairs mu only be carried out by authorised speciali personnel. Under no

circumances should you open the microphone yourself. The warranty is void for

devices that have been opened by the cuomer.

•Do not expose the product to rain, snow, liquids or moiure.

•Only use the product under the conditions specified in the technical data.

•Only use accessories and spare pas approved by the manufacturer.

•Reduce the volume on connected playback devices to prevent hearing damage,

acouic feedback and damage to speakers.

Intended use

Only use the product as described in this product manual. beyerdynamic does not assume

any liability for improper use of the product and accessories.

Liability

•The company beyerdynamic GmbH & Co. KG accepts no liability for damage to the

product or injury to persons caused by careless, improper or incorrect use of the product,

or by use for purposes not specified by the manufacturer.

•beyerdynamic is not liable for damage to USB devices that do not comply with the USB

specifications.

English

16/22 Product descriptions

Product descriptions

M70PROX

Scope of delivery

•1x M 70 PRO X microphone

•Elaic suspension

•Pop filter

•Protective bag

Product overview

Speech direction

Pop filter

Microphone in the spider with

mounting nut

Elaic suspension

(spider)

XLR (M) connector

17/22Product descriptions

Applications

The M 70 PRO X dynamic microphone with extended and balanced frequency response has

been designed for high-quality recording of speech, vocals and inruments. Unwanted

sound waves are eectively suppressed by the pronounced cardioid characteriic, and

the precisely tuned proximity eect guarantees consient sound clarity. An extended

frequency response provides a dierentiated and high-resolution sound image.

The robu design of the M 70 PRO X ensures durability. The integrated elaic syem

suspension protects the microphone again ructure-borne noise, and the pop filter

supplied largely suppresses plosive sounds.

The M 70 PRO X is paicularly suitable for the following sources:

•Speech for broadca applications (radio, podca, reaming)

•Vocals (rock, pop music)

•Guitar and bass amps

Technical data

Conveer principle ��Dynamic

Operating principle��Pressure gradient receiver

Polar pattern��Cardioid

Frequency response:

Near field....................................................................25–18,000 Hz

Far field (diance 1 m)..................................... 40–18,000 Hz

Open-circuit

sensitivity�� 1�8 mV/Pa (-55�0 dBV) ±3 dB

Nominal impedance ��350 Ω

Nominal terminating impedance��≥ 1�5 kΩ

Connection�� XLR, 3-pin, male

Length�� 185 mm

Diameter�� 52 mm

Weight��320 g

Polar pattern

Target frequency response curve (±3 dB)





Curves for distance = 2cm and = 1m

English

18/22 Product descriptions

M90PROX

Scope of delivery

•1x M 90 PRO X microphone

•Elaic suspension

•Pop filter

•Protective bag

Product overview

Pop filter

Speech direction

Microphone in the spider with

mounting nut

Elaic suspension

(spider)

XLR (M) connector

19/22Product descriptions

Applications

With its 34-mm true condenser capsule, the M 90 PRO X condenser microphone has been

specially developed for high-quality recording of vocals and inruments but is also suitable

for the natural-sounding recording of speech during broadcas. While unwanted sound

waves are suppressed eectively by the pronounced cardioid characteriic, the low-

noise circuit specially developed by beyerdynamic ensures that the electrical signals are

processed to the highe andard. The integrated elaic syem suspension protects the

microphone again ructure-borne noise, and the pop filter supplied largely suppresses

plosive sounds.

The M 90 PRO X is paicularly suitable for the following sources:

•Vocals

•Acouic guitar

•Piano

•Strings

•Speech for broadca applications

•Universal use (percussion, room miking, choir and

orchera)

Technical data

Conveer principle ��Condenser

Operating principle�� Pressure gradient

receiver

Frequency response�� 20–20,000 Hz

Polar pattern��Cardioid

Open-circuit sensitivity

at 1 kHz (0 dB = 1 V/Pa)��36�3 mV/Pa =

-28�8 dBV ±2 dB

Nominal impedance �� < 180 Ω

Nominal terminating impedance��≥ 1,000 Ω

Maximum sound pressure level

(at 1 kHz)��133 dB

S/N ratio (referenced to 1 Pa)�� 88�4 dBA

Equivalent sound pressure level

(A-weighted)��5,6 dB

Power supply��20–52 V (phantom)

Current consumption�� < 6�2 mA

Connection�� XLR, 3-pin, male

Length��197mm

Diameter��52mm

Weight�� 296g

Polar pattern

Target frequency response curve (±2 dB)

0 dB = 36,3 mV/Pa





Curves for distance = 2cm and = 1m

English

20/22 Inallation and commissioning

Inallation and commissioning

CAUTION Cable trip hazard

Carelessly laid cables pose a trip hazard. This can injure people and damage the

microphone.

►Always lay cables so that no one can trip over them.

Attaching the microphone

1. Unscrew the mounting nut from the microphone thread.

2. Inse the microphone into the spider with the bottom side fir.

3. Tighten the mounting nut on the thread.

4. Attach the microphone to the and with the and connector.

5. Attach the microphone to the and with the and connector.

Connecting the microphone

•The M 70 PRO X has a 3-pin XLR connector. It can be connected to any microphone input

with a suitable microphone cable.

•The M 90 PRO X has a 3-pin XLR connector. It can be connected to any microphone input

with phantom power (24–52V) with a suitable microphone cable. You therefore need to

activate the phantom power.

Aligning the microphone

WARNING Unable and

An unable and can fall and damage the microphone mounted on it.

►Make sure that the and used and the microphone mounted on it are able.

►Position the microphone so that the speech direction is opposite that of the source of

inteerence to achieve the be possible noise suppression.

Disposal

At the end of its life, this product should not be disposed of with normal

household wae but should be taken to a recycling facility for electric and

electronic devices. This symbol on the product, inructions for use or packaging

indicates this.

WEEE

Troubleshooting

If you have technical problems while using the microphones or need fuher guidance,

please visit our FAQ website at suppo.beyerdynamic.com

21/22Service

Service

►If service is required, please contact an authorised speciali. Never open the

microphone yourself. You could lose all warranty claims otherwise.

Please refer to our website www.beyerdynamic.de for information about service and spare

pas.

Fuher information

If you require fuher information, please visit our website at

www.beyerdynamic.com/microphones.html.

For tutorials and inructions on using your microphone, please visit our YouTube channel at

www.youtube.com/beyerdynamic.

Cleaning

►Use a so cloth moiened with water to clean the suace.

►Make sure that no water enters the microphone.

►Do not use cleaning agents containing solvents.

Warranty

beyerdynamic provides a limited warranty of 2 years on the purchased beyerdynamic

product. The exact warranty conditions can be found on our website at

www.beyerdynamic.de/service/garantie.

Compliance

Information about the product’s compliance can be found on our website at

www.beyerdynamic.com/downloads.

English
