Biostar M7TDE Bedienungsanleitung

M7TDE

Federal Communications Commission

(F.C.C.) Statement

This device complies with Part 15 of the FCC Rules. Operation of this device is

subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Accessories: This device has been tested and found to comply with the limits of a

Class B digital device; the accessories associated with this equipment are as

follows:

1. Shielded serial cable. (Can be obtained from multiple retail outlets)

2. Shielded printer cable. (Can be obtained from multiple retail outlets)

3. Shielded video cable. (Can be obtained from multiple retail outlets)

4. Shielded power cord. (Provided by manufacturer)

These accessories are required to ensure compliance with FCC Rules. It is the

responsibility of the user to provide and use these accessories properly.

This equipment has been tested and found to comply with the limits of a Class B

digital device, pursuant of Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and radiates radio frequency energy

and, if you did not installed and used in accordance with the instructions, may

cause harmful interference in the radio communications. There is no guarantee

that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, you are encouraged to try to

correct the interference by one or more of the following measures:

1. Reorient / relocate the receiving antenna.

2. Increase the separation between the equipment and the receiver.

3. Connect the equipment into an outlet from a circuit where the receiver is

connect.

4. Consult the dealer or an experienced radio/TV technician for help.

Caution: Changes or modifications that is not expressly approved by the

manufacturer could void the user’s authority to operate the equipment.

Disclaimer

The vendor makes no representations or warranties with respect to the contents

and specially the vendor disclaims any implied warranties of merchantability or

fitness for any purpose. Further, the vendor reserves the right to revise this

publication and to make changes of the contents without obligation to notify any

party beforehand.

Duplication of this publication, in part or in whole, is not allowed without first

obtaining the vendor’s approval in writing.

Trademarks and Remarks

MS-DOS, Windows, Windows NT, Windows 9X, Windows ME, Windows 2000

and Windows XP are products of Microsoft Corp, with its ownership of trademark,

and are distributed by the vendor under a license agreement.

All trademarks used in this manual are property of their respective owners.

Canadian D.O.C. Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus to set out of the radio interference regulations of the

Canadian Department of Communications.

Cet appareil numérique n‘émet pas de bruits radioélectriques dépassant les limites

appliquées aux appareils numériques de Class B préscrits dans le réglement du

brouillage radioélectrique edict par le minister Des Communications du Canada.

Contents

Introduction ..................................................................................1-1

1. Motherboard Description........................................................1-2

1.1 Features...................................................................................................1-2

1.1.1 Hardware...........................................................................................................1-2

1.1.2 BIOS.................................................................................................................1-6

1.1.3 Software............................................................................................................1-6

1.1.4 Accessories.......................................................................................................1-6

1.2 Motherboard Installation.........................................................................1-7

1.2.1 System Block Diagram....................................................................................1-7

1.2.2 Layout of Motherboard....................................................................................1-8

1.2.3 Quick Reference...............................................................................................1-8

1.2.3 Quick Reference...............................................................................................1-9

1.3 CPU Installation....................................................................................1-10

1.3.1 0CPU Installation Procedure: Socket 478....................................................1-10

1.3.2 CPUFan Header: JCFAN1...........................................................................1-11

1.3.3 System Fan Header: JSFAN1(Optional).....................................................1-11

1.4 RAM Module Installation .....................................................................1-12

1.4.1 DIMM.............................................................................................................1-12

1.4.2 Howto install a DIMM Module...................................................................1-14

1.5 Slots ......................................................................................................1-15

1.5.1 AGP (Accelerated Graphics Port) Slot.........................................................1-16

1.5.2 CNR (Communication Network Riser) Slot................................................1-16

1.5.3 PCI (Peripheral Component Interconnect) Slots..........................................1-16

Contents

1.6 Connectors, Headers & Jumpers...........................................................1-17

1.6.1 Front Panel Connector: JPANEL1 ...............................................................1-18

1.6.2 ATX 20-pin Power Connector: JATXPWR1..............................................1-20

1.6.3 ATX 12V Power Connector: JATXPWR2.................................................1-20

1.6.4 AUX Power Connector: JAUXPWR1.........................................................1-20

1.6.5 Hard Disk Connectors: IDE1/IDE2..............................................................1-21

1.6.6 Floppy Disk Connector: FDD1.....................................................................1-21

1.6.7 Wake On LAN Header: JWOL1..................................................................1-21

1.6.8 Clear CMOSJumper: JCMOS1...................................................................1-22

1.6.9 Front USB Headers: JUSB2..........................................................................1-22

1.6.10 DIMMPower Voltage Selection: JDIMMVOLT....................................1-22

1.7 Peripheral Port.......................................................................................1-23

1.7.1 PS/2 Mouse / Keyboard Connector: JKBMS1............................................1-23

1.7.2 USB& LAN Connector: JRJ45USB1.........................................................1-24

1.7.3 Serial and Parallel Interface Ports..................................................................1-25

1.7.3.1 The Serial Interface: JCOM1/ JCOM2....................................................1-25

1.7.3.2 Parallel Interface Port: JPRNT1 ..............................................................1-27

1.7.4 Game (Joystick/MIDI) Port Connector: JGAME1 .....................................1-28

1.7.5 Audio Port Connectors: JSPKR1/JLIN1/JMIC1.........................................1-28

1.7.6 Audio Subsystem...........................................................................................1-29

1.7.6.1 CD-ROM Audio-In Header: JCDIN1 .....................................................1-30

1.7.6.2 Front Audio Header: JAUDIO1...............................................................1-30

1.7.6.3 Telephony Audio Header: JTAD1(Optional) .........................................1-30

2. BIOS Setup................................................................................2-1

Contents

iii

2.1 Main Menu..............................................................................................2-3

2.2 Standard CMOS Features........................................................................2-6

2.3 Advanced BIOS Features........................................................................2-9

2.4 Advanced Chipset Features...................................................................2-13

2.5 Integrated Peripherals ...........................................................................2-16

2.6 Power Management Setup.....................................................................2-21

2.7 PnP/PCI Configurations........................................................................2-26

2.8 PC Health Status ...................................................................................2-29

2.9 Frequency Control.................................................................................2-31

3. Trouble Shooting.......................................................................3-1

Chapter 1 Motherboard Description

1-1

Introduction

System Overview

Congratulations on the purchase of your new system! This motherboard is designed

to takeadvantage of the latest industry technology to provide you with the ultimate

solution in data processing. In the tradition of its predecessors, this motherboard

continues the commitment of reliability, performance and strives for full compliance

and compatibility with industry software and hardware standards.

M7TDE Highlights:

8 Contains on board I/O facilities, which include two serial ports, a parallel port, a PS/2

mouse port, a PS/2 keyboard port, audio ports, USB ports, a LAN port (optional) and a

game port.

8 Contains on board IDE facilities for IDE devices such as hard disks and CD-ROM

Drives.

8 Supports the Intel Pentium 4®(Socket 478) processor, a leading edge processor which

brings to you the latest technology in micro architecture design, graphics performance,

system bus design, cache architecture and much more.

8 Complies with PC Micro ATX form factor specifications.

8 Supports popular operating systems such as Windows 95/98, Windows NT, Windows

2000, Windows ME, Windows XP, LINUX and SCO UNIX.

Chapter 1 Motherboard Description

1-2

1. Motherboard Description

1.1 Features

1.1.1 Hardware

CPU

−Single Socket-478 for an Intel Pentium ®4 processor.

−Supports the Intel Pentium ®4 processor subset of the Enhanced Mode

Scaleable Bus Protocol.

−Intel Pentium ®4 System Bus interrupt delivery.

−Supports system bus Dynamic Bus Inversion (DBI).

−Supports 32-bit system bus addressing.

Speed

−Runing at 400 MHz Front Side Bus frequency.

−Supports up to 2 GHz CPU core speeds.

−The 33MHz 32 bit PCI 2.2 compliant.

−The 66MHz AGP 2.0 compliant interface supports 1x, 2x and 4x data

transfer mode. (Supports only 1.5v AGP electricals.)

Chipset

−Intel 82845/82801BA.

−Winbond W83627HF.

Chapter 1 Motherboard Description

1-3

DRAM Memory

−Supports 200MHz or 266MHz DDR SDRAM devices.

−Supports 128MB, 256MB, 512MB/ 1GB technologies for x8 and 16

devices.

−Supports one DDR-SDRAM channel, 64 wide (72b with ECC).

−No support for DSx16 DIMMs.

Shadow RAM

−Motherboard is equipped with a memory controller providing shadow

RAM and support for ROM BIOS.

Green Functionality

−Supports Award BIOS™ power management functionality.

−Has a power down timer from 1 to 15 minutes.

−Wakes from power saving sleep mode with any keyboard or mouse

activity.

BUS Slots

−One AGP slot.

−One CNR slot (Support Type A CNR only).

−Three 32-bit PCI bus slots.

Flash Memory

−Supports flash memory functionality.

−Supports ESCD functionality.

Chapter 1 Motherboard Description

1-4

Built in IDE Facilities

−Supports four IDE hard disk drives.

−Supports PIO Mode 4, Master Mode, and high performance hard disk

drives.

−Supports disk transfer rates up to 100 MB/second.

−Supports Ultra DMA 33, Ultra DMA 66, Ultra DMA 100 Bus Master

Modes.

−Supports IDE interface with CD-ROM.

−Supports high capacity hard disk drives.

−Supports LBA mode.

AC’97 Sound Codec Onboard

−AC-LINK protocol comfliance.

−AC’97 2.2compliant.

−Energy saving power down modes.

−18-bit full duplex stereo ADC,DACs.

Universal Serial Bus

−Supports two back panel Universal Serial Bus Ports and two front panel

Universal Serial Bus Ports (optional).

−Supports 48 MHz USB.

BIOS Hardware Monitor Function

−Monitors CPU Fan Speed.

−Monitors System Voltage.

−Monitors System Fan Speed.

Chapter 1 Motherboard Description

1-5

Super I/O Built-in onboard

−Support one multi-mode Parallel Port.

(1) Standard & Bidirection Parallel Port (SPP).

(2) Enhanced Parallel Port (EPP).

(3) Extended Capabilities Port (ECP).

−Supports two serial ports, 16550 UART with 16 byte FIFO.

−UART data rates up to 1.5 Mbaud.

−Supports one Infrared transmission (IR) port.

−Supports PS/2 Mouse /Keyboard.

−Supports 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB floppy disk

drives.

Accelerated Graphics Port (AGP) Interface

−Supports a single AGP device (either a connector or on the

motherboard).

−Supports AGP 2.0 including 4X AGP data transfers and 2x/4x Fast

Write protocol.

−Supports only 1.5v AGP electricals.

−High priority access support.

−Hierarchical PCI configuration mechanism.

Dimensions (Micro ATX form-factor)

−22.1cm x 24.4cm (WxL).

LAN (Optional)

−10 Mb/s and 100 Mb/s operation.

−Supports 10/100 Mb/s N-way Auto-negotiation operation

−Supports Wake-On-LAN function and remote wake-up.

−Supports Full Duplex Flow Control (IEEE 802.3X)

Andere Handbücher für M7TDE

Inhaltsverzeichnis

Andere Biostar Hauptplatine Handbücher

Biostar

Biostar M7VIT 800 V7.X Bedienungsanleitung

Biostar

Biostar M5ATD Bedienungsanleitung

Biostar

Biostar P4M890-M7 FE - QUICK Bedienungsanleitung

Biostar

Biostar P4 TDP Bedienungsanleitung

Biostar

Biostar TA970XE Bedienungsanleitung

Biostar

Biostar H61MH Benutzerhandbuch

Biostar

Biostar 865G MICRO 775 Benutzerhandbuch

Biostar

Biostar G41U3G Benutzerhandbuch

Biostar

Biostar H81MGP2 Benutzerhandbuch

Biostar

Biostar BIELK-IHT Bedienungsanleitung

Biostar

Biostar TH55XE - BIOS Bedienungsanleitung

Biostar

Biostar H110MDS2 PRO D4 Bedienungsanleitung

Biostar

Biostar B250GT3 Bedienungsanleitung

Biostar

Biostar BI94GS-IAC Benutzerhandbuch

Biostar

Biostar H81MDV5 Benutzerhandbuch

Biostar

Biostar TZ68K Bedienungsanleitung

Biostar

Biostar A760GE - BIOS Bedienungsanleitung

Biostar

Biostar Hi-Fi B85S2G Benutzerhandbuch

Biostar

Biostar U8668 Pro Bedienungsanleitung

Biostar

Biostar H61MHV3 Bedienungsanleitung

Biostar

Biostar Hi-Fi H170Z3 Bedienungsanleitung

Biostar

Biostar H310MHP 3.0 Bedienungsanleitung

Biostar

Biostar P4TDK Bedienungs- und Montageanleitung

Biostar

Biostar VIOTECH 3100 PLUS - BIOS Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
