SRP-380/382II

Command Manual

Ver. 1.00

http://www.bixolon.com

SRP-380/382II

Ver. 1.00 BIXOLON

- 2 -

■ Contents

1. Notice ....................................................................................................................................................................................................... 3

2. Control Commands List in Alphanumeric Order ................................................................................................................................... 4

2-1 Command Description Items ...................................................................................................................................................................... 6

2-2 Details of Control Commands ..................................................................................................................................................................... 7

SRP-380/382II

Ver. 1.00 BIXOLON

- 3 -

1. Notice

This document contains proprietary information of BIXOLON Corporation and its affiliates. You may utilize the information solely

for the purpose of facilitating authorized sales and service of, or developing software and similar products for authorized use with,

BIXOLON products, provided that such proprietary information may not be used, reproduced, or disclosed to any other parties for

any other purpose without the prior written permission of BIXOLON Corporation. BIXOLON has no liability for loss or damage

arising from or relating to your use of or reliance on the information in the document.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following,

product specifications and/or user manual content may be changed without prior notice.

SRP-380/382II

Ver. 1.00 BIXOLON

- 4 -

2. Control Commands List in Alphanumeric Order

No.

Command Function

No.

Command Function

1 HT Horizontal tab

26 ESC R Specify an international character set

2 LF Print and line feed

27 ESC S Select standard mode

3 FF Form feed (in page mode)

28 ESC T Select print direction in page mode

4 CR Print and carriage return

29 ESC V Turn 90° clockwise rotation mode on/off

5 CAN Cancel the print data in page mode

30 ESC W Set print area in page mode

6 DLE EOT Transmit real-time status

31 ESC \ Set relative print position

7 DLE DC4 Generate pulse at real-time

32 ESC a Set position alignment

8 ESC SP Set the character right space

33 ESC d Print and feed n lines

9 ESC ! Set print mode

34 ESC i Partial cut

10 ESC $ Set absolute print position

35 ESC m Partial cut

11 ESC % Select/cancel user-defined character set

36 ESC p Generate pulse

12 ESC & Define user-defined character set

37 ESC t Select character code table

13 ESC * Specify bit image mode

38 ESC v Transmit paper sensor status

14 ESC - Turn underline mode on/off

39 ESC { Turn upside-down print mode on/off

15 ESC 2 Select default line spacing

40 FS p Print NV bit image

16 ESC 3 Set line spacing

41 FS q Define NV bit image

17 ESC = Select peripheral device

42 GS ! Select character size

18 ESC ? Cancel user-defined characters

43 GS $ Set absolute vertical print position in

page mode

ESC @

Initialize printer

GS ( A

Execute test print

20 ESC D Set horizontal tab positions

GS ( L

GS 8 L Select graphics data

21 ESC E Turn emphasized mode on/off

46 GS ( k Specify and print the symbol

22 ESC G Turn double-strike mode on/off

47 GS * Define downloaded bit image

23 ESC J Print and feed paper

48 GS / Print downloaded bit image

24 ESC L Select page mode

49 GS : Start/end macro definition

25 ESC M Select character font

50 GS B Turn white/black reverse print mode on/off

SRP-380/382II

Ver. 1.00 BIXOLON

- 5 -

No.

Command Function

51 GS H Select print position of HRI characters

52 GS I Transmit printer ID

53 GS L Set left margin

54 GS V Select cut mode and executes a partial cut

55 GS W Set print area width

56 GS ^ Execute macro

57 GS a Enable/Disable Automatic Status Back (ASB)

58 GS f Select font for HRI characters

59 GS h Set bar code height

60 GS k Print bar code

61 GS r Transmit status

62 GS v 0 Print raster bit image

63 GS w Set bar code width

64 BS M Select device font type

65 BS V Select cut mode and executes a partial/full

cut

66 BS ^ P Set power saving mode

SRP-380/382II

Ver. 1.00 BIXOLON

- 6 -

2-1 Command Description Items

Command

Function: Command function outline

Code: Command format expressed in ASCII, hexadecimal, and decimal codes

Range: Argument value (Setting range) for the command

Default: Initial argument value for the command

Description: Detailed command function description

Remarks: Additional information about using the command

Differences: Variations depending on the printer model

SRP-380/382II

Ver. 1.00 BIXOLON

- 7 -

2-2 Details of Control Commands

Function: Horizontal tab

Code: ASCII HT

Hex 09

Decimal

Range: None

Default: None

Description: This command moves the print position to the next

horizontal tab position. If the next horizontal tab position is

not specified, this command will be void.

Remarks: ■ The horizontal tab position is set by <ESC> D.

■ With the underline mode turned on, the underline printing is not applied to the tab space created by this

command.

Differences: None

SRP-380/382II

Ver. 1.00 BIXOLON

- 8 -

Function: Print and line feed

Code: ASCII LF

Hex 0A

Decimal

Range: None

Default: None

Description: This command prints the data in the print

buffer and feeds one line based on the current set line spacing in

standard mode.

Remarks: ■ In page mode, the printer does not perform actual printing, but moving only the print position to the next

line.

Differences: None

SRP-380/382II

Ver. 1.00 BIXOLON

- 9 -

Function: Form feed (in page mode)

Code: ASCII FF

Hex 0C

Decimal

Range: None

Default: None

Description: This commands prints all data collected in the printer buffer In page mode. A

fter completion of printing, the

printer is returned to standard mode.

Remarks: ■ The printer is returned to standard mode after completion of printing.

■ This command works in page mode enabled by ESC L.

■ If the paper is positioned at the print starting position, this command is ignored, not performing actual paper

feeding operation.

Differences: None

SRP-380/382II

Ver. 1.00 BIXOLON

- 10 -

Function: Print and carriage return

Code: ASCII CR

Hex 0D

Decimal

Range: None

Default: None

Description:

This command prints the data. With auto line feed enabled, it performs printing and one line feeding same as

LF.

Differences: None
