Command Manual

SRP-270

Impact Printer

Rev. 1.01

http://www.samsungminiprinters.com

Rev. 1.01 - 2 -

SRP-270

■Table of Contents

1. Notice.......................................................................................................................... 3

2. Control Commands List ............................................................................................ 3

2-1 EPSON Mode ......................................................................................................... 3

2-2 CITIZEN Mode........................................................................................................ 4

2-3 STAR Mode ............................................................................................................ 4

3. Control Commands Details....................................................................................... 6

3-1 Command Notation................................................................................................. 6

3-2 Explanation of Terms.............................................................................................. 6

3-3 Control Commands Details..................................................................................... 6

Rev. 1.01 - 3 -

SRP-270

1. Notice

This Control Commands Manual contains information on the protocol and functions of all

control commands that can be used with this printer (SRP-270).

2. Control Commands List

2-1 EPSON Mode

Control code Hexadecimal code Function

<HT> 09 Horizontal tab

<LF> 0A Print and line feed

<CR> 0D Print and carriage return

<DLE> <EOT> n 10 04 n Real-time status transmission

<DLE> <ENQ> n 10 05 n Real-time request to printer

<ESC> <SP> n 1B 20 n Set right-side character spacing

<ESC> ! n 1B 21 n Select print modes

<ESC> % n 1B 25 n Select/Cancel user-defined character set

<ESC> & y c1 c2 .. 1B 26 y c1 c2 Define user-defined characters

<ESC> * m nL nH .. 1B 2A m nL nH Select bit-image mode

<ESC> - n 1B 2D n Turn underline mode on/off

<ESC> 2 1B 32 Select default line spacing

<ESC> 3 n 1B 33 n Set line spacing

<ESC> < 1B 3C Return home

<ESC> = n 1B 3D n Set peripheral device

<ESC> ? n 1B 3F n Cancel user-defined characters

<ESC> @ 1B 40 Initialize printer

<ESC> D n1 ~ nK 1B 44 … 00 Set horizontal tab position

<ESC> E n 1B 45 n Turn emphasized mode on/off

<ESC> G n 1B 47 n Turn double-strike mode on/off

<ESC> J n 1B 4A n Print and feed paper

<ESC> K n 1B 4B n Print and Reverse feed

<ESC> R n 1B 52 n Select an international character set

<ESC> U n 1B 55 n Turn unidirectional printing mode

<ESC> a n 1B 61 n Select justification

<ESC> c 3 n 1B 63 33 n Select paper sensor to output paper end signals

<ESC> c 4 n 1B 63 34 n Select paper sensor to stop printing

<ESC> c 5 n 1B 63 35 n Enable/Disable panel button

<ESC> d n 1B 64 n Print and feed n lines

<ESC> p m t1 t2 1B 70 m t1 t2 Generate pulse

<ESC> t n 1B 74 n Select character code table

<ESC> r n 1B 72 n Select print color

<ESC> m 1B 6D Execute partial cut

<ESC> { n 1B 7B n Turn on/off upside-down printing mode

<ESC> e n 1B 65 n Print and reverse feed n lines

<GS> I n 1D 49 n Transmit printer ID

<GS> V m

<GS> V m n

1D 56 m

1D 56 m n

Select cut mode and cut paper

<GS> a n 1D 61 n Enable/Disable Automatic status back

<GS> r n 1D 72 n Transmit status

Rev. 1.01 - 4 -

SRP-270

2-2 CITIZEN Mode

Control code Hexadecimal code Function

<FF> "n" 0C + n "n" -lines paper feed command

<LF> OA Paper feed command

<SO> 0E Enlarged character command

<SI> 0F Normal character command

<DC1> 11 Initial set command

<DC2> 12 Inverted character command

<DC3> 13 Red color print command

<CAN> 18 Clear command

<ESC> "P" <0> 1B, 50, 00 Paper partial cut command

<ESC> "P" <1> 1B, 50, 01 Paper partial cut command

<ESC> "-" "n" 1B, 2D, n Underline command

<ESC> "1" 1B, 31 1/9 inch paper feed preset command

<ESC> "2" 1B, 32 2/9 inch paper feed preset command

<ESC> "C" "n" 1B, 43, n Page length set command

<ESC> "f" "1" 1B, 66, 01 Form feed command

<SUB> 1A Second drawer drive command

<FS> 1C First drawer quick drive command

<ESC><BEL> n1 n2 1B, 07, n1, n2 Drive pulse setting command for the first

drawer

<BEL> 07 First drawer drive command

2-3 STAR Mode

Control code Hexadecimal code Function

<ESC> "C" n 1B 43 n Set page length at n lines

<ESC> "R" n 1B 52 n Select international character set.

<ESC> "M" 1B 4D Select 9×7(Half dots) character size

<SO> 0E Select expanded character mode

<SI> 0F Select upside-down

<DC2> 12 Cancel upside-down character

<DC4> 14 Cancel expanded character mode

(Default setting)

<ESC> "W" "1"

1B 57 31

1B 57 01

Select expanded character mode

<ESC> "W" "0"

1B 57 30

1B 57 00

Cancel expanded character mode

(Default setting)

<ESC> "4" 1B 34 Red color print selection

<ESC> "5" 1B 35 Red color print deselection

<ESC> "E" 1B 45 Emphasized print mode selection

<ESC> "F" 1B 46 Emphasized print mode deselection

(Default setting)

<ESC> "a" n 1B 61 n Feed paper n lines

Rev. 1.01 - 5 -

SRP-270

Control code Hexadecimal code Function

<ESC><BEL>n1 n2 1B 07 n1 n2 Adjust drive pulse width for peripheral

unit(Default setting)

<BEL> 07 Deferred drive command "A" for peripheral

unit 1

<FS> 1C Immediate drive command "B" for peripheral

unit 1

<SUB> 1A Immediate drive command for peripheral

unit 2

<EM> 19 Immediate drive command for peripheral

unit 2

<CAN> 18 Cancel print data in buffer

<ESC> "@" 1B 40 Initialize printer

<ESC> "e" "0"

1B 65 30

1B 65 00

FEED switch valid

(Default setting)

<ESC> "e" "1"

1B 65 31

1B 65 01

FEED switch invalid

<ESC> U n 1B 55 n Set or Cancel uni-direction mode

<ESC> - n 1B 2D n Set or Cancel underline mode

<ESC> "z" "1"

1B 7A 31

1B 7A 01

Set 1/6 inch line feed

<FF> 0C Page feed (form feed)

<ESC> d <0> 1B 64 00 Partial cut

<ESC> d <1> 1B 64 01 Partial cut

<ESC> "-" "1"

1B 5F 31

1B 5F 01 Select overline mode

<ESC> "-" "0"

1B 5F 30

1B 5F 00

Cancel overline mode

<ESC> "e" "1"

1B 65 31

1B 65 01 Set the control panel switch invalid

<ESC> "e" "0"

1B 65 30

1B 65 00 Set the control panel switch valid

<ESC> "f" "1"

1B 66 31

1B 66 01 Set the ON LINE switch invalid

<ESC> "f" "0"

1B 66 30

1B 66 00 Set the ON LINE switch valid

Rev. 1.01 - 6 -

SRP-270

3. Control Commands Details

3-1 Command Notation

[Name]

[Format]

[Range]

[Description]

The name of the command.

The code sequence. ASCII Indicates the ASCII equivalents.

Hex indicates the hexadecimal equivalents.

Decimal indicates the decimal equivalents.

[ ] k indicates the contents of the [ ] should be repeated k times.

Gives the allowable ranges for the arguments.

Describes the function of the command.

3-2 Explanation of Terms

LSB

Least Significant Bit

3-3 Control Commands Details

[Name]

[Format]

[Description]

Horizontal tab.

ASCII HT

Hex 09

Decimal 9

Moves the print position to the next horizontal tab position.

[Name]

[Format]

[Description]

Print and line feed.

ASCII LF

Hex 0A

Decimal 10

Prints the data in the print buffer and feeds one line based on the current

line spacing.

[Name]

[Format]

[Description]

Print and carriage return.

ASCII CR

Hex 0D

Decimal 13

- This command prints the data in the print buffer and does not feed the

paper.

- Sets the print starting position to the beginning of the line.

Rev. 1.01 - 7 -

SRP-270

DLE EOT n

[Name]

[Format]

[Range]

[Description]

Real-time status transmission.

ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

1 ≤n ≤4

Transmits the selected printer status specified by n in real-time, according

to the following parameters :

n = 1 : Transmit printer status.

n = 2 : Transmit off-line status.

n = 3 : Transmit error status.

n = 4 : Transmit paper roll sensor status.

n = 1 : Printer status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 Drawer open/close signal is LOW (connector pin 3).2

On 04 4 Drawer open/close signal is HIGH (connector pin 3).

Off 00 0 On-Line3

On 08 8 Off-Line

4 On 10 16 Not used. Fixed to On.

Off 00 0 Not waiting for on-line recovery.5

On 20 32 Waiting for on-line recovery.

6 - - - Undefined.

7 Off 00 0 Not used. Fixed to Off.

n = 2 : Off-line status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

2 - - - Undefined.

Off 00 0 Paper is not being fed by using the PAPER FEED

button.

On 08 8 Paper is being fed by the PAPER FEED button.

4 On 10 16 Not used. Fixed to On.

Off 00 0 No paper-end stop.5

On 20 32 Printing stops due to paper end.

Off 00 00 No error.6

On 40 64 Error occurs.

7 Off 00 0 Not used. Fixed to Off.

Rev. 1.01 - 8 -

SRP-270

n = 3 : Error status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

2 Off 00 0 No mechanical error.

On 04 4 Mechanical error occurred.

3 - - - Undefined.

4 On 10 16 Not used. Fixed to On.

6 Off 00 0 No auto-recoverable error.

On 40 64 Auto-recoverable error has occurred.

7 Off 00 0 Not used. Fixed to Off.

Bit 2 :

Bits 2 & 3 :

Bit 6 :

Mechanical errors include home position, carriage sensor, and slip ejection

errors.

If these errors occur due to paper jams or the like, it is possible to recover by

correcting the cause of the error and executing ELE ENQ n(1 ≤n ≤2). If an

error due to a circuit failure (e.g. broken wire) occurs, it is impossible to

recover.

If the print head temperature becomes high, bit 6 is transmitted until the print

head temperature drops sufficiently. The printer automatically recovers from

this error.

n = 4 : Continuous paper sensor status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 Paper roll end sensor. Paper adequate.2

On 04 4 Paper roll end sensor. Paper end.

Off 00 0 Paper roll end sensor. Paper adequate.3

On 08 8 Paper roll end sensor. Paper end.

4 On 10 16 Not used. Fixed to On.

Off 00 0 Paper roll end sensor. Paper present.5

On 20 32 Paper roll end sensor. No paper.

On 00 0 Paper roll end sensor. Paper present.6

On 40 64 Paper roll end sensor. No paper.

7 Off 00 0 Not used. Fixed to Off.

DLE ENQ n

[Name]

[Format]

[Range]

[Description]

Real-time request to printer.

ASCII DLE ENQ n

Hex 10 05 n

Decimal 16 5 n

1 ≤n ≤2

Recovers from an error after clearing the receive and print buffers.

This command is available only with a serial interface, and is ignored with

a parallel interface.

Rev. 1.01 - 9 -

SRP-270

ESC SP n

[Name]

[Format]

[Range]

[Description]

Set right-side character spacing.

ASCII ESC SP n

Hex 1B 20 n

Decimal 27 32 n

0 ≤n ≤255

Sets the character spacing for the right side of the character to n/160

inches.

ESC ! n

[Name]

[Format]

[Range]

[Description]

Select print mode(s).

ASCII ESC ! n

Hex 1B 21 n

Decimal 27 33 n

0 ≤n ≤255

Selects print mode(s) using n as follows.

Bit Off/On Hex Decimal Function

Off 00 0 Character font(9 ×9) selected.0

On 01 1 Character font(9 ×7) selected.

1,2 - - - Undefined.

Off 00 0 Emphasized mode not selected.3

On 08 8 Emphasized mode selected.

Off 00 0 Double-height mode not selected.4

On 10 16 Double-height mode selected.

Off 00 0 Double-width mode not selected.5

On 20 32 Double-width mode selected.

6 - - - Undefined.

Off 00 0 Underline mode not selected.7

On 80 128 Underline mode selected.

* Determine the values of n by adding the value of all the characteristics

you want to select.

ESC % n

[Name]

[Format]

[Range]

[Description]

[Notes]

[Default]

Select / Cancel user-defined character set.

ASCII ESC % n

Hex 1B 25 n

Decimal 27 37 n

0 ≤n ≤255

Selects or cancels the user-defined character set.

When the Least Significant Bit(LSB) is 0, the user-defined character set is

canceled and the internal character set is enabled.

When the LSB is 1, the user-defined character set is selected.

The user-defined character and the downloaded bit image cannot be

defined simultaneously.

n = 0

Rev. 1.01 - 10 -

SRP-270

ESC & y c1 c2 [x1 d1…d(y X x1)]… [xk d1… d(yx X xk)]

[Name]

[Format]

[Range]

[Description]

Define user-defined characters.

ASCII ESC & n y c1 c2[x1d1…d(y X x1)]… [xk d1… d(yx X xk)]

Hex 1B 26 n y c1 c2[x1 d1…d(y X x1)]… [xk d1… d(yx X xk)]

Decimal 27 38 n y c1 c2[x1 d1…d(y X x1)]… [xk d1… d(yx X xk)]

y = 2, 32 ≤c1 ≤c2 ≤126

0 ≤x ≤12 (9x9 font)

0 ≤x ≤9 (7x9 font)

0 ≤d1 … d(y X x) ≤255

Defines user-defined characters.

- y specifies the number of bytes in the vertical direction.

- c1 specifies the beginning character code for the definition,

and c2 specifies the final code. For only one character, use c1 = c2.

- The allowable character code range is from decimal code 32 to 126.

The maximum number of user-define character is 95.

- x specifies the number of dots in the horizontal direction.

- d is the dot data for the characters. The dot pattern is on the horizontal

direction from the left side. Any remaining dots on right side are blank.

- The number of bytes required to download a character definition for one

character is “y” X “x”.

- In the definition data, a “1” represents a dot that is to be printed, and

a “0” represents a dot that is not to be printed.

- Independent downloaded character definitions are possible for each font.

The font is selected characters are cleared in the following circumstance.

1. When “ESC @” is executed

2. When deleted by “ESC ?”

3. When printer is reset or turned off

ESC * m nL nH d1…dk

[Name]

[Format]

[Range]

[Description]

Select bit-image mode.

ASCII ESC * mnLnHd1…dk

Hex 1B 2A mnLnHd1…dk

Decimal 27 42 mnLnHd1…dk

m = 0, 1

0 ≤nL ≤255

0 ≤nH ≤1

0 ≤d ≤255

Selects a bit-image mode using m for the number of dots specified by nL

and nH.

Horizontal Direction

m No. Vertical Dots Dot Density Adjacent dot Maximum number of dots

0 8 Single Density Permitted 180

1 8 Double Density Prohibited 360

Andere Handbücher für Bixolon SRP-270

Inhaltsverzeichnis

Andere BIXOLON Drucker Handbücher

BIXOLON

BIXOLON SRP-350 PlusA Bedienungsanleitung

BIXOLON

BIXOLON SPP-R210 Bedienungsanleitung

BIXOLON

BIXOLON SRP-370 - Two-color Direct Thermal Printer Bedienungsanleitung

BIXOLON

BIXOLON SPP-R300 Installations- und Betriebshandbuch

BIXOLON

BIXOLON XD5-40d Series Bedienungsanleitung

BIXOLON

BIXOLON SRP-S3000 Gebrauchsanweisung

BIXOLON

BIXOLON SRP-350II Bedienungsanleitung

BIXOLON

BIXOLON SRP-383 Bedienungsanleitung

BIXOLON

BIXOLON SRP-370 - Two-color Direct Thermal Printer Bedienungsanleitung

BIXOLON

BIXOLON SPP-R200 Gebrauchsanweisung

BIXOLON

BIXOLON SLP-DX220 Bedienungsanleitung

BIXOLON

BIXOLON BK5-31 Bedienungsanleitung

BIXOLON

BIXOLON XM7-20 Gebrauchsanweisung

BIXOLON

BIXOLON SRP-350III Bedienungsanleitung

BIXOLON

BIXOLON SRP-330II Installations- und Betriebsanleitung

BIXOLON

BIXOLON SRP-380 Installations- und Betriebsanleitung

BIXOLON

BIXOLON SRP-350plusV Gebrauchsanweisung

BIXOLON

BIXOLON SLP-DX420 Bedienungsanleitung

BIXOLON

BIXOLON SRP-350plusA Bedienungsanleitung

BIXOLON

BIXOLON SRP-350 PlusA Bedienungsanleitung

BIXOLON

BIXOLON SRP-350 PlusA Bedienungsanleitung

BIXOLON

BIXOLON SRP-350plusII Bedienungsanleitung

BIXOLON

BIXOLON STP-103II Bedienungsanleitung

BIXOLON

BIXOLON SRP-275IIIAOSG Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
