BIXOLON SRP-Q200 Bedienungsanleitung

Network Connection Manual

SRP-Q200

THERMAL RECEIPT PRINTER

Ver. 1.00

http://www.bixolon.com

SRP-Q200

Table of Contents

1. Manual Information......................................................................................................3

2. Precautions..................................................................................................................3

3. Specifications ..............................................................................................................4

4. How to Connect............................................................................................................5

4-1 Connecting Printer....................................................................................................5

4-1-1 USB cable.....................................................................................................5

4-1-2 WLAN...........................................................................................................5

4-2 Checking Network Setting ........................................................................................6

4-2-1 LAN and Wireless(WLAN or BLUETOOTH).................................................6

4-2-2 LAN Setting Values.......................................................................................7

4-2-3 WLAN Setting Values ...................................................................................8

4-3 Android Soft AP mode..............................................................................................9

4-4 iOS Soft AP mode...................................................................................................10

4-5 How to change Infrastructure mode........................................................................11

5. Ethernet Test by using Windows Test Page............................................................13

6. Factory Reset.............................................................................................................20

6-1 Initializing WLAN Setting ........................................................................................20

6-2 Factory Reset Values .............................................................................................21

7. Troubleshooting.........................................................................................................22

Ver. 1.00 - 2 -

SRP-Q200

1. Manual Information

This manual provides information on the connection of wireless network with the printer.

This document contains proprietary information of BIXOLON and its affiliates.

You may utilize the information solely for the purpose of facilitating authorized sales and

service of, or developing software and similar products for authorized use with, BIXOLON

products, provided that such proprietary information may not be used, reproduced, or

dis-closed to any other parties for any other purpose without the prior written permission of

BIXOLON.

BIXOLON has no liability for loss or damage arising from or relating to your use of the

information in the document.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and

quality of all our products. In following, product specifications and/or user manual content

may be changed without prior notice.

2. Precautions

- The printer has to be within 100m(Outdoor) from AP(Access point) to connect

WLAN. Although 35m is able to communicate in door, WLAN could be affected by

environment to be shorten.

- The maximum separating distance may be shortened if transmission obstacles, such

as cement walls, are present.

- If a device (such as a microwave oven, wireless LAN, etc.) that uses the same

frequency is present, transmission may be interrupted. Separate the printer and

Bluetooth-enabled device from such interrupting devices by a distance of at least 5m.

Ver. 1.00 - 3 -

SRP-Q200

3. Specifications

CATEGORIES

FEATURE

IMPLEMENTATION

LAN

Specification Interface 10/100 Base-T All in one(Auto detection)

Protocol

DHCP Client, HTTP, ARP, ICMP, IPv4, TCP, UDP

WLAN

Specification

Operation Mode Infrastructure, Soft AP, Ad-hoc, Wi-Fi Direct

Wireless

Standard

IEEE 802.11b/g/n, IEEE 802.11a/b/g/n

Range Up to 100m free space (Outdoor)

Security

WEP64/128

WPA1/2 – PSK

WPA 1/2 – Enterprise

(EAP-TLS, EAP-TTLS, PEAP, LEAP, EAP-FAST)

Management WLAN Configuration tool, HTTP,

Smart connection APP

Ver. 1.00 - 4 -

SRP-Q200

4. How to Connect

WLAN can be configured through the printer’s WLAN interface. Likewise, WLAN can also

be configured though the printer’s USB interface.

4-1 Connecting Printer

4-1-1 USB cable

Connect USB cable to Printer, PC device.

Use the “Net Configuration Tool” to adjust the settings.

4-1-2 WLAN

Connect to the AP (Access Point) configured in Infrastructure mode in order to connect to

the LAN/wireless network

In order to configure the network between the wireless host device and the printer, set the

printer to Soft AP Mode.

* Soft AP mode is only supported on WLAN.

A P

Ver. 1.00 - 5 -

SRP-Q200

4-2 Checking Network Setting

4-2-1 LAN and Wireless(WLAN)

After the printer has finished booting, open the printer cover and press and hold the FEED

Button. This will cause the interface setting confirmation mode.

Then add the paper, close the cover, and check that the following message is printed.

* Errors LED is toggled/blinked until WLAN is booted

If the above message is printed, select Mode 1, and you will see the following LAN data.

(To select Mode 1, press the Feed button once quickly/ once long.)

Checking Interface Setting

0: Exit

1: LAN Information Print

2: LAN Factory Reset and Reboot Printer

3: WLAN Information Print

4: WLAN Factory Reset and Reboot Printer

5 or more: None

Select Modes by Feed button control

as below.

Step 1. Short-press as many times as

The mode number to choose.

Step 2. Long-press over 1 second.

*e.g. To choose Mode 2, press Feed

Button 3 times(short-short-long)

FEED Button

Cover Open Lever

Ver. 1.00 - 6 -

SRP-Q200

4-2-2 LAN Setting Values

Classification Item Description Input Range

Network

Inactivity Time

TCP connection hold time

0~3600 integer

IP Assignment

Method IP Assignment Method DHCP/Manual

IP Address Printer IP IP Address

Subnet Mask Subnet mask IP Address

Gateway Default Gateway IP Address

Ver. 1.00 - 7 -

SRP-Q200

4-2-3 WLAN Setting Values

Classification Item Description Input Range

Home WLAN setting status display

Network

Network Mode Wireless LAN operating mode Infrastructure/Adhoc

Adhoc Channel Channel when creating Adhoc

network 1~14

SSID ID of the AP to connect 1~32 letters

Inactivity Time TCP connection hold time 0~3600 integer

IP Assignment

Method IP Assignment Method DHCP/Manual

IP Address Printer IP IP Address

Subnet Mask Subnet mask IP Address

Gateway Default Gateway IP Address

DNS Domain name server IP IP Address

Authentication

Authentication Wireless LAN authentication

method

open, shared,

wpa1/2-psk, wpa1/2

Cryptograph Wireless LAN encryption method none, WEP64/128,

TKIP, AES

EAP Mode Authentication method none, PEAP, TLS,

LEAP, FAST

WEP Key Key for WEP encryption method

WEP64 (5 Ascii, 10

Hex)

WEP128 (13 Ascii, 26

Hex)

PSK Key Key for PSK encryption method 1~64 letters

Authentication ID ID for EAP Authentication 1~32 letters

Authentication PW Password for EAP Authentication 1~32 letters

Note For changing network setting values using Net configuration tool,

Refer to ‘Net configuration tool manual’.

Ver. 1.00 - 8 -

SRP-Q200

4-3 Android Soft AP mode

1) Select “Wi-Fi”. 2) Select the printer to connect.

3) Select “CONNECT”. 4) Wi-Fi communication is available.

Ver. 1.00 - 9 -

SRP-Q200

4-4 iOS Soft AP mode

1) Select “Wi-Fi”. 2) Wi-Fi ON and Select the printer

to connect.

3) Wi-Fi communication is available.

Ver. 1.00 - 10 -
