BJE 007685 Montageanleitung
1. Locate the most visible location to install control panel.
2. Securely (not permanently) mount control panel to wall.
3. Assemble gauge (do not install to tank).
4. Loosen thumbscrews on sensor.
5. Slide sensor to desired depth (high or low).
6. Connect an ohmmeter to sensor leads.
8. Once proper setting is achieved, lock sensor in place using thumbscrews - tighten
9. Remove glass jar and linkage assembly from bung adaptor - do not disturb sensor
setting.
10. Use appropriate sealant on the male threads of bung adaptor.
past hand tight, but do not overtighten.
12. Install linkage assembly into bung adaptor. Float arm must travel freely and not contact
overtighten.
14. Solder (or wire nut) sensor leads then tape the connections.
15. Seal hole with silicone or appropriate sealant.
16. Connect wire to printed circuit board terminals marked "FLOAT".
17. Install 9-volt battery.
DO NOT OVERTIGHTEN. DO NOT USE SIGHT GLASS AS A WRENCH.
TESTING / MAINTENANCE / INSPECTION
Jarhead
WARNING
Page 1 009313-6 7/2019
INSTALLATION INSTRUCTIONS
Daily
"ON" position.
• Remove sensor from tank and
system goes into alarm mode.
connected to control panel and
sensor(s).
Biannually
• Replace 9-volt battery.
Replace 9-volt battery if tank alarm
occurs.
• Follow all city, state, or federal wiring
• Apply city, state, or federal testing
regulations as appropriate.
ANY TEST / INSPECTION FAILURE
REQUIRES IMMEDIATE EQUIPMENT
REPLACEMENT OR REMOVAL FROM
SERVICE.
MADE IN THE USA
Jarhead Tank Gauge
and Inspection Instructions
007685
007686
008646
008664
008677
009969
CAUTION: MONITOR IS DISABLED WHEN TOGGLE SWITCH IS
TURNED OFF!
ALWAYS ADHERE TO INSTALLATION / USAGE INSTRUCTIONS AND WARNINGS.
Improper use may result in injury, damage, or hazardous spill.
Husky Corporation will, at its option, repair, replace, or credit the purchase price of any BJE®product deemed to be defective
in material and/or workmanship for a period of one (1) year.
Buyer must return the products to Husky®, transportation charges prepaid. The warranty excludes damages due to
malfunction, failure to follow manufacturer's installation, operation or maintenance instructions and guidelines, unauthorized
The warranty provisions contained herein apply only to original purchasers who use the equipment for commercial or
Husky assumes no liability for labor charges or other costs incurred by Buyer incidental to the service, adjustment, repair,
incurred by the purchaser during the time necessary to repair the equipment. Husky assumes no liability for any incidental,
consequential, or other damages under any warranty, express or implied, and all such liability is hereby expressly excluded.
Husky reserves the right to change or improve the design of any Husky Oil Filter Crushers, Tank Monitors, Tank Gauges,
WARRANTY
• Use of equipment is at individuals’ own
risk.
and federal regulations regarding
use and installation of monitoring
equipment.
manufacturer’s installation and
maintenance instructions.
during maintenance activities.
damaged equipment immediately.
to appropriate authorities.
equipment during maintenance and
inspection activities.
extinguishing equipment within 5 ft /
1.5 m of tanks.
®tape or appropriate
thread sealant.
• The tank contents are the sole
responsibility of the tank owner.
• Never allow waste product to touch eyes
or skin.
• Never install monitors outdoors without
proper protection from the elements.
• Never use on below ground storage
tanks.
• Never exceed the maximum milliamps
and maintenance instructions.
• Never solely rely on this product; there is
no substitute for human supervision.
• Never to be used as a component of any
automatically controlled pump
transfer system.
GENERAL WARNINGS / INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC
SHOCK OR INJURY TO PERSONS:
Applications Single or double walled above ground
tanks.
Fluids Test and warranty for oil, waste oil, diesel
fuel, antifreeze, water and other uids with
a low ash point
Pipe ½" x 6" (12.7 mm x 152.4 mm) NPT PVC
Sensor Buna
Shipping 5 - 8 lbs / 2.2 - 3.6 kg (depends on
Weight length of Jarhead)
Thread 2" / 50.8 mm NPT
Case Quantity 2 - 5 (depends upon length of Jarhead)
WIRING CONNECTIONS
GENERAL TECHNICAL DATA
Audible alarm won't shut o... 1. Replace control panel.
System won't go into alarm mode... 1. Verify all wires are connected properly.
2. Replace the 9-volt battery.
Audible alarm won't sound... 1. Conrm toggle switch is in "ON" position.
Bulk Product Sensor activates alarm prematurely... 1. Conrm oat is in the correct position.
2. Conrm pipe is not over 10 ft (3 m) long.
TROUBLESHOOTING GUIDE
Husky Corporation • 2325 Husky Way • Pacic, MO 63069 • Phone: (800) 325-3558 • Fax: (636) 825-7300 • www.husky.com
Page 3 009313-6 7/2019
Model 007675, 007676 Leak Guards
007680,007681OverllGuards
1. Remove eyelet connector from end of chain and save.
2. Determine tank depth in inches.
3. Stand oat on end on a at work surface alongside a
measuring tape and pull chain taut to desired measurement.
4. Subtract 2" (50.8 mm) from determined measurement and
mark chain.
5. Cut chain on mark then feed chain through bottom center hole
in shaft and back out either side hole of shaft.
6. Secure chain with eyelet by crimping eyelet closed.
7. Loosen thumbscrews on sensor.
8. Slide sensor, positioning arrow just inside top of clear window.
9. Connect an ohmmeter to sensor leads.
10. Using chain, pull orange indicator to bottom of gauge and
conrm circuit is open.
11. Slowly release chain tension allowing spring to raise orange
indicator to its full extension
12. Conrm circuit is now closed.
13. Tighten thumbscrews rmly, approximately 1 to 2 turns past
hand tight - do not overtighten.
14. Apply appropriate sealant to the male threads of bung adaptor.
15. Slowly lower weighted oat into tank and tighten gauge,
approximately 1 to 2 turns past hand tight, onto tank bung.
16. Conrm orange indicator is at proper level - if tank is empty
it should not be visible. (If visible, remove sight glass and
depress orange indicator. Reinstall sight glass. If orange
indicator is still visible, recheck measurements in steps 2 - 4
and shorten chain as required).
17. Solder (or wire nut) sensor leads then tape connections.
18. Seal hole with silicone or appropriate sealant.
19. Connect wire to printed circuit board terminals marked
"FLOAT".
SENTRY REMOTE LEAK / OVERFILL GUARDS
12-VOLT TRANSFORMER
Model 007595
1. Select a non-switched 24-hour hot 115v outlet, preferably
dedicated solely for use with the monitor.
2. Temporarily remove the 9-volt battery.
3. Connect transformer to printed circuit board terminals marked
"OPTIONAL XFORMER". Observation of polarity is not
necessary.
4. Reinstall 9-volt battery.
5. Secure transformer to outlet using outlet plate screw.
6. Test control panel to conrm audible siren sounds.
NOTE: Connection of the transformer should always be the last
connection to the control panel.
Use 18-gauge / 2 conductor wire up to
150 ft (45.7 m)
or
14 gauge / 2 conductor wire up to 350 ft
(106.6 m) to connect all components.
