BlackVue DR770X-2CH Bedienungsanleitung
Quick Start Guide
DR770X-2CH LTE
DR970X-2CH LTE
www.blackvue.com Detailed Manual
ENGLISH/NEDERLANDS
For manuals, customer support and FAQs go to www.blackvue.com
Voor handleidingen, Customer Support en Veelgestelde Vragen, ga naar
www.blackvue.com
BLACKVUE
DR770X-2CH LTE l DR970X-2CH LTE
DR770X-2CH LTE l DR970X-2CH LTE 3
Important safety information
For user safety and to avoid property damage, read through this manual and follow
these safety instructions to use the product correctly.
yDo not disassemble, repair, or modify the product yourself.
Doing so may cause fire, electric shock, or malfunction. For internal inspection and
repair, contact the service center.
yDo not adjust the product while driving.
Doing so may cause an accident. Stop or park your car in a safe place before installing
and setting up the product.
yDo not operate the product with wet hands.
Doing so may cause electric shock.
yIf any foreign matter gets inside the product, detach the power cord immediately.
Contact the service center for repair.
yDo not cover the product with any material.
Doing so may cause external deformation of the product or fire. Use the product
and peripherals in a well-ventilated location.
yIf the product is used outside the optimal temperature range, performance can decline
or malfunctions may occur.
yWhen entering or exiting a tunnel, when directly facing into bright sunlight, or when
recording at night without lighting the quality of recorded video may deteriorate.
yIf the product is damaged or the power supply is cut due to an accident, video may
not be recorded.
yDo not remove the microSD card while the microSD card is saving or reading data.
The data can be damaged or malfunctions may occur.
4BLACKVUE
FCC Compliance Information
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protections against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception
which can be determined by turning the equipment off and on, the user is encouraged
to ty to correct the interference by one or more of the following measures.
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
yConsult the dealer or an experienced radio, TV technician for help.
yOnly shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not expressly
approved by the grantee or manufacturer could void the user’s authority to operate
such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation of this device.
FCC ID: YCK-BV7LTE, YCK-DR970XLTE
DR770X-2CH LTE l DR970X-2CH LTE 5
CAUTION
Any changed or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
There is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
CE WARNING
yChanges and modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
yIt is desirable that it be installed and operated with at least 20cm or more between the
radiator and a person’s body (excluding extremities: hand, wrists, feet, and ankles).
Disposal of your BlackVue dashcam
1. All electrical and electronic products should be disposed of
separately from the municipal waste stream via designated
collection facilities appointed by the government or the local
authorities. Contact local authorities to learn about disposal and
recycling options available in your area.
2. The correct disposal of your BlackVue dashcam will help prevent
potential negative consequences for the environment and human
health.
3. For more detailed information about disposal of your BlackVue
dashcam, please contact your city office, waste disposal service or
the shop where you purchased the product.
6BLACKVUE
IC Compliance
This Class [B] digital apparatus complies with Canadian ICES-003.
This radio transmitter has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
- IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicable aux appreils
radio exempts de license.
L’exploitation est autoriséee aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l ’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, méme si
le brouillage est susceptible d’encompromettre le fonctionnement.
DR770X-2CH LTE l DR970X-2CH LTE 7
Declaration of Conformity
Product information
For the following
Product: radio equipment/ dashcam
Type: DR770X-2CH LTE | DR970X-2CH LTE
Declaration and applicable standards
Hereby, TJM Supplies B.V. declares that the type of radio equipment DR770X-2CH LTE |
DR970X-2CH LTE conforms to:
Directive EMC 2014/53/EU and the RoHS directive (2011/65/EU) on the restriction of
the use of certain hazardous substances in electronic equipment by applying EN 50581:
2012 and IEC 62321-3-1: 2013.
The full text of the EU declaration of conformity can be found at the following internet
address:
https://blackvue-nederland.nl/declaration-of-conformity/
Importer
Company: TJM Supplies B.V.
Address: Zompstraat 8
8102 HX Raalte
The Netherlands
Email: [email protected]
Phone number: +31 85-0402973
Business license number: 72016981
VAT number: NL858946439B01
8BLACKVUE
Verklaring van overeenstemming
Productgegevens
Voor het volgende
Product: radioapparatuur/ dashcam
Model(len): DR770X-2CH LTE | DR970X-2CH LTE
Verklaring en toepasselijke normen
Hierbij verklaart TJM Supplies B.V., dat het type radioapparatuur DR770X-2CH LTE |
DR970X-2CH LTE conform is met:
Richtlijn EMC 2014/53/EU en de RoHS richtlijn (2011/65/EU) betreffende beperking
van het gebruik van bepaalde gevaarlijke stoffen in elektronische apparatuur door
toepassing van EN 50581:2012 en IEC 62321-3-1:2013.
De volledige tekst van de EU-conformiteitsverklaring kan worden geraadpleegd op het
volgende internetadres:
https://blackvue-nederland.nl/declaration-of-conformity/
Importeur
Bedrijfsnaam: TJM Supplies B.V.
Adres: Zompstraat 8
8102 HX Raalte
Nederland
Email: [email protected]
Telefoon: +31 85-0402973
KVK nummer: 72016981
BTW nummer: NL858946439B01
DR770X-2CH LTE l DR970X-2CH LTE 9
In the box
Check the box for each of the following items before installing the BlackVue dashcam.
Front camera Rear camera
connection cable
Rear camera Cigarette lighter
power cable
Hardwiring power
cable Quick start guide
Double-sided tape
for the Mounting
Brackets
Cable clips (8 EA)
SIM eject tool microSD card reader
microSD card SIM card (optional)
Pry tool
Need help?
Download the manual (including FAQs) and the latest firmware from www.blackvue.com
Or contact a Customer Support expert at cs@pittasoft.com
ENGLISH
ENGLISH
10 BLACKVUE
At a glance
The following diagrams explain each part of the BlackVue dashcam.
Front camera
B/W/L
GPS LED
: Lights blue when GPS is on.
: Blinks blue slowly when GPS is turning off.
B/W/L (Bluetooth, Wi-Fi, LTE) LED
: Lights yellow when LTE is connected.
: Lights white when Wi-Fi is connected.
: Blinks yellow quickly when Bluetooth is in
pairing mode.
: Blinks yellow slowly when Bluetooth is paired.
Recording LED
: Lights orange in normal mode.
: Lights red when (i) an event is being recorded (impact detected),
or (ii) manual recording has started.
: Lights green in parking mode when motion is detected.
Speaker
43 mm
Camera lens
Lock button
57.3 mm
137.6 mm
Mounting bracket Front security LED
: Lights on during (i) normal mode, (ii) an
event is being recorded (impact detected),
(iii) manual recording has started, or (iv)
motion is detected in parking mode.
: Blinks slowly during parking mode motion
detection standby.
