FNT4550

Refrigerator

User Manual

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in a 1st-class

manufacturing facility and checked under the most meticulous quality control

procedures, will provide you with years of good service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future reference.

This manual

• Will help you use your appliance quickly and safely.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

1 Your Freezer 4

2 Warnings 5

Electrical Requirements .....................7

Warning! This Appliance Must Be

Earthed .............................................7

Energy Saving Tips............................8

Compliance with WEEE Directive and

Disposing of the Waste Product: .......8

Compliance with RoHS Directive: ......9

Package information..........................9

3 Installation 10

Points to be paid attention to when the

relocation of the freezer ...................10

Electrical connection........................10

Disposing of the packaging .............11

Disposing of your old freezer ...........11

Placing and Installation ....................11

4Before operating 15

Starting............................................15

5 Using your freezer 16

6 Maintenance and cleaning 17

7 Do's and Don'ts 18

Problem Solving ..............................19

8 How To Obtain Service 20

9 Guarantee Details 21

Figures that take place in this instruction manual are schematic and may not correspond

exactly with your product. If the subject parts are not included in the product you have

purchased, then it is valid for other models.

1Your Freezer

Congratulations on your choice of a BLOMBERG quality Appliance which has

been designed to give you service for many years.

1. Thermostat

2. Flap (Fast-Freeze compartment)

3. Drawers

4. Adjustable front feet

2Warnings

• DO NOT connect

your appliance to the

electricity supply until

all packing and transit

protectors have been

removed.

• Leave to stand for

at least 4 hours before

switching on to allow

compressor oil to settle if

transported horizontally.

• If you are

discarding an old

refrigerator with a lock or

latch fitted to the door,

disable the lock/latch,

ensure that it is left in a

safe condition to prevent

the entrapment of young

children.

• This appliance

must only be used for

its intended purpose

i.e the storing of edible

foodstuff.

• Do not dispose of

the appliance on a fire.

At BLOMBERG, the

care and protection of

our environment is an

ongoing commitment.

This appliance which

is among the latest

range introduced is

particularly environment

friendly. Your appliance

contains non CFC /

HFC natural substances

in the cooling system

(Called R600a) and in

the insulation (Called

cyclopentane) which are

potentially flammable

if exposed to fire.

Therefore, take care

not to damage, the

cooling circuit / pipes

of the appliance in

transportation and in

use. In case of damage

do not expose the

appliance to fire or

potential ignition source

and immediately ventilate

the room where the

appliance is situated.

• We suggest

you contact your local

authority for disposal

information and facilities

available.

• To obtain the best

possible performance

and trouble free

operation from your

appliance it is very

important to carefully

read these instructions.

• On delivery, check

to make sure that the

product is not damaged

and that all the parts

and accessories are in

perfect condition.

• Ensure that the

plug remains readily

accessible. Do not use

multiple adapter or

extension cable.

• Failure to observe

these instructions may

invalidate your right to

free service during the

guarantee period.

• Keep ventilation

openings, in the

appliance enclosure or

in the built-in structure,

clear of obstruction.

• Do not use

mechanical devices

or other means to

accelerate the defrosting

process, other than

those recommended by

the manufacturer.

• Do not damage

the refrigerant circuit.

• Do not use

electrical appliances

inside the food storage

compartments of the

appliance, unless

they are of the type

recommended by the

manufacturer.

• We suggest you

keep these instructions

in a safe place for easy

reference.

• This appliance

can be used by

children aged from 8

years and above and

persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance

in a safe way and

understand the hazards

involved.

• Children should

be supervised to ensure

that they do not play with

the appliance.

Electrical

Requirements

Before you insert the

plug into the wall socket

make sure that the

voltage and the frequency

shown on the rating

plate inside the appliance

corresponds to your

electricity supply.

Rating label is on the left

hand side of inner liner.

We recommend that this

appliance be connected

to the mains supply via a

suitable switched

and fused socket. The

appliance must be

positioned so that the

plug is accessible.

Should the mains lead

of the appliance become

damaged or should it

need

replacing at any time, it

must be replaced by a

special purpose made

mains lead which can

only be obtained from a

BLOMBERG Authorised

Service Agent.

Warning! This

Appliance Must Be

Earthed

If the fitted moulded plug

is not suitable for your

socket, then the plug

should be cut off and an

appropriate plug fitted.

Destroy the old plug

which is cut off as a plug

with bared cord could

cause a shock hazard

if inserted into a socket

elsewhere in the house.

The moulded plug

on this appliance

incorporates a 13 A

fuse. Should the fuse

need to be replaced an

ASTABEAB approved BS

1362 fuse of the same

rating must be used. Do

not forget to refit the fuse

cover. In the event of

losing the fuse cover the

plug must not be used

until a replacement fuse

cover has been fitted.

Colour of the replacement

fuse cover must be the

same colour as that

visible on the pin face of

the plug. Fuse covers are

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22mm.

6mm.

6mm. 32mm.

12mm.

FUSE

CORD GRIP

available from any good

electrical store.

Important! Fitting A

Different Plug

As the colours of the

wires in the mains lead

of this appliance may

not correspond with

the coloured markings

identifying the terminals

in your plug proceed as

follows: (See diagram).

1. Connect the green-yellow or green

(Earth) wire to the terminal in the plug

marked ‘E’ or with the symbol or

coloured green and yellow or green.

2. Connect the blue (Neutral) wire to

the terminal in the plug marked ‘N’ or

coloured black.

3. Connect the brown (Live) wire to the

terminal in the plug marked ‘L’ or

coloured red.

4. With alternative plugs a 13 A fuse

must be fitted either in the plug or

adaptor or in the main fuse box. If in

doubt contact a qualified electrician.

Energy Saving Tips

1. Ensure your appliance is installed in a

well ventilated area.

2. Ensure the time between buying

chilled/frozen food and placing

them in your appliance is kept at

minimum, particularly in summer. We

recommend you use a cool bag or a

special carrier bag to carry perishable

food.

3. Do not leave the door (s) of your

appliance open longer than

necessary and ensure they are closed

properly after each opening.

4.Defrost frozen food in the fridge, so

that frozen food acts as an ice pack

to assist cooling in fridge.

Compliance with

WEEE Directive and

Disposing of the Waste

Product:

Thisproduct

complies with EU

WEEE Directive

(2012/19/EU).

This product

bears a classification

symbol for waste

electrical and electronic

equipment (WEEE).This

product has been

manufactured with high

quality parts and

materials which can be

reused and are suitable

for recycling. Do not

dispose of the waste

product with normal

domestic and other

wastes at the end of its

service life. Take it to the

collection center for the

recycling of electrical and

electronic equipment.

Please consult your local

authorities to learn about

these collection centers.

Compliance with RoHS

Directive:

The product you have

purchased complies

with EU RoHS Directive

(2011/65/EU). It does

not contain harmful and

prohibited materials

specified in the Directive.

Package information

Packaging materials

of the product are

manufactured from

recyclable materials in

accordance with our

National Environment

Regulations. Do not

dispose of the packaging

materials together with

the domestic or other

wastes. Take them to

the packaging material

collection points

designated by the local

authorities.

3Installation

BThe manufacturer will not be liable for

any event caused by disregarding

the information supplied in this user

manual.

Points to be paid attention

to when the relocation of

the freezer

1. Your freezer should be

unplugged.Before transportation of

your freezer, it should be emptied and

cleaned.

2. Before it is re-packaged,

shelves, accessories, crisper, etc.

inside your freezer should be fixed

with adhesive tape and secured

against impacts. Packaging should

be adequate and the transportation

rules on the package should be

strictly observed.

3. Original packaging and foam

materials should be kept for future

transportations or moving.

Before you start the freezer,

Check the following before you

start to use your freezer:

1. Attach 2 plastic wedges as

illustrated below. Plastic wedges are

intended to keep the distance which

will ensure the air circulation between

your freezer and the wall. (The picture

is drawn up as a representation

and may not be identical with your

product.)

2. Clean the interior of the

freezer as recommended in the

“Maintenance and cleaning” section.

3. Connect the plug of the freezer

to the wall socket. When the freezer

door is opened,freezer internal lamp

will turn on.

4. When the compressor starts to

operate, a sound will be heard. The

liquid and gases sealed within the

refrigeration system may also give rise

to noise, even if the compressor is not

running and this is quite normal.

5. Front edges of the freezer may

feel warm. This is normal. These areas

are designed to be warm to avoid

condensation.

Electrical connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

The connection must be in compliance

with national regulations.

• The power plug must be easily

accessible after installation.

• Electrical safety of your freezer shall

be guaranteed only if the earth

system in your house complies with

standards.

• The voltage stated on the label

located at left inner side of your

product should be equal to your

network voltage.

Inhaltsverzeichnis

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg BRFT1522SS Bedienungsanleitung

Blomberg

Blomberg SSM1351I Bedienungsanleitung

Blomberg

Blomberg BRFB 0900 Bedienungsanleitung

Blomberg

Blomberg DND 9977 P Bedienungsanleitung

Blomberg

Blomberg SSM 9550 A+ Bedienungsanleitung

Blomberg

Blomberg BRFB 1042SSN Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN-KQD1254XN Bedienungsanleitung

Blomberg

Blomberg DSM 9630 A++ Bedienungsanleitung

Blomberg

Blomberg BRFB 1450 SS Bedienungsanleitung

Blomberg

Blomberg TSM 1541 Bedienungsanleitung

Blomberg

Blomberg BRFB1312SS Bedienungsanleitung

Blomberg

Blomberg KSE 1550 i Bedienungsanleitung

Blomberg

Blomberg TSM 1541 i A+ Bedienungsanleitung

Blomberg

Blomberg KQD 1360X Bedienungsanleitung

Blomberg

Blomberg BRFB1045 Series Bedienungsanleitung

Blomberg

Blomberg DSM 1510 A+ Bedienungsanleitung

Blomberg

Blomberg KND 9860 XA+ Bedienungsanleitung

Blomberg

Blomberg KNM4760N Bedienungsanleitung

Blomberg

Blomberg brfd2230ss Bedienungsanleitung

Blomberg

Blomberg KWD2330X Bedienungsanleitung

Blomberg

Blomberg KWD 1330 X Bedienungsanleitung

Blomberg

Blomberg KGM4574VPS Bedienungsanleitung

Blomberg

Blomberg KFD4952XD Bedienungsanleitung

Blomberg

Blomberg DNM 1860 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
