D Bedienungsanleitung

Refrigerator

Kühlschrank

Ψυγείο

Frigorifero

DNE 9887 A+

DNE 9887 X A+

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future references.

This manual

• Will help you use your appliance in a fast and safe way.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

This product bears the selective sorting symbol for waste electrical and

electronic equipment (WEEE).

This means that this product must be handled pursuant to European Directive

2002/96/EC in order to be recycled or dismantled to minimize its impact on

the environment. For further information, please contact your local or regional

authorities.

Electronic products not included in the selective sorting process are potentially

dangerous for the environment and human heatlh due to the presence of

hazardous substances.

Recycling

1 Your refrigerator 3

1 Your refrigerator 4

2 Warnings 5

Intended use .....................................5

General safety ...................................5

HCA Warning ....................................8

Things to be done for energy saving..8

3 Installation 9

Preparation........................................9

Points to be considered when re-

transporting your refrigerator .............9

Before operating your refrigerator ......9

Electric connection ..........................10

Disposing of the packaging .............10

Disposing of your old refrigerator .....10

Installing the plastic wedges ............11

Adjusting the legs ............................11

Installing the lower ventilation cover .11

Changing the illumination lamp .......11

CONTENTS

4 Using your refrigerator 12

Temperature setting button..............12

Setting the temperature of your

refrigerator.......................................12

Dual cooling system ........................12

Dual protection................................12

Odour filter ......................................13

Sliding storage container ................13

Snack compartments ......................13

Crisper humidity control sliders........ 14

Icematic and ice storage container ..14

Reversing the doors ........................15

5 Maintenance and

cleaning 16

Protection of plastic surfaces ..........16

6 Recommended solutions

for the problems 17

Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your refrigerator

1- Freezer compartment shelf

2- Icematic

3- Ice storage container

4- Odour filter (in the air duct)

5- Temperature setting button

6- Adjustable glass shelves

7- Wine rack

8- Illumination lens

9- Snack compartments

10- Crisper humidity control sliders

11- Crisper cover

12- Crispers

13- Lower ventilation cover

14- Adjustable legs

15- Freezer compartment door shelf

16- Egg holders

17- Fridge compartment door shelves

18- Wire door shelf

19- Sliding storage containers

20- Freezer compartment

21- Fridge compartment

517

Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your refrigerator

1- Freezer compartment shelf

2- Icematic

3- Ice storage container

4- Odour filter (in the air duct)

5- Temperature setting button

6- Adjustable glass shelves

7- Wine rack

8- Illumination lens

9- Snack compartments

10- Crisper humidity control sliders

11- Crisper cover

12- Crispers

13- Lower ventilation cover

14- Adjustable legs

15- Freezer compartment door shelf

16- Egg holders

17- Fridge compartment door shelves

18- Wire door shelf

19- Sliding storage containers

20- Freezer compartment

21- Fridge compartment

517

2Warnings

.Please review the following

information. If these are not followed,

personal injury or material damage

may occur. Otherwise, all warranty and

reliability commitments will become

invalid.

The usage life of the unit you

purchased is 10 years. This is the

period for keeping the spare parts

required for the unit to operate as

described.

Intended use

.This product is designed for domestic

use.

.It should not be used outdoors. It is

not appropriate to use it outdoor even

if the place is covered with a roof.

General safety

.When you want to dispose/scrap

the product, we recommend you

to consult the authorized service in

order to learn the required information

and authorized bodies.

.Consult your authorized service for

all your questions and problems

related to the refrigerator. Do not

intervene or let someone intervene to

the refrigerator without notifying the

authorized services.

.Do not eat cone ice cream and ice

cubes immediately after you take

them out of the freezer compartment!

(This may cause frostbite in your

mouth.)

.Do not put bottled and canned

liquid beverages in the freezer

compartment. Otherwise, these may

burst.

.Do not touch frozen food by hand;

they may stick to your hand.

.Vapor and vaporized cleaning

materials should never be used in

cleaning and defrosting processes of

your refrigerator. In such cases, the

vapor might get in contact with the

electrical parts and cause short circuit

or electric shock.

.Never use the parts on your

refrigerator such as the door as a

means of support or step.

.Do not use electrical devices inside

the refrigerator.

.Do not damage the cooling circuit,

where the refrigerant is circulating,

with drilling or cutting tools. The

refrigerant that might blow out when

the gas channels of the evaporator,

pipe extensions or surface coatings

are punctured may cause skin

irritations and eye injuries.

.Do not cover or block the ventilation

holes on your refrigerator with any

material.

. Repairs of the electrical appliances

must only be made by qualified

persons. Repairs performed by

incompetent persons may create a

risk for the user.

.In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s mains

supply by either turning off the

relevant fuse or unplugging your

appliance.

.Do not pull by the cable when pulling

off the plug.

.Place the beverage with higher proofs

tightly closed and vertically.

.Flammable items or products that

contain flammable gases (e.g.

spray) as well as the explosive

materials should never be kept in the

appliance.

.Do not use mechanical devices

or other means to accelerate the

defrosting process, others than those

recommended by the manufacturer.

.This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

.Children should be supervised to

ensure that they do not play with the

appliance

.Do not operate a damaged

refrigerator. Consult your service if

you have any doubts.

.Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

.Exposing the product to rain, snow,

sun and wind is dangerous with

respect to electrical safety.

.Contact the authorized service when

there is a power cable damage and

etc. so that it will not create a danger

for you.

.Never plug the refrigerator into

the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

.If you have a lock on the door, the

key should be kept out of reach of

children.

.This refrigerator is designed solely for

storing food. It should not be used for

any other purposes.

.The label that describes the technical

specification of the product is

located on the inner left part of the

refrigerator.

.Do not hook up the refrigator to

electronic energy saving systems as it

may damage the product.

.If the refrigerator has blue light do not

look at the blue light through optical

devices.

.If the power supply is disconnected

in manually controlled refrigerators

please wait for at least 5 minutes

before reconnectig the power.

.This product manual should be

passed to the next owner of the

refrigerator if the owner changes.

.When moving the refrigerator make

sure that you do not damage the

power cord. In order to prevent

fire the power cord should not be

twisted. Heavy objects should not

be placed on the power cord. When

the refrigerator is being plugged do

not handle the power outlet with wet

hands.

.Do not plug the refrigerator if the

electric outlet is loose.

.Do not splash water directly on the

outer or inner parts of the refrigerator

due to safety.

.Do not spray inflammable materials

such as propane gas etc near

refrigerator due to the risk of fire and

explosion.

.Do not place objects filled with water

on top of the refrigerator as it may

result in electric shock or fire.

.Do not overload the refrigerator with

excess food. The excess food may

fall when the door is opened resulting

in injuring you or damaging the

refrigerator. Do not place objects on

top of the refrigerator as the objects

may fall when opening or closing the

refrigerator door.

.Materials that require certain

temperature conditions such as

vaccine, temperature sensitive

medicines, scientific materials etc

should not be kept in refrigerator.

.If refrigerator will not be operated for

an extended period of time it should

be unplugged. A problem in electrical

cable insulation may result in fire.

.The tip of the electric plug should be

cleaned regularly otherwise it may

cause fire.

.The refrigerator may move when the

adjustable feet is not positioned firmly

on the floor. Using the adjustable feet

you can unsure that the refrigerator is

positioned firmly on the floor.

.If the refrigerator has door handle

do not pull the refrigerator via door

handles when moving the product as

it may disconnect the handle from the

refrigerator.

HCA Warning

If your product is equipped with

a cooling system that contains

R600a:

This gas is flammable. Therefore, pay

attention to not damaging the cooling

system and piping during usage and

transportation. In the event of damage,

keep your product away from potential

fire sources that can cause the

product catch a fire and ventilate the

room in which the unit is placed.

Ignore the warning.

If your product is equipped with

a cooling system that contains

R134a.

You can see the gas used in

production of your product on the

rating plate that is located on the left

inner part of it.

Never dispose the product in fire.

Things to be done for energy

saving

.Do not leave the doors of your

refrigerator open for a long time.

.Do not put hot food or drinks in your

refrigerator.

.Do not overload your refrigerator so

that the air circulation inside of it is not

prevented.

.Do not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators.

.Pay attention to keep your food in

closed containers.

3Installation

Please remember that the

manufacturer shall not be held liable if

the information given in the instruction

manual is not observed.

Preparation

CYour refrigerator should be installed at

least 30 cm away from heat sources

such as hobs, ovens, central heater

and stoves and at least 5 cm away

from electrical ovens and should not

be located under direct sunlight.

CThe ambient temperature of

the room where you install your

refrigerator should at least be 10°C.

Operating your refrigerator under

cooler conditions than this is not

recommended with regard to its

efficiency.

CPlease make sure that the interior

of your refrigerator is cleaned

thoroughly.

CIf two refrigerators are to be installed

side by side, there should be at least

2 cm distance between them.

CWhen you operate your refrigerator

for the first time, please observe the

following instructions during the initial

six hours.

- The door should not be opened

frequently.

- It must be operated empty without

any food in it.

- Do not unplug your refrigerator. If

a power failure occurs out of your

control, please see the warnings in

the “Recommended solutions for the

problems” section.

COriginal packaging and foam

materials should be kept for future

transportations or moving.

Points to be considered

when re-transporting your

refrigerator

1. Your refrigerator must be

emptied and cleaned prior to any

transportation.

2. Shelves, accessories, crisper and etc.

in your refrigerator must be fastened

securely by adhesive tape against any

jolt before repackaging.

3. Packaging must be tied with thick

tapes and strong ropes and the

rules of transportation printed on the

package must be followed.

Please remember…

Every recycled material is an

indispensable source for the nature

and for our national resources.

If you wish to contribute to recycling

the packaging materials, you can

get further information from the

environmental bodies or local

authorities.

Before operating your

refrigerator

Before starting to use your refrigerator

check the following:

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg KGM4881 Bedienungsanleitung

Blomberg

Blomberg SOM 9673P Bedienungsanleitung

Blomberg

Blomberg SOM 1650 + Bedienungsanleitung

Blomberg

Blomberg KND 9950 Bedienungsanleitung

Blomberg

Blomberg KQE 1010 X Bedienungsanleitung

Blomberg

Blomberg SSM1351I Bedienungsanleitung

Blomberg

Blomberg SSM4543 Bedienungsanleitung

Blomberg

Blomberg KND 9950 XDA+ Bedienungsanleitung

Blomberg

Blomberg KNE4564EVI Bedienungsanleitung

Blomberg

Blomberg KND 3880 X Bedienungsanleitung

Blomberg

Blomberg DSM 1650 Bedienungsanleitung

Blomberg

Blomberg MDND 1880 Bedienungsanleitung

Blomberg

Blomberg KNM1551i Bedienungsanleitung

Blomberg

Blomberg BRFB1050FFBIN Bedienungsanleitung

Blomberg

Blomberg SSM 9550 A+ Bedienungsanleitung

Blomberg

Blomberg BRFB 1040 Bedienungsanleitung

Blomberg

Blomberg KFD4952XD Bedienungsanleitung

Blomberg

Blomberg KND9921 X Bedienungsanleitung

Blomberg

Blomberg KSM 9641 XA+ Bedienungsanleitung

Blomberg

Blomberg BRFB 10150FFBIN Bedienungsanleitung

Blomberg

Blomberg DNM 9650 T Bedienungsanleitung

Blomberg

Blomberg KNM4563EI Bedienungsanleitung

Blomberg

Blomberg BRFD2650SS5VFLR Bedienungsanleitung

Blomberg

Blomberg KND 9860 XA++ Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
