Blomberg TSM 1541 A+ Bedienungsanleitung

Bedienungsanleitung

Operating instructions

TSM 1541

TSM 1541 A+

TSM 1541 A++

TSM 1541 A+++

Kühlschrank

Refrigerator

Réfrigérateur

Koelkast

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants and

checked under the most meticulous quality control procedures, will provide you

an effective service.

For this, we recommend you to carefully read the entire manual of your product

before using it and keep it at hand for future references.

This manual

• Will help you use your appliance in a fast and safe way.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

This product is supplied with the selective sorting symbol for waste electrical

and electronic equipment (WEEE).

This means that this product must be handled pursuant to European Directive

2002/96/EC in order to be recycled or dismantled to minimise its impact on

the environment. For further information, please contact your local or regional

authorities.

Electronic products not included in the selective sorting process are potentially

dangerous for the environment and human health due to the presence of

hazardous substances.

Recycling

CONTENTS

1 Your refrigerator 3

2 Important Safety

Warnings 4

Intended use ..................................4

For products with a water dispenser;6

Child safety.....................................6

HCA Warning .................................6

Things to be done for energy saving7

3Installation 8

Points to be considered when re-

transporting your refrigerator ..........8

Before operating your refrigerator ...8

Electric connection .........................8

Disposing of the packaging ............9

Disposing of your old refrigerator ....9

Placing and Installation ...................9

Replacing the interior light bulb ....10

Adjusting the feet..........................11

Installation (Under the counter) ....11

4 Preparation 12

Reversing the doors .....................14

5 Using your refrigerator16

Freezing........................................16

Freezing food................................16

Making ice cubes .........................17

Storing frozen food.......................17

Defrosting of the appliance ...........17

Cooling.........................................18

Food storage................................18

Defrosting of the appliance ...........18

6 Maintenance and

cleaning 19

Protection of plastic surfaces .......19

7 Recommended solutions

for the problems 20

1Your refrigerator

1-a.) Freezing compartment & ice tray

(for models)

b.) Frozen food compartment & ice tray

(for models)

2-Interior light & Thermostat knob

3-Movable shelves

4-Defrost water collection channel - Drain

tube

5-Crisper cover

6-Crisper

7-Adjustable front feet

8-Dairy compartment

9-Door shelves

10-Egg tray

11-Bottle shelf

12-Bottle gripper

13-Top trim

CFigures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

2Important Safety Warnings

Please review the following

information. Failure to observe this

information may cause injuries or

material damage. Otherwise, all

warranty and reliability commitments

will become invalid.

The usage life of the unit you

purchased is 10 years. This is the

period for keeping the spare parts

required for the unit to operate as

described.

Intended use

This product is intended to be used

– indoors and in closed areas such as

homes;

– in closed working environments such

as stores and offices;

– in closed accommodation areas such

as farm houses, hotels, pensions.

• This product should not be used

outdoors.

General safety

• When you want to dispose/scrap

the product, we recommend you

to consult the authorized service in

order to learn the required information

and authorized bodies.

• Consult your authorized service for

all your questions and problems

related to the refrigerator. Do not

intervene or let someone intervene to

the refrigerator without notifying the

authorised services.

• For products with a freezer

compartment; Do not eat cone ice

cream and ice cubes immediately

after you take them out of the freezer

compartment! (This may cause

frostbite in your mouth.)

• For products with a freezer

compartment; Do not put bottled and

canned liquid beverages in the freezer

compartment. Otherwise, these may

burst.

• Do not touch frozen food by hand;

they may stick to your hand.

• Unplug your refrigerator before

cleaning or defrosting.

• Vapor and vaporized cleaning

materials should never be used in

cleaning and defrosting processes of

your refrigerator. In such cases, the

vapor may get in contact with the

electrical parts and cause short circuit

or electric shock.

• Never use the parts on your

refrigerator such as the door as a

means of support or step.

• Do not use electrical devices inside

the refrigerator.

• Do not damage the parts, where

the refrigerant is circulating, with

drilling or cutting tools. The refrigerant

that might blow out when the gas

channels of the evaporator, pipe

extensions or surface coatings are

punctured causes skin irritations and

eye injuries.

• Do not cover or block the ventilation

holes on your refrigerator with any

material.

• Electrical devices must be repaired

by only authorised persons. Repairs

performed by incompetent persons

create a risk for the user.

• In case of any failure or during

a maintenance or repair work,

disconnect your refrigerator’s mains

supply by either turning off the

relevant fuse or unplugging your

appliance.

• Do not pull by the cable when pulling

off the plug.

• Place the beverage with higher proofs

tightly closed and vertically.

• Never store spray cans containing

flammable and explosive substances

in the refrigerator.

• Do not use mechanical devices

or other means to accelerate the

defrosting process, other than those

recommended by the manufacturer.

• This product is not intended to be

used by persons with physical,

sensory or mental disorders or

unlearned or inexperienced people

(including children) unless they are

attended by a person who will be

responsible for their safety or who will

instruct them accordingly for use of

the product

• Do not operate a damaged

refrigerator. Consult with the service

agent if you have any concerns.

• Electrical safety of your refrigerator

shall be guaranteed only if the earth

system in your house complies with

standards.

• Exposing the product to rain, snow,

sun and wind is dangerous with

respect to electrical safety.

• Contact authorized service when

there is a power cable damage to

avoid danger.

• Never plug the refrigerator into

the wall outlet during installation.

Otherwise, risk of death or serious

injury may arise.

• This refrigerator is intended for only

storing food items. It must not be

used for any other purpose.

• Label of technical specifications is

located on the left wall inside the

refrigerator.

• Never connect your refrigerator to

electricity-saving systems; they may

damage the refrigerator.

• If there is a blue light on the

refrigerator, do not look at the blue

light with optical tools.

• For manually controlled refrigerators,

wait for at least 5 minutes to start the

refrigerator after power failure.

• This operation manual should be

handed in to the new owner of the

product when it is given to others.

• Avoid causing damage on power

cable when transporting the

refrigerator. Bending cable may cause

fire. Never place heavy objects on

power cable. Do not touch the plug

with wet hands when plugging the

product.

• Do not plug the refrigerator if the wall

outlet is loose.

• Water should not be sprayed directly

on inner or outer parts of the product

for safety purposes.

• Do not spray substances containing

inflammable gases such as propane

gas near the refrigerator to avoid fire

and explosion risk.

• Never place containers filled with

water on top of the refrigerator,

otherwise this may cause electric

shock or fire.

• Do not overload your refrigerator

with excessive amounts of food. If

overloaded, the food items may fall

down and hurt you and damage

Child safety

• If the door has a lock, the key should

be kept away from reach of children.

• Children must be supervised to

prevent them from tampering with the

product.

HCA Warning

If your product's cooling system

contains R600a:

This gas is flammable. Therefore, pay

attention to not damaging the cooling

system and piping during usage and

transportation. In the event of damage,

keep your product away from potential

fire sources that can cause the

product catch a fire and ventilate the

room in which the unit is placed.

Ignore this warning if your

product's cooling system contains

R134a.

Type of gas used in the product is

stated in the type plate which is on the

left wall inside the refrigerator.

Never throw the product in fire for

disposal.

refrigerator when you open the door.

Never place objects on top of the

refrigerator; otherwise, these objects

may fall down when you open or

close the refrigerator's door.

• As they require a precise

temperature, vaccines, heat-sensitive

medicine and scientific materials

and etc. should not be kept in the

refrigerator.

• If not to be used for a long time,

refrigerator should be unplugged. A

possible problem in power cable may

cause fire.

• The plug's tip should be regularly

cleaned; otherwise, it may cause fire.

• The plug’s tip should be cleaned

regularly with a dry cloth; otherwise, it

may cause fire.

• Refrigerator may move if adjustable

legs are not properly secured on the

floor. Properly securing adjustable

legs on the floor can prevent the

refrigerator to move.

• When carrying the refrigerator, do not

hold it from door handle. Otherwise, it

may be snapped.

• When you have to place your product

next to another refrigerator or freezer,

the distance between devices should

be at least 8cm. Otherwise, adjacent

side walls may be humidified.

For products with a water

dispenser;

Pressure of water mains should be

minimum 1 bar. Pressure of water

mains should be maximum 8 bars.

• Use only potable water.

Things to be done for energy

saving

• Do not leave the doors of your

refrigerator open for a long time.

• Do not put hot food or drinks in your

refrigerator.

• Do not overload your refrigerator so

that the air circulation inside of it is not

prevented.

• Do not install your refrigerator

under direct sunlight or near heat

emitting appliances such as ovens,

dishwashers or radiators.

• Pay attention to keep your food in

closed containers.

• For products with a freezer

compartment; You can store

maximum amount of food items in

the freezer when you remove the

shelf or drawer of the freezer. Energy

consumption value stated for your

refrigerator has been determined

by removing freezer shelf or drawer

and under maximum load. There

is no harm to use a shelf or drawer

according to the shapes and size of

food to be frozen.

• Thawing frozen food in fridge

compartment will both provide energy

saving and preserve the food quality.

3 Installation

BPlease remember that the

manufacturer shall not be held liable if

the information given in the instruction

manual is not observed.

Points to be considered

when re-transporting your

refrigerator

1.Your refrigerator must be emptied and

cleaned prior to any transportation.

2.Shelves, accessories, crisper and etc.

in your refrigerator must be fastened

securely by adhesive tape against any

jolt before repackaging.

3.Packaging must be tied with thick

tapes and strong ropes and the

rules of transportation printed on the

package must be followed.

Please do not forget…

Every recycled material is an

indispensable source for the nature

and for our national resources.

If you wish to contribute to recycling

the packaging materials, you can

get further information from the

environmental bodies or local

authorities.

Before operating your

refrigerator

Before starting to use your refrigerator

check the following:

1.Is the interior of the refrigerator dry and

can the air circulate freely in the rear

of it?

2.Please install the 2 plastic wedges

as illustrated in the figure. Plastic

wedges will provide the required

distance between your refrigerator

and the wall in order to allow the air

circulation. (The illustrated figure is

only an example and does not match

exactly with your product.)

3.Clean the interior of the refrigerator as

recommended in the “Maintenance

and cleaning” section.

4.You will hear a noise as the

compressor starts up. The liquid and

gases sealed within the refrigeration

system may also give rise to noise,

even if the compressor is not running

and this is quite normal.

5.Front edges of the refrigerator may feel

warm. This is normal. These areas

are designed to be warm to avoid

condensation

Electric connection

Connect your product to a grounded

socket which is being protected by a

fuse with the appropriate capacity.

Important:

• The connection must be in compliance

with national regulations.

• The power cable plug must be easily

accessible after installation.

• The specified voltage must be equal to

your mains voltage.

• Extension cables and multiway plugs

must not be used for connection.

BA damaged power cable must be

replaced by a qualified electrician.

BProduct must not be operated before

it is repaired! There is danger of

electric shock!

Disposing of the packaging

The packing materials may be

dangerous for children. Keep the

packing materials out of the reach

of children or dispose of them by

classifying them in accordance

with the waste instructions. Do not

dispose of them along with the normal

household waste.

The packing of your refrigerator is

produced from recyclable materials.

Disposing of your old

refrigerator

Dispose of your old refrigerator without

giving any harm to the environment.

•You may consult your authorised dealer

or waste collection center of your

municipality about the disposal of

your refrigerator.

Before disposing of your refrigerator, cut

out the electric plug and, if there are

any locks on the door, make them

inoperable in order to protect children

against any danger.

Placing and Installation

AIf the entrance door of the room

where the refrigerator will be

installed is not wide enough for the

refrigerator to pass through, then call

the authorised service to have them

remove the doors of your refrigerator

and pass it sideways through the

door.

1. Install your refrigerator to a place that

allows ease of use.

2. Keep your refrigerator away from heat

sources, humid places and direct

sunlight.

3. There must be appropriate air

ventilation around your refrigerator

in order to achieve an efficient

operation. If the refrigerator is to be

placed in a recess in the wall, there

must be at least 5 cm distance with

the ceiling and at least 5 cm with

the wall. If the floor is covered with

a carpet, your product must be

elevated 2.5 cm from the floor.

4. Place your refrigerator on an even floor

surface to prevent jolts.

If your appliance is equipped with an air

grille, please refer for installation of the air

grille.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Blomberg Kühlschrank Handbücher

Blomberg

Blomberg DND 1977 XT Bedienungsanleitung

Blomberg

Blomberg KNE4554EVI Bedienungsanleitung

Blomberg

Blomberg FNT 9670 XT Bedienungsanleitung

Blomberg

Blomberg BRFB1 22SS Series Bedienungsanleitung

Blomberg

Blomberg KQD 1250 Bedienungsanleitung

Blomberg

Blomberg SSM 1450 I A++ Bedienungsanleitung

Blomberg

Blomberg SSM1554P Bedienungsanleitung

Blomberg

Blomberg KGM4881 Bedienungsanleitung

Blomberg

Blomberg KQD 1253 XN-KQD1254XN Bedienungsanleitung

Blomberg

Blomberg SST3455I Bedienungsanleitung

Blomberg

Blomberg KGM 9680 Bedienungsanleitung

Blomberg

Blomberg KGM4530 Bedienungsanleitung

Blomberg

Blomberg KKD 1650 Bedienungsanleitung

Blomberg

Blomberg KNM4760N Bedienungsanleitung

Blomberg

Blomberg BRFB 1042SSN Bedienungsanleitung

Blomberg

Blomberg KQD 1360X Bedienungsanleitung

Blomberg

Blomberg KSM 9641 XA+ Bedienungsanleitung

Blomberg

Blomberg BRFB 1450 SS Bedienungsanleitung

Blomberg

Blomberg DSM 1510 Bedienungsanleitung

Blomberg

Blomberg KQD114VPX Bedienungsanleitung

Blomberg

Blomberg SOM 9650 Bedienungsanleitung

Blomberg

Blomberg BRFB 1040 Bedienungsanleitung

Blomberg

Blomberg DSM 9510 A+ Bedienungsanleitung

Blomberg

Blomberg DSM 1510 i Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
