BlueTrek Mini Bedienungsanleitung
EC - Declaration of Conformity
We, Innovi Technologies Ltd of
31/F China Online Centre,
333 Lockhart Road,
Wan Chai, Hong Kong
declare under our sole responsibility that our product
BLUETREK mini
to which this declaration refers is in conformity with the appropriate standards
EN300 328-02
EN301 489-17
EN301 489-01
EN50371
EN60950
Following the provisions of Radio and Telecommunications Terminal Equipment directive
1999/5/EC.
March 2007
Guillaume Ponticelli, Director of Development
FCC/ Industry Canada Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference. (2) This device must accept
any interference received, including interference that may cause undesired operation.
In compliance with Industry Canada regulations, technical specifications have been
provided in a declaration of conformity.This does not imply that Industry Canada approved
the equipment.
Caution: Changes or modifications to this Bluetooth® headset not expressly approved by
the party responsible for compliance could void the user’s authority to operate it.
Bluetooth® is a trademark owned by Bluetooth SIG, Inc. and is used by the manufacturer
under license.
Before using your headset for the first time
-You must charge it continuously for about 4 hours, until the red indicator light turns off.
Please refer to the “Charging the BLUETREK® MINI” section of this manual.
-Pair the headset with a mobile phone. Please refer to the “Pairing the BLUETREK® MINI”
section of this manual.
Introduction
The BLUETREK® MINI headset is a wireless headset based on the Bluetooth® technology. It
complies with Bluetooth® 1.2 protocol, supporting Headset and Hands-free profile.
The BLUETREK® MINI headset has 2 buttons:
·“TALK”button (main button)
· 1“VOL+/-“ button
1 I BLUETREK MINI
English
Charging socket
Indicator light TALK button
VOL+/- button
Microphone
Charging the BLUETREK® MINI
Please connect the charger to the headset and to the main. During the charge, the
indicator light is red. The indicator light will turn off when the charge is complete.
During subsequent charges, the charging should take approximately 3 hours.
When you hear a low-tone beep in your headset at regular intervals, and the indicator light
flashes in red, your headset needs to be recharged.
Important:
· If your headset is fully charged, the red indicator light will not turn on when plugging
into the charger.
(To check whether your headset is fully charged, press the talk button for approx.
2 seconds, once released, the red indicator light will turn on for approx. 3 seconds.)
· To maximize battery lifetime, it is recommended to recharge your headset to full capacity
only when the battery is low, since a battery has a lifetime of about 500 charging cycles.
· If you leave your headset battery empty for an extended period of time, it could
excessively discharge the battery. In this case, charge your headset for 3 hours or more
until the battery recovers and recharges completely.When you first charge the headset
after prolonged storage, it may take few minutes for the red indicator light to turn on.
· Do not charge your headset for more than 10 hours.
· The use of any other charger will automatically suspend the warranty. It is strictly
forbidden and can be very dangerous.
BLUETREK MINI I 2
English
Pairing the BLUETREK® MINI
Before using the BLUETREK® MINI headset, you must pair it with your Bluetooth® mobile
phone. Pairing is the process of linking 2 Bluetooth® devices, so that they can communicate.
To initiate pairing:
Place the BLUETREK® MINI and your mobile phone within 0.3 meter (1 foot) from each
other.
3 I BLUETREK MINI
English
1
2
3
Switch on your phone and select its
Bluetooth® discover mode (refer to the
Bluetooth® mobile phone user manual).
When the BLUETREK® MINI is switched
off, press and hold the TALK button for
about 7 seconds until the indicator light
flashes red and blue alternately. And a
sound can be heard in the speaker.
BLUETREK MINI
“0000”
4
BLUETREK MINI
BLUETREK MINI
5
BLUETREK MINI
Connect
Assign short name
Set as unauthorised
Delete
Select Cancel
If pairing was successful, the indicator light will switch to blue and flashes slowly.
If you haven’t started the discovery mode within 5 minutes, the headset will go to the
standby mode. You must then switch off your headset and start the pairing again.
English
Once the mobile phone detects the headset, a “BLUETREK MINI”message
will be displayed. Follow the phone instructions to accept the pairing.The PIN
code (or passkey) is 0000, then press “yes” or“ok”.
For some phones, you
may need to select
“Connect”
BLUETREK MINI I 4
Fitting lanyard
5 I BLUETREK MINI
English
Switching the BLUETREK® MINI ON and OFF
Switching BLUETREK® MINI ON
When your headset is off, press and hold the TALK button for about 5 seconds until the
blue indicator light is on. A beep (2 tones) can be heard in the speaker. Release the
TALK button.
Switching BLUETREK® MINI OFF
When your headset is on, press and hold the TALK button for about 7 seconds until the red
indicator light is on. A beep (2 tones) can be heard in the speaker then release the TALK
button.
Making a call
Mobile phone with voice recognition
. Make sure the voice recognition function on your mobile is activated and your voice tags
have been recorded with the phone.To enter these, please refer to your phone’s manual.
.When there is no incoming or active call, press once on the TALK button
.Wait for the audio signal sent by the mobile phone (generally a short tone).
. Speak the name of person you wish to call.
English
BLUETREK MINI I 6
Mobile without voice recognition
. Make sure both the headset and the mobile phone are ON and in stand-by mode.
. Dial the number on the phone keypad, after approximately 2 seconds the audio
connection will be established.
This function may not be available on some phones, please refer to the trouble shooting
frequent asked questions in our website: www.bluetrek.com. to find out more.
Answering a call
When the headset rings, press once on the TALK button to take the call.
Ending a call
Press once on the TALK button to end an active call.
Adjusting the volume
To increase the volume during an active call, press the“VOL+”button on the headset.
To decrease the volume during an active call, press the“VOL-“ button on the headset.
7 I BLUETREK MINI
English
Muting the microphone
To mute the microphone during an active call
During an active call, press and hold the VOL+ button for approximately 2 seconds. A
periodic tone can be heard in the speaker when the microphone is muted.
To end the mute function
When the microphone is muted, press and hold the VOL+ button for approximately 2-3
seconds. The periodic tone will end.
Transferring a call from BLUETREK® MINI to the mobile phone
During an active call, double click on the TALK button.
This function only works in the Hands-Free Profile.
In the Headset profile, you can simply turn off your headset.
Transferring a call from the mobile phone to the BLUETREK® MINI
During an active call on the mobile phone, press once on the TALK button to transfer the call.
This function may not be available depending on your phone.
English
BLUETREK MINI I 8
