Introduction

Congratulations on your purchase, and welcome to BOSS Audio Systems!

This product is designed to directly t the Carling type switch location.

It receives audio via Bluetooth streaming and 3.5 mm AUX jack. The

product outputs audio by connection to an external 12V amplier.

The product has a remote output wire which allows the connected amplier

to automatically turn on or off whenever this product is turned on or off.

The product also has illuminated soft buttons for playback control. The

buttons are illuminated blue in Bluetooth mode and red in AUX input mode.

Package Contents

• Bluetooth audio receiver

• User manual and warranty card.

Important

Read and understand all instructions before you use your product. If you

do not follow the instructions in this manual, we are not responsible for

injury or damage resulting from improper handling. This will also void the

warranty.

Important safety precautions

• Be sure to observe the following guidelines:

- Do not increase speaker volume so high that you cannot hear what

is around you.

- Use caution or temporarily discontinue use in potentially hazardous

situations.

• Do not make any adjustment on the product when driving or in other

situations where distractions can be hazardous. Responsible and safe

driving is your primary responsibility when operating a vehicle.

• Start volume at a low setting then gradually increase the volume until

you can hear it comfortably, without sound distortion or ear discomfort.

• In the event of smoke, strange noise or odor emitted from the product

or any other abnormal operational signs appearing on the product,

disconnect the product from the power supply. Discontinue use and

contact your dealer or our technical support. Using the product in this

condition may result in permanent damage to the system.

• Servicing must only be carried out by a technician. Contact our

technical support for any service question.

Installation precautions

• WARNING: Always consult a professional installer.

• Before installation, disconnect the negative terminal of the vehicle

battery to prevent damage to the product, re, and/or possible injury.

• If extending the power cable which connects the vehicle battery, we

recommend to run the extended cable to the battery through a fuse box

(not included) with at least 5A.

• The ground cable should be as short as possible. Connect the ground

cable to metal parts of your vehicle, or to the negative terminal on the

battery if your vehicle does not have a grounded chassis frame.

• If extending the ground cable to the battery, make sure to use a high

quality cable with proper gauge rating.

• Replace a faulty fuse with a new one of the same type and rating.

• Observe the safety and operating instructions of the devices which are

connected to the product.

• DO NOT use abrasive cleaning materials on the product.

• DO NOT submerge the product to water.

Control Panel

Volume up; hold down

to increase rapidly.

Hold down to switch

between BT and AUX

mode.

Start, pause or resume

playback;

in BT mode, hold

down to disconnect or

re-connect BT;

in AUX mode, press

briey to mute or

unmute volume

Volume down; hold

down to decrease

rapidly.

Select next track.

Hold down to power

on or off.

Select previous track.

Mounting

The unit features rocker switch dimensions, and is designed to directly t

the Carling switch location.

Option 1: Direct t

Simply insert the unit into an available Carling sized cut-out on the

dashboard of your vehicle. No drilling or cutting is required.

Option 2: Hole cutting

Find a suitable location in the dashboard, and cut a

rectangular hole (W x H: 0.85” x 1.45”). Then directly t

the unit in the hole.

Important! When drilling or cutting any holes on your

vehicle, make sure the gas tank, fuel lines, hydraulic lines

and electrical wiring are not damaged.

0.85”

1.45”

Wiring

Important notes on wiring

• See the section “Installation precautions”.

• Disconnect the negative terminal of the vehicle battery prior to wiring.

• Connect the unit to a 12V DC battery and negative ground only.

Battery

External

Amplier

Fuse holder

On-off switch

Chassis ground Chassis ground

ATM fuse (2A)

12V

Optional direct battery wiring circuit

A: Using RCA cables (not included), connect the MAIN OUT sockets to

the RCA input on a 12V amplier (not included) for sound output.

B: Using an 18 gauge wire (not included), connect the REMOTE OUT

wire (blue) to the remote terminal on the amplier. This can control

turn-on/turn-off of the amplier whenever the unit is turned on/off.

C: Using an 18 gauge wire, connect the GROUND wire (black) to the

metal frame (chassis) of your vehicle.

D: Using an 18 gauge wire, connect the POWER wire (red) to the

battery (positive terminal). We recommend to connect the battery

through a 5A fuse (not included) and on-off switch (not included).

Bluetooth Audio Streaming

Before you can stream music from your mobile phone to this unit, you

must pair the unit with your mobile phone through Bluetooth.

1. Make sure the unit is connected to an amplier for sound output.

2. Press and hold to turn on the unit. You will hear an audible tone.

- The unit will automatically switch to Bluetooth mode, and the button

backlights will light up blue and ash. This indicates that the unit is

not connected and is currently in pairing mode.

3. On your mobile phone, enable Bluetooth then select “Boss Audio

BPS1RS” to pair the unit with your mobile phone. If prompted for

password, input “0000” on your mobile phone.

- When the unit successfully connects your mobile phone, you will

hear an audio tone, and the button backlights will turn to solid blue.

- If failed to connect your mobile phone, repeat the steps above.

4. Start audio playback on your mobile phone, audio will be streamed to

the unit and will output through the connected amplier.

- The unit automatically connects to the last paired device each time

the two are powered on.

- Hold down to disconnect or reconnect Bluetooth connection.

NOTE: To connect to another device, you have to disconnect the currently

connected device then repeat the steps above to pair with a device.

Playback control through Bluetooth

• To start, pause or resume play, press .

• To select the previous or next track, press or .

• To adjust volume, press or .

- If there is an incoming call during play, music

play will automatically pause. Music play will

automatically resume after the call ends.

AUX Audio Input

You can input audio from a playback device (e.g. a mobile phone or MP3

player) through the AUX IN socket (3.5 mm).

3.5 mm audio

cable

1. Make sure the unit is connected to an amplier for sound output.

2. Press and hold to turn on the unit.

3. Press and hold the button to switch to AUX mode from Bluetooth

mode. The button backlights will turn red.

4. Using a 3.5 mm audio cable (not included), connect

the AUX IN socket (3.5 mm) to the headphone on

your device (e.g. a mobile phone or MP3 player).

5. Start audio playback on the connected device. Audio

will output through the connected amplier.

• To adjust volume, press or .

• To mute or unmute volume, press briey .

- The unit’s buttons cannot be used to select track and

play/pause playback.

Care of the environment

Do not throw away the product with the normal household waste at the

end of its life, but hand it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.

Troubleshooting

Refer to the checklist below to solve the problems when using the product.

If problems persist, contact our technical support. Do not attempt to

disassemble or modify the product.

Problem Solution

No power The fuse is blown. Replace with a new one of the same

type and rating.

The unit is not powered on. Press and hold on the

unit’s control panel to turn it on.

No sound Incorrect source input. Press and hold the button

to select Bluetooth or AUX source.

adfaVolume is minimum. Increase volume using the volume

control on the unit or the connected device.

Make sure the REMOTE OUT wire of the unit is

correctly or securely connected to your amplier.

Make sure the connected amplier has correct signal

input and output connection (refer to the user manual

of the amplier).

No/poor

Bluetooth

connection

Make sure Bluetooth is enabled on your device.

Make sure the device is within Bluetooth range.

To connect to another device, disconnect the current

Bluetooth connection.

Move the device closer to the unit. Or remove any

obstacle between the device and the unit.

Problem Solution

Poor audio

quality

For Bluetooth streaming, move the device closer or

remove obstacles or sources of interference that are

affecting Bluetooth reception.

For best audio performance, set the device volume to a

minimum 75% before connecting to the unit (Bluetooth

and AUX input).

Make sure your amplier has correct settings (refer to

the user manual of the amplier).

No response Power glitch or interference. Disconnect power for 10

seconds then reconnect power.

Specications

BluetoothBBluetooth

• Version: 5.0 + EDR

• Proles: A2DP, AVRCP

• Range: 33 ft/10 m (line of sight)

Audio

• RCA output: 2V RMS

• AUX input: max. 1V RMS

• Input/Output impedance: 10k Ω

• Frequency response:

20Hz - 20kHz

• THD+N: 1%

BluetoothBGeneral

• Power supply: 12V DC (10-16V

allowable)

• Current draw: 1A

• Fuse: 2A (ATM mini type)

• Remote output: max. 300mA

• Weight: 0.22 lbs/ 0.1 kg

• Mounting cut-out (W x H):

0.85” x 1.45”

• Dimensions (W x H x D):

1” x 1.93” x 2.36”

Specications are subject to change without notice.

Inhaltsverzeichnis

Andere Boss Audio Systems Empfänger Handbücher

Boss Audio Systems

Boss Audio Systems BCP62 Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BE10ACP Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems MR1309UAB Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems ELITE HARLEY-DAVIDSON BEHDX98 Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems ELITE BV765B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems MGV500B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BV9370B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems MGV520B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems MGR300B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems ELITE BECPA10W Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BVCP9690A Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems MGV520B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BV9973 Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems MGR450B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems Elite BE7ACP-SD Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems ELITE BE62CP Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BV9364B Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BV755BLC Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems ELITE BV800ACP Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems 508UAB Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BVB9358RC Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems 609UAB Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BV9356 Bedienungsanleitung

Boss Audio Systems

Boss Audio Systems BV9386NV Bedienungsanleitung

Beliebte Empfänger Handbücher anderer Marken

Garmin

Garmin GA 23 Bedienungsanleitung

Aiphone

Aiphone PS-12F Bedienungsanleitung

IMES

IMES TCS-01CA-PMI Bedienungsanleitung

BWI Eagle

BWI Eagle AIR-EAGLE SR Handbuch

AMIMON

AMIMON AMN12310 WHDI Bedienungsanleitung

Dual

Dual DMCPA79BT Betriebsanleitung

Sound Associates

Sound Associates SA652P Bedienungsanleitung

Sherwood

Sherwood NewCastle R-772 Bedienungsanleitung

Audio

Audio A10-RX Series Bedienungsanleitung

AllSee

AllSee PushShare PSRV1.1 Bedienungsanleitung

DEMAG

DEMAG DRC-DR D2 Bedienungsanleitung

Teleco

Teleco TVRCL868A02 Bedienungsanleitung

Bosch

Bosch RF3222E Bedienungsanleitung

Kramer

Kramer 631R Bedienungsanleitung

Xpress

Xpress xmc10 Bedienungsanleitung

JVC

JVC KD-MR1BTS Bedienungsanleitung

Omega Engineering

Omega Engineering UWTC-REC3 Bedienungsanleitung

e-survey

e-survey E300 Pro Bedienungsanleitung
