Braeburn 5310 Montageanleitung

Detailed

Installer Guide

Programmable Touchscreen Thermostats

Speciﬁcations

Installation and Wiring

Quick Reference

Installer Settings

System Testing

To prevent damage to the thermostat, never use a sharp instrument

to press the touchscreen keys. Always press keys with your ﬁngers.

Attention

• Possible electric shock or damage to equipment can occur.

• Disconnect power before beginning installation.

Caution

This thermostat requires 24 Volt AC Power or 2 properly installed “AA” Alkaline

batteries for

proper operation. When connecting 24 Volt AC Power the batteries may

be installed as a backup.

For use only as described in this manual. Any other use will void warranty.

5310

Single Stage Heat / Cool Conventional

or Heat Pump

5320

Up to 4 Heat / 2 Cool Heat Pump

Up to 3 Heat / 2 Cool Conventional

Warning

For installation by experienced service technicians only.

Touchscreen

This thermostat is compatible with:

  • Singlestageheat/coolconventionalandheatpumpsystems

  • Conventionalsystemsupto3stagesofheatingand2stagesofcooling(5320only)

  • Heatpumpsystemsupto4stagesofheatingand2stagesofcooling(5320only)

  • 250–750millivoltheatingonlysystems

Electrical and control speciﬁcations:

  • ElectricalRating:24VoltAC

  • 1ampmaximumloadperterminal

  • ACPower:18–30VoltsAC

  • DCPower:3.0VoltDC(2“AA”AlkalineBatteriesIncluded)

  • ControlRange:45°–90°F(7°–32°C)

  • TemperatureAccuracy:+/-1°F(+/-.5°C)

  • OutdoorTemperatureDisplayRange:-40°-120°F(-40°-49°C)

Terminations

  • 5310:G,Rc,Rh,W1,O/B,Y1,C,S1,S2

  • 5320:A,G,Rc,Rh,W1/E/AUX1,W2/AUX2,W3/O/B,Y1,Y2,C,L,S1,S2

Speciﬁcations

5310W-100-02

Model number is located on back of thermostat.

Thermostat Location

Installthethermostatapproximately5feet(1.5m)abovetheoorinanareathathasagoodamountofair

circulationandmaintainsanaverageroomtemperature.

Avoidinstallationinlocationswherethethermostatcanbeaffectedbydrafts,deadairspots,hotorcoldair

ducts,sunlight,appliances,concealedpipes,chimneysandoutsidewalls.

Installer Guide 2

Install your new Braeburn thermostat in 4 basic steps:

1 InstalltheSub-Base

2 ProvidePower

3 ConnectYourWires

4 AttachThermostattoSub-Base

Install the Sub-Base:

•Removethesub-basefromthebodyofthethermostat.

•Mountthesub-baseasshownbelow:

Warning

Disconnect power before beginning installation.

Installation and Wiring

UP UP

Drill 3/16” pilot holes in your

desired location. Use supplied

anchors for drywall or plaster.

3 Installer Guide

Provide Power

24VAC Power Terminal (C)

Wiring Terminations for model 5310

Terminal Function Description

 G Output FanControl

 Rc Input 24VoltACCoolingTransformer

   (DualTransformerSystemsOnly)

 Rh Input PowerConnection(24VoltACHeating

   TransformerorMillivoltPowerSource)

 W1 Output ConventionalHeatRelay

 O/B Output ReversingValve(CoolActiveorHeatActive)

 Y1 Output CompressorRelay

 C Input 24VoltACTransformerCommon

 S1

 S2

Connect Your Wires

Input OptionalRemoteSensor(indoororoutdoor)

• For24VoltACpower,youmustconnectthecommonsideofthetransformertotheCterminalonthethermostatsub-base.In

 dualtransformerinstallations,thetransformercommonmustcomefromthecoolingtransformer.

• Forbatterypower,insertthe2supplied“AA”typealkalinebatteriesintothebatterycompartmentlocatedintherear

 housingofthethermostat.MakesuretopositionthePositive(+)andNegative(-)sidesofthebatteriescorrectlywith

 the+/-symbolsinthebatterycompartment.

Batteries Installed as Shown

Installer Guide 4

Wiring Terminations for model 5320

Terminal Function Description

 A Output EconomizerControl

  G Output FanControl

  Rc Input 24VoltACCoolingTransformer

    (DualTransformerSystemsOnly)

  Rh Input PowerConnection(24VoltACHeating  

    TransformerorMillivoltPowerSource)

 W1/E/ Output (W1)1stStageConventionalHeat,

 AUX1  (E)EmergencyHeat,    

(AUX1)1stStageAuxiliaryHeat

 W2/AUX2 Output (W2)2ndStageConventionalHeat,  

    (AUX2)2ndStageAuxHeat

 W3/O/B Output (W3)3rdStageConventionalHeat,  

    (O)CoolActiveReversingValve   

    (B)HeatActiveReversingValve

  Y1 Output 1stStageCompressor

  Y2 Output 2ndStageCompressor

  C Input 24VoltACTransformerCommon

  L Input SystemMalfunctionIndicator

  S1

  S2

Connecting Your Wires (continued)

Input OptionalRemoteSensor(indoororoutdoor)

5 Installer Guide

Heat Only or Millivolt

Set System Type to 11CONV

Rh PowerConnection

W1 HeatRelay

1 HEAT / 1 COOL Single or Dual Transformer

Set System Type to 11CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelay

Y1 CompressorRelay

G FanRelay

C 24VoltACTransformerCommon[note 1, 3] NOTES - Conventional Systems

[1]Optional24VoltACcommonconnection.

[2]Removefactoryinstalledjumperfordual

 transformersystems.Providedisconnectand

 overloadprotectionasrequired.

[3]Indualtransformersystems,transformer

 commonmustcomefromcoolingtransformer.

[4]ConnectY2onlyifasecondcoolingcompressor

 isbeingused.

Provide disconnect and overload protection as required.

3 HEAT / 2 COOL Single or Dual Transformer

Set System Type to 32CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelayStage1

W2 HeatRelayStage2

W3 HeatRelayStage3

Y1 CompressorRelayStage1

Y2 CompressorRelayStage2 [note 4]

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

2 HEAT / 2 COOL Single or Dual transformer

Set System Type to 22CONV

24VoltACPower(heatingtransformer)[note 2]

24VoltACPower(coolingtransformer)[note 2]

W1 HeatRelayStage1

W2 HeatRelayStage2

Y1 CompressorRelayStage1

Y2 CompressorRelayStage2 [note 4]

G FanRelay

C 24VoltACTransformerCommon[note 1, 3]

Typical Wiring Conﬁgurations

NOTE: The “System Type” option will be conﬁgured in the Installer Settings section. The 5310 is a single stage

thermostat and not intended for multi stage equipment.

Conventional Systems

NOTE: Additional options are conﬁgured in the

Installer Settings section.

A EconomizerControl(5320only)[note 2]

NOTES - Additional Wiring Options

[1]Theseterminalscanbeusedtoconnecta

 Braeburn

indoororoutdoorremotesensor.

[2]

Thisterminalcanbeusedforeconomizer

 control(5320).

Additional Wiring Options

IndoororOutdoorRemoteSensor[note 1]

Installer Guide 6

1 HEAT / 1 COOL - No Auxiliary Heat

Set System Type to 11HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B

ChangeoverValve [note 2]

Y1 CompressorRelay(appearsasYonthe5310)

G FanRelay

C 24VoltACTransformerCommon [note 1]

3 HEAT / 2 COOL – Including Auxiliary Heat

Set System Type to 32HP

Rh 24VoltACPower

ConnectedtoRhwithsuppliedJumperWire

O/B ChangeoverValve [note 2]

Compressor1Relay(1ststageheating/cooling)

Compressor2Relay(2ndstageheating/cooling)

AUX1

AuxiliaryHeatRelay(3rdstageheating)[note 5]

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

2 HEAT / 1 COOL - Including Auxiliary Heat

Set System Type to 22HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B

ChangeoverValve[note 2]

Y1 CompressorRelay(1ststageheating/cooling)

AuxiliaryHeatRelay(2ndstageheating)[note 3]

E EmergencyHeatRelay[note 3]

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

2 HEAT / 2 COOL - No Auxiliary Heat

Set System Type to 32HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B

ChangeoverValve[note 2]

Compressor1Relay(1ststageheating/cooling)

Compressor2Relay(2ndstageheating/cooling)

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

4 HEAT / 2 COOL - Including Auxiliary Heat

Set System Type to 42HP

Rh 24VoltACPower

Rc ConnectedtoRhwithsuppliedJumperWire

O/B ChangeoverValve[note 2]

Compressor1Relay(1ststageheating/cooling)

Compressor2Relay(2ndstageheating/cooling)

AUX1

AuxiliaryHeatRelay1(3rdstageheating)[note 5]

AUX2

AuxiliaryHeatRelay2Relay(4thstageheating)

G FanRelay

C 24VoltACTransformerCommon[note 1]

L OptionalSystemFaultMonitor[note 4]

NOTES - Heat Pump Systems

[1] Optional24VoltACcommonconnection.

[2] O(coolactive)orB(heatactive)isselectedin

 theInstallerSettingsmenu.

[3] Installaeldsuppliedjumperbetweenthe

 W2/AUX2andW1/E/AUX1terminalsifthereis

 noseparateemergencyheatrelayinstalled.

[4] IftheLterminalisused,the24VoltACcommon

 mustbeconnected(Cterminal).

[5] Ifaseparateemergencyheatrelayisinstalled,the

 W1/E/AUX1terminalshouldhaveboththeauxiliary

 heat1relayandemergencyheatrelayconnected.

Provide disconnect and overload protection as required.

Typical Wiring Conﬁgurations

NOTE: The “System Type” option will be conﬁgured in the Installer Settings section. The 5310 is a single

stage thermostat and not intended for multi stage equipment.

Heat Pump Systems

7 Installer Guide

NOTE: This thermostat ships conﬁgured as a 1H/1C conventional

thermostat. Conﬁrm installer settings. See page 10.

UP UP

W1/E

/AUX1

W2/

AUX2

W3/

O/B

W1/E

AUX

Attach Thermostat to Sub-Base

3) InsertQuickReferenceCardintoslot

 ontopofthermostat.

1) Lineupthethermostatbodywiththesub-base.

2) Carefullypushthethermostatbodyagainstthe

 sub-baseuntilitsnapsinplace.

NOTE: Additional options are conﬁgured in the

Installer Settings section.

A EconomizerControl(5320only)[note 2]

NOTES - Additional Wiring Options

[1]Theseterminalscanbeusedtoconnecta

 Braeburn

indoororoutdoorremotesensor.

[2]

Thisterminalcanbeusedforeconomizer

 control(5320).

Additional Wiring Options

IndoororOutdoorRemoteSensor[note 1]

Installer Guide 8

Room Temperature...................... Displaysthecurrentroomtemperature

Lock Mode Indicator ................... Indicatesifthethermostatislocked

Set Temperature.......................... Displaysthecurrentsetpointtemperature

Service Indicators ...................... Displaysvariousservice/maintenanceinformation

Time of Day ................................. Displaysthecurrenttimeofday

Program Event Indicator.............. Displaystheprogramevent

Day of the Week........................... Displaysthecurrentdayoftheweek

System Status Indicator ............. Displaysinformationaboutthestatusofthesystem

Hold Mode Indicator ................... IndicatesifthethermostatisinHOLDmode

Fan Indicator................................ Indicateswhenthesystemfanisrunning

Low Battery Indicator.................. Indicateswhenthebatteriesneedtobereplaced

Quick Reference Instructions...... Storedinslotlocatedattopofthermostat

SpeedBar®................................... Increasesordecreasessettings(time,temperature,etc.)

Reset Button ............................... Resetscurrenttime,programandusersettings

Installer Clear Button .................. Locatedonbackofthermostatbody–clearsallsettings

Battery Compartment ................. Locatedinthebackofthermostat

Quick Reference

Thermostat Display

Thermostat

9 Installer Guide

Thermostat TouchPadsTM

NOTE: Thermostat TouchPads are located on the left, right and bottom portions of the display screen. They are

the “touch sensitive” segments used to adjust your thermostat. Depending on the equipment installed, all touch

pads may not show.

SYSTEM......SelectsAUTO(Heat/Cool),COOL,OFFHEATorEMER(EmergencyHeat)

FAN.............SelectsAUTO,ON,CIRC(Circulation)andPROG(Program)fanmodes

PROG..........Selectsprogrammingmodeorpressfor3secondstoselectSpeedSetTMmode

HOLD..........Enters/ExitstheHOLDmode(programbypass)

DAY/TIME...Setsthecurrenttimeanddayoftheweek

BACK..........Movesbackinsettingandprogrammingmodes

NEXT...........Movesforwardinsettingandprogrammingmodes

RETURN......Returnstonormalmodefromprogramorsettingsmodes

CONFIG.......EnterstheUserandInstallersettingsmodes

CLEAN........Entersabriefscreencleaningmode

Outdoor Temperature

IfaBraeburn®outdoortemperaturesensorwasconnected,youmaytouchtheroomtemperatureareaofthe

screentoviewtheoutdoortemperature.

TheInstallerSettingsmustbeproperlyconguredinorderforthisthermostattooperatecorrectly.TheInstaller

Settingsaremenudriven.Theportionofthesesettingsthatdonotapplytoyoursetupwillbeskipped.These

settingsareindicatedbelowwithcomments.Moredetailoneachsettingfollowsthistable.

Installer Guide 10

1. TouchandholddowntheSYSTEMandCONFIGTouchPads™for3seconds.

2. Releasebothbuttonsandtherstinstallersettingwillbedisplayed.

3. ChangesettingsasrequiredusingtheUPorDOWNportionoftheSpeedBar®.

4. TouchNEXTorBACKtomovetothenextorprevioussetting,touchRETURNtoexit.

NOTE: Shaded areas below do not apply to the 5310.

No. Installer Setting Factory Setting Comments

(Notes follow this table) Default Options (More information follows this table)

1  Residentialor RES RES SelectforResidentialprole

  orCommercialProle    COMM SelectforCommercialprole

2  ProgrammingMode 7 PROG 7 PROG Selectfor7dayprogrammingmode

[note 1] 52 PROG Selectfor5-2dayprogrammingmode

NO PROG Selectfornon-programmablemode

3  ClockFormat 12 HR 12 HR Selectfor12hourclock

24 HR Selectfor24hourclock

4  TemperatureScale F DEG F DEG SelectforFahrenheitdisplay

C DEG SelectforCelsiusdisplay

5  AutoChangeover oF AUTO oF AUTO DisablesAutoChangeovermode

ON AUTO EnablesAutoChangeovermode

11CONV Selectfor1H/1CConventionalsystem

22CONV Selectfor2H/2CConventionalsystem

32CONV Selectfor3H/2CConventionalsystem

6  SystemType 11CONV 11HP Selectfor1H/1CHeatPumpsystem

22HP Selectfor2H/2CHeatPumpsystem

32HP Selectfor3H/2CHeatPumpsystem

42HP Selectfor4H/2CHeatPumpsystem

7  1stStageDifferential 0.5 DIF1 0.5, 1.0or Selecta1ststagetemperaturedifferentialof.5°,

2.0 DIF1 1°or2°F(.25°,.5°or2°C)

8  2ndStageDifferential 2.0 DIF2 1.0, 2.0, 3.0, Selecta2ndstagetemperaturedifferentialof1°,

[note 2] 4.0, 5.0or 2°,3°,4°,5°or6°F(.5°,1°,1.5°,2°,2.5°or3°C)

6.0 DIF2

9  3rdStageDifferential 2.0 DIF3 1.0, 2.0, 3.0, Selecta3rdstagetemperaturedifferentialof1°,2°,

[note 2] 4.0, 5.0or 3°,4°,5°or6°F(.5°,1°,1.5°,2°,2.5°or3°C)

6.0 DIF3

10 4thStageDifferential 2.0 DIF4 1.0, 2.0, 3.0,

Selecta4thstagetemperaturedifferentialof1˚,

[note 2] 4.0, 5.0or 2°,3°,4°,5°or6°F(.5°,1°,1.5°,2°,2.5°or3°C)

6.0 DIF4

Installer Settings

Andere Handbücher für 5310

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Braeburn Thermostat Handbücher

Braeburn

Braeburn 2020 Bedienungs- und Wartungshandbuch

Braeburn

Braeburn 3020 Bedienungs- und Wartungshandbuch

Braeburn

Braeburn 7300 Bedienungsanleitung

Braeburn

Braeburn 2220 Bedienungsanleitung

Braeburn

Braeburn BlueLink 7205 Bedienungsanleitung

Braeburn

Braeburn 3100 Bedienungsanleitung

Braeburn

Braeburn Premier Series Bedienungsanleitung

Braeburn

Braeburn 7320 Montageanleitung

Braeburn

Braeburn Premier 5000 Bedienungsanleitung

Braeburn

Braeburn Premier Series Montageanleitung

Braeburn

Braeburn Premier 5050 Bedienungsanleitung

Braeburn

Braeburn 3200 Bedienungsanleitung

Braeburn

Braeburn Premier Series Bedienungsanleitung

Braeburn

Braeburn Economy Series Bedienungsanleitung

Braeburn

Braeburn 3020 Gebrauchsanweisung

Braeburn

Braeburn 5020 Benutzerhandbuch

Braeburn

Braeburn 3000 Bedienungsanleitung

Braeburn

Braeburn Premier Series Gebrauchsanweisung

Braeburn

Braeburn Premier 5300 Bedienungsanleitung

Braeburn

Braeburn 1200 Bedienungsanleitung

Braeburn

Braeburn 1020 Gebrauchsanweisung

Braeburn

Braeburn 5200 Bedienungsanleitung

Braeburn

Braeburn 1100 Builder Series Bedienungsanleitung

Braeburn

Braeburn Premier 5100 Bedienungsanleitung

Beliebte Thermostat Handbücher anderer Marken

EWELLY

EWELLY EW-181 Bedienungsanleitung

Prolon

Prolon T1100 Montageanleitung

Computherm

Computherm Q20 Bedienungsanleitung

Heatmiser

Heatmiser neoStat Bedienungsanleitung

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Bedienungsanleitung

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Bedienungsanleitung

Saswell

Saswell SAS920XWHB-7-S-RF Leitfaden

Aircalo

Aircalo TFP1-ET85P2 Bedienungsanleitung

Honeywell

Honeywell CM721 Bedienungsanleitung

Carrier

Carrier DEBONAIR 33CS Bedienungsanleitung

Lennox

Lennox iHarmony Zone Thermostat Montageanleitung

Gemtech

Gemtech GT7000 Bedienungsanleitung

Rollei

Rollei Smartes 45000 Bedienungsanleitung

Sinope

Sinope TH1300RF Bedienungsanleitung

Honeywell

Honeywell RLV4305 Bedienungsanleitung

Honeywell

Honeywell Prestige 2.0 THX9421 Bedienungsanleitung

NuTone

NuTone NTBZ48 Original Betriebsanleitung

Stelpro

Stelpro MAESTRO ASMT402AD Bedienungsanleitung
