EN GUIDE TO INSTALLATION AND USE
Washing Machine
1
CONTENTS
Safety instructions ........................................................................................ 2
Installation..................................................................................................... 5
Operation .................................................................................................... 12
Maintenance operations ............................................................................. 23
Troubleshooting .......................................................................................... 27
Availability of spare parts............................................................................ 29
2
Safety instructions
This appliance is designed to be used for domestic and
similar applications such as:
-
kitchen areas for staff in shops, offices and other
professional premises,
-
farms,
-
use by hotel, motel and other residential clients,
-
B&B type environments.
The appliance must be connected to the mains water
supply using the brand new connection fittings supplied
with the appliance. Never reuse old fittings.
Never obstruct the ventilation openings.
This appliance may be used by children aged 8years or
over and by individuals with reduced physical, sensual or
metal capacity or lack of experience or knowledge of the
device provided that they are correctly supervised or have
been provided with instructions regarding the safe use of
the appliance and provided that the risks present have
been fully understood. Children must not be allowed to
play with the appliance. Cleaning and maintenance
operations must not be carried out by children without
supervision.
Children under the age of three should be kept away from
the appliance unless they are under constant supervision.
If the power cord is damaged, it should be replaced by the
manufacturer, its after-sales service department or a
similarly qualified person, so as to avoid danger.
Regarding the instructions for installing the appliance and
making its electrical connections, please refer to the
appropriate section in this guide.
WARNING: Do not connect the appliance to hot water.
The maximum weight of dry laundry is 7kilograms.
Maximum water supply pressure: 1 MPa
Minimum water supply pressure: 0.1MPa
3
Warning!
Productinstallation
This washing machine is intended for indoor use only.
It is not designed for built-in installation.
Never obstruct the openings.
This washing machine must not be installed in bathrooms,
very damp rooms or in rooms where there are explosive
gasses or caustic substances. If the washing machine has
only one water inlet valve, connect it to a cold water source
only.
The power plug must remain accessible after the
appliance is installed.
Remove all packaging materials and the transit bolts
before using the appliance. Failure to do so may seriously
damage your washing machine.
Appliancedamagehazard!
Your appliance is for household (domestic) use only and is
designed solely for machine washable textiles.
Do not climb on the top of the washing machine. Care
when handling the washing machine:
Care when handling the washing machine:
1. The transit bolts must be refitted to the washing
machine by a qualified person.
2. Drain any water from the appliance before moving
the washing machine.
3. Handle the appliance with care. Never lift the
appliance by grabbing projecting parts. The door
must not be used as a handle when moving the
appliance.
4. This appliance is heavy. Carry it with care.
Do not close the door using excessive force. If the
door is hard to close, make sure that the drum is not
overloaded and that the laundry is properly
4
distributed.
Operationoftheappliance
Before using the appliance for the first time, perform a
complete wash cycle empty.
Use of inflammable and explosive solvents is prohibited.
Never use fuel and alcohol, etc. as detergents. Only
choose detergents that are suitable for machine washing.
Empty the pockets of your clothes. Cutting and rigid
objects like coins, pins, nails, screws, stones, etc. may
seriously damage this appliance.
Be careful to avoid injury when draining very hot washing
water.
Never add water by hand during washing.
Once the washing cycle has finished, wait two minutes
before opening the door.
5
Installation
Descriptionoftheproduct
Note!
The illustration of the accessories is provided for reference
purposes only. Please refer to the actual product.
Door
Detergent compartment
Drum
Filter
Power cord
Control panel
Drain hose
6
Accessories
Transit bolt
hole covers
Cold water
supply hose
Drain hose
holder
User guide
Installationlocation
Warning!
It is important that the product is stabilised to prevent it
from moving!
Ensure that the appliance is not resting on the power cord.
To install your washing machine, choose a location
that is:
1. On a hard, dry, flat surface
2. Not exposed to direct sunlight
3. Adequately ventilated
4. In a room at ambient temperature
5. Away from heat sources
The washing machine is designed to operate at
ambient temperature. If it is used in a room where
the temperature is below 0°C, the water inlet valve
and the drainage system may be damaged.
7
Unpackingthewashingmachine
Warning!
Packaging materials (e.g. plastic film, polystyrene) can be
hazardous to children.
There is a suffocation hazard! Keep all packaging materials
away from children.
1. Remove the cardboard box and the
polystyrene wrapping.
2. Lift the washing machine and
remove the packaging under it.
Don't forget to remove the small
foam triangle at the same time as
the lower packaging.
If you cannot do so, lay the washing
machine on its side and remove the
small foam triangle by hand.
3. Remove the adhesive tape that holds the power cord and
the drain hose in place.
4. Remove the water supply hose from the drum.
8
Fit the acoustic foam (optional)
Note!
Fitting acoustic foam helps to reduce noise when the
washing machine is in use.
1. Place your washing machine on one of its sides, making
sure you protect the floor.
2. Affix the foam as shown on the diagram, using the correct
dimensions.
Removethetransitbolts
Warning!
You need to remove all the transit bolts located at the back
of the washing machine before using it.
You'll need the transit bolts again if you move the washing
machine. Keep them in a safe place.
9
Proceed as follows to remove the transit bolts:
1. Use a spanner to loosen the four
transit bolts then pull them out.
2. Push the four transit bolt cover
caps provided for this purpose into
the holes.
3. Keep the transit bolts in a safe
place for future reuse.
Adjustingthelevellingfeet
Warning!
The lock nuts on the four levelling feet must be tightened against the body
of the washing machine.
1. Check that the feet are still firmly attached to the washing
machine. If this is not the case, return them to their original
position and tighten the nuts.
2. Slacken the lock nut and turn the foot until it touches the
floor.
3. Adjust the feet and lock them into position using a spanner.
Check that the washing machine is stable.
