Braun 83XXcc Bedienungsanleitung

www.braun.com

Type 5795

Modèle 5795

Modelo 5795

83XXs

83XXcc

Series 8

91818850/III-18

91818850_83XXcc&s_W&D_NA_Type_5795.indd 191818850_83XXcc&s_W&D_NA_Type_5795.indd 1 07.05.18 14:3507.05.18 14:35

Stapled booklet, 120 x 170 mm, 48 pages (incl. 8 pages cover), 2/2c = PMS485c + black

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 1 of 48

English 6

Français 21

Español 35

EN/FR/ES

Braun Infolines

Lignes d’assistance Braun

Líneas de información de Braun

Thank you for purchasing a Braun product.

We hope you are completely satisfied with

your new Braun product.

If you have any questions, please visit

www.service.braun.com or call:

US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun.

Nous espérons que vous serez entièrement

satisfait de votre nouveau produit Braun.

Si vous avez des questions, veuillez visiter le

www.service.braun.com ou appeler

Braun Canada : 1-800-387-6657

Gracias por haber comprado un producto Braun.

Esperamos que quede completamente

satisfecho con su nuevo producto Braun.

91818850_83XXcc&s_W&D_NA_Type_5795.indd 291818850_83XXcc&s_W&D_NA_Type_5795.indd 2 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 2 of 48

wet&dry

5c 5d

5a 5f

5b 5e*

5g*

10a*

5e*

5g*

15a 15b 15c*

wet&dry

Series 8

wet&dry

Series 8

91818850_83XXcc&s_W&D_NA_Type_5795.indd 391818850_83XXcc&s_W&D_NA_Type_5795.indd 3 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 3 of 48

20°

10°

0° 10°

20°

10°

0° 10° 20°

90°

91818850_83XXcc&s_W&D_NA_Type_5795.indd 491818850_83XXcc&s_W&D_NA_Type_5795.indd 4 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 4 of 48

91818850_83XXcc&s_W&D_NA_Type_5795.indd 591818850_83XXcc&s_W&D_NA_Type_5795.indd 5 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 5 of 48

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should always be

followed, including the following:

Read all instructions before using this appliance.

When disconnected, the hand-held part of this shaving appliance

may be used in a bath or shower. For safety reasons, the

appliance can only be operated cordless.

DANGER

To reduce the risk of electric shock:

1. The charger unit is not for immersion in water or for use in shower.

2. Do not reach for a charger that has fallen into water. Unplug

immediately.

3. Do not place, store or charge the appliance where it can fall or be

pulled into a tub or sink. Do not place in or drop into water or other

liquid.

4. Except when charging, always unplug this appliance from the

electrical outlet immediately after using.

5. This appliance is provided with a special cord set with integrated

Safety Extra Low Voltage power supply. Do not exchange or

manipulate any part of it.

6. Do not use an extension cord with this appliance.

7. Unplug this appliance before cleaning.

English

91818850_83XXcc&s_W&D_NA_Type_5795.indd 691818850_83XXcc&s_W&D_NA_Type_5795.indd 6 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 6 of 48

WARNING

To reduce the risk of burns, fire, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by, on, or

near children or persons with disabilities.

2. Use this appliance only for its intended use as described in this

manual. Do not use attachments not recommended by the

manufacturer.

3. Never operate this appliance if it has a damaged cord or plug, if it is

not working properly, if it has been dropped or damaged, or if the

power supply has been dropped into water. Return the appliance to a

service center for examination and repair.

4. Keep the cord away from heated surfaces.

5. Never drop or insert any object into any opening of the appliance.

6. Do not use outdoors or operate where aerosol (spray) products are

being used or where oxygen is being administered.

7. Do not use this appliance with a damaged or broken foil, as serious

skin injuries may occur.

8. Always attach plug to appliance first, then to outlet. To disconnect,

turn all controls off, then remove plug from outlet.

9. When plugging to an electrical outlet outside North America, use a

plug adapter to match the outlet’s pin configuration.

10. Caution: The battery used in this device may present a fire or

chemical burn hazard if mistreated. Do not disassemble, heat above

100 °C (212 °F), or incinerate.

11. To recharge the battery, only use the detachable power supply

provided with this appliance. If the appliance is marked

492-XXXX, only use Braun power supplies coded 492-XXXX.

SAVE THESE INSTRUCTIONS

91818850_83XXcc&s_W&D_NA_Type_5795.indd 791818850_83XXcc&s_W&D_NA_Type_5795.indd 7 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 7 of 48

Our products are designed to meet the highest standards of quality, functionality and

design. Thank you for your trust in Braun’s quality, and we hope you enjoy your new

Braun shaver.

Important

Do not open the appliance! Only at the end of the product’s useful life, disassemble the

rechargeable battery for disposal reasons as shown in the battery removal section.

This product is for household use only.

Shaver

1 Foil & Cutter cassette

2 Cassette release button

3 Multi Head Lock switch

4 On / off button

5 Shaver display**

5a Travel lock

5b Replacement indicator for Foil & Cutter cassette

5c Status segments

5d Minutes left display

5e Cleaning indicator*

5f Plug reminder

5g Battery icon*

6 Precision trimmer

7 Shaver-to-station contacts

8 Release button for precision trimmer

9 Shaver power socket

10 Power supply**

10a Charging stand*/**

11 Travel case

* not with all models (see display box)

** design can differ

For electric specifications, see printing on the power supply.

Basic operating information

• A full charge takes 1 hour and provides up to 60 minutes of cordless shaving time.

This may vary depending on your beard growth and ambient temperature.

• Recommended ambient temperature for charging is 41 °F to 95 °F / 5 °C to 35 °C. The

battery may not charge properly or at all under extreme low or high temperatures.

• Recommended ambient temperature for shaving is 60 °F to 95 °F / 15 °C to 35 °C.

• Do not expose the shaver to temperatures higher than 122 °F / 50 °C for extended

periods of time.

• When the shaver is connected to an electrical outlet, it may take some minutes until

the display illuminates.

91818850_83XXcc&s_W&D_NA_Type_5795.indd 891818850_83XXcc&s_W&D_NA_Type_5795.indd 8 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 8 of 48

Charging

• Connect the shaver to an electrical outlet by snapping the power supply (10) into the

power socket of the shaver (9) or the charging stand (10a). For cc models plug into

the station power socket (see chapter «Clean & Charge Station»).

• For first-time charge, charge continuously for at least 1 hour.

• The actual charge status is shown on the display.

Display

• The display information is dependent on the model.

• Some models only show icons during charging or operation. On other models a series

of icons is also shown after the shaver has been turned off.

• The table below shows the icons that can appear on the shaver display.

Battery status

The battery status is shown with segments and additionally

in digits (for some models also with a battery icon).

• The status segments appear / disappear gradually with the

status of the battery power.

• The digital number shows the remaining shaving time in

minutes.

Plug reminder (low charge / cordless operation only)

1. Flashing: Battery is in low charge, i.e. 5 minutes shaving

time are left.

2. Fast flashing: This appliance can only be operated

cordless. Disconnect the shaver from the power supply

before turning it on.

Travel lock

When the travel lock icon appears on the display, the shaver is

locked.

Replacement indicator for Foil & Cutter cassette

The replacement indicator shows the usage of the

Foil & Cutter cassette. The status segments disappear

gradually with the numbers of shaves.

91818850_83XXcc&s_W&D_NA_Type_5795.indd 991818850_83XXcc&s_W&D_NA_Type_5795.indd 9 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 9 of 48

Cleaning indicator (with Clean & Charge station usage only)

The cleaning indicator lights up after

each shave as a reminder that the shaver

should be cleaned in the Clean & Charge

Station.

Usage

Make sure that the shaver is disconnected from the power supply. Press the on / off

button (4) to operate the shaver.

Tips for a perfect shave

1. Position the shaver at the right angle (90°) to your skin.

2. Stretch your skin slightly with your hand.

3. Shave against the direction of your beard growth.

MultiHeadLock switch (head lock)

The shaver head can be locked in five positions to shave hard-to-reach areas

(e.g. under the nose).

• Slide the Multi Head Lock switch (3) down to lock the shaver head.

• Move the shaver head manually to your desired position.

• For automatic cleaning in the Clean & Charge Station the head lock needs to be

released.

Precision trimmer

The trimmer can be used to trim sideburns, moustache or beard.

• Press the release button (8) and slide the trimmer (6) upwards.

Travel lock

The shaver can be locked to avoid unintended starting of the motor (e.g. for storing in a

suitcase).

• Press the on / off button (4) for 3 seconds to lock / unlock the shaver. This is

confirmed by a beep sound and the lock icon appearing / disappearing on the

display.

Foil replacement

To maintain 100% shaving performance, replace the Foil & Cutter cassette (1), when

the foil replacement indicator lights up and no status segments are visible.

• To remove the Foil & Cutter cassette press the release button (2).

• Press the on / off button for 8 seconds to reset the counter.

• Afterwards you need to unlock the shaver (see chapter «Travel lock»).

• On some shaver models the replacement indicator will reset automatically after

7 shaves.

91818850_83XXcc&s_W&D_NA_Type_5795.indd 1091818850_83XXcc&s_W&D_NA_Type_5795.indd 10 07.05.18 14:3507.05.18 14:35

Business Use - P&G AUTHORIZED POA-00044124 Rev 001 Effective Date 2018-05-09 Printed 2018-07-25 Page 10 of 48
