FACSIMILE EQUIPMENT

PARTS REFERENCE LIST

MODEL: MFC9760 / MFC9860 / MFC9880

(For Germany / United Kingdom / France /

Norway / Belgium / Netherlands /

Switzerland / Ireland / Denmark /

Austria / Spain / Italy / Sweden /

Euro Generic )

( For Australia / New Zealand / Asia )

No part of this publication may be reproduced in any form

or by any means without permission in writing from the

publisher.

Specifications are subject to change without prior notice.

NOTES FOR USING THIS PARTS REFERENCE LIST

1. In the case of ordering parts, it needs mentioning the following items:

(1) Code

(2) Q' ty

(3) Description

Note: No orders without Parts Code or Tool No. can be accepted.

[Example] (1) (2) (3)

REF.NO. CODE Q' TY DESCRIPTION

RECOMMEND

REMARKS

2. Parts change will be informed by the technical information.

COUNTRIES

GERMANY ---- GER

UNITED KINGDOM ---- UK

FRANCE ---- FRA

NORWAY ---- NOR

BELGIUM ---- BEL

NETHERLANDS ---- NLD

SWITZERLAND ---- CHE

IRELAND ---- IRE

DENMARK ---- DEN

AUSTRIA ---- AUS

SPAIN ---- SPA

ITALY ---- ITA

SWEDEN ---- SWE

EURO GENERIC ---- GNR

AUSTRALIA ---- ARL

NEW ZEALAND ---- NZ

ASIA ---- ASA

LIST1(MAIN FRAME)

REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER

TO BIUK

1 LE1744001 1 MAIN MOTOR ASSY

2 087320616 4 TAPTITE, CUP S M3X6

3 LJ5701001 1 SOLENOID ASSY

4 000300415 1 SCREW, BIND M3X4

5 UL8984001 1 FRONT COVER LIN

6 LJ5704001 1 TONER SENSOR

(

LED

)

PCB

7 087320616 6 TAPTITE, CUP S M3X6

8 LE1166001 1 THERMISTOR FILM

9 LG2423001 1 IN CASING TEMPERATURE THERMISTOR

10 LJ4745001 1 FAN

11 UL9104001 1 TONER SENSOR

(

RECEIVER

)

PCB

12 LG2438001 1 PAPER EJECTION SENSOR PCB

13 087320616 21 TAPTITE, CUP S M3X6

14 LJ7403001 4 RUBBER FOOT

15 LJ8031001 1 2ND CASSETTE RELAY PCB

16 085411215 5 SCREW, BIND B TITE M4X12

17 LJ5703001 1 SOLENOID RELEASE SPRING

18 UL8972001 1 P/R CLUTCH LEVER

19 UL8971001 1 F/R CLUTCH LEVER

20 UL8982001 1 DEVELOP JOINT

21 UL8983001 1 JOINT SPRING

22 UL8959001 1 FRICTION SPRING

MFC9760, MFC9860, MFC9880

LIST2(LASER UNIT)

REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER

TO BIUK

1 LJ5828001 1 LASER UNIT

(

)

2 087321615 3 TAPTITE, CUP S M3X16

MFC9760, MFC9860, MFC9880

LIST3(PAPER TRANSPORT)

REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARK ORDER

TO BIUK

1 UL9059001 1 JOINT

2 UL9060001 1 PAPER FEED ROLLER ASSY

3 UL9062001 1 PAWLED BUSHING

4 UL9066001 1 PAPER PICK-UP ROLLER

5 UL9062001 1 PAWLED BUSHING

6 UL9069001 1 CONDUCTOR BUSHING

7 LJ4499001 1 ELECTRODE SPRING

8 LJ4843001 1 OUTER CHUTE 1

(

)

9 LJ5591001 1 PICKUP ROLLER PLANETARY GEAR ASSY (SP)

10 UL9070001 1 GEAR 21

11 UL8985001 1 GEAR 59

12 LJ5705001 1 GEAR 21 PRESSURE PLATE

13 LJ5838001 1 FEED ROLLER PLANETARY GEAR ASSY (SP)

14 UL9049001 1 MANUAL INSERTION SENSOR ACTUATOR

15 UL9050001 1 REGISTRATION SENSOR ACTUATOR

16 UL9051001 1 REGISTRATION SENSOR SPRING

17 UU2042001 1 CASSETTE SENSOR ACTUATOR

18 UL9053001 2 TRANSFER ARM ADD

19 UL9052001 2 TRANSFER SPRING ADD

MFC9760, MFC9860, MFC9880
