Type 6213 EV, 6281 EV

2/2-way solenoid valve

2/2-Wege-Magnetventil

Électrovanne 2/2 voies

1 OPERATING INSTRUCTIONS

The operating instructions contain important information.

▶Read the operating instructions carefully and follow the safety instruc-

tions in particular, and also observe the operating conditions.

▶Operating instructions must be available to each user.

▶The liability and warranty for the device are void if the operating instruc-

tions are not followed.

1.1 Symbols

▶designates an instruction to prevent risks.

→designates a procedure which you must carry out.

Warning of injuries:

DANGER!

Imminent danger. Serious or fatal injuries.

WARNING!

Potential danger. Serious or fatal injuries.

CAUTION!

Danger. Minor or moderately severe injuries.

Warns of damage to property:

NOTE!

2 INTENDED USE

Incorrect use of the solenoid valve can be dangerous to people,

nearby equipment and the environment.

▶The device type 6213 EV / 6281 EV is designed to control, shut off

and meter neutral media up to a viscosity of 21 mm2/s.

▶Provided the cable plug is connected and installed correctly, e.g.

Bürkert Type 2508, the device satisfies protection class IP65 in

accordance with DIN EN 60529 / IEC 60529.

▶Use according to the permitted data, operating conditions and con-

ditions of use specified in the contract documents and operating

instructions.

▶In the case of explosion-proof devices (see rating plate or additional

plate) also follow the operating instructions for the coil / pilot control.

▶Correct transportation, correct storage and installation and careful use

and maintenance are essential for reliable and problem-free operation.

▶Use the device only as intended.

2.1 Definition of term

In these operating instructions, the term “device” always refers to the

Type 6213 EV / 6281 EV.

english

Risk of injury due to malfunction of valves with alternating

current (AC).

Sticking core causes coil to overheat, resulting in a malfunction.

▶Monitor process to ensure function is in perfect working order.

Risk of short-circuit/escape of media through leaking screw

joints.

▶Ensure seals are seated correctly.

▶Carefully screw valve and pipelines together.

To prevent injury, ensure that:

▶Do not make any external modifications to the housing of the

device. Ensure that the system cannot be activated unintentionally.

▶Installation and repair work may be carried out by authorized techni-

cians only and with the appropriate tools.

▶After an interruption in the power supply or fluidic supply, ensure

that the process is restarted in a defined or controlled manner.

▶Do not put any loads on the body.

▶The general rules of technology apply to application planning and

operation of the device.

3 BASIC SAFETY INSTRUCTIONS

These safety instructions do not make allowance for any

• contingencies and events which may arise during the installation,

operation and maintenance of the devices.

• local safety regulations - the operator is responsible for observing

these regulations, also with reference to the installation personnel.

Danger - high pressure.

▶Before loosening the pipes and valves, turn off the pressure and

vent the pipes.

Risk of electric shock.

▶Before reaching into the device or the equipment, switch off the

power supply and secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

Risk of burns/risk of fire if used for a prolonged switch-on time

through hot device surface.

▶Keep the device away from highly flammable substances and media

and do not touch with bare hands.

english

3.1 Warranty

The warranty is only valid if the device is used as intended in accordance

with the specified application conditions.

3.2 Information on the internet

The operating instructions and data sheets for type 6213 EV / 6281 EV

can be found on the internet at:

www.buerkert.com Type “6213” or “6281”

4 TECHNICAL DATA

4.1 Operating conditions

The following values are indicated on the type label:

• Voltage (Tolerance ± 10 %) / Current type

• Coil power consumption

(active power in W - at operating temperature)

• Operating pressure

• Body material: Brass (MS), Stainless steel (VA)

• Seal material: FKM, EPDM, NBR

Circuit function:

A (NC)

2 (A)

1 (P)

2/2-way valve, normally

closed

A (NC)

2 (A)

1 (P)

2/2-way valve, normally

closed,

with manual override

B (NO)

2 (B)

1 (P)

2/2-way valve, normally

open

english

Protection class: IP65 with accordance with DIN EN 60529 / IEC

60529 with cable plug, e. g. Bürkert Type 2508

4.2 Application conditions

Ambient temperature: max. +55 °C

Operating duration: Unless otherwise indicated on the type label,

the solenoid system is suitable for con-

tinuous operation

Important information for functional reliability during continuous

operation.

If standstill for a long period at least 1-2 activations per day are

recommended.

Service life: High switching frequency and high pressures

reduce the service life

Permitted medium temperature depending on coil and seal material:

Coil body

PA/EP1)

Seal material Medium temperature

Polyamide PA FKM 0...+90 °C

Epoxy EP (NA38) FKM 0...+120 °C

Polyamide PA EPDM -30...+90 °C

Epoxy EP (NA38) EPDM -30...+100 °C

Polyamide PA NBR -10...+80 °C

1) Marking PA and EP under electric connection

Permitted media depending on seal material:

Seal material Permitted media 2)

FKM Per-solutions, hot oils without additives, diesel

and heating oil without additives, detergent

solution

EPDM Oil and grease-free liquids, cold and warm

water

NBR Cold and warm water

Gaseous media at low differential pressures (e.g. compressed air and vacuum)

can also be actuated in consideration (or due to restriction) of a lower tightness.

We recommend prior clarification with our sales office regarding the possible

application

english

The following values must also be observed for valves with

UL/UR approval:

Temperatures non-hazardous

fluids (air, water and inert gas)

-30...+120 °C

-30...+100 °C

(for 6213 EV DN40)

Ambient Temperature -30...+55 °C

4.3 Conformity

In accordance with the EC Declaration of conformity, the solenoid

valve Type 6213 EV / 6281 EV is compliant with the EC Directives

(if applicable).

4.4 Standards

The applied standards, which verify conformity with the EC Directives,

can be found on the EC Type Examination Certificate and / or the EC

Declaration of Conformity (if applicable).

4.5 Type label (Example)

Type

Circuit function

Orifice Seal material

Body material

Identification number Manufacturer code

Voltage, Frequency,

Power consumption

Connection thread,

operating pressure

6213EV A 10 EPDM MS

Made in Germany

00221649

W14 LU

230V 50Hz 8W

G3/8 P

10bar

english

5 INSTALLATION

5.1 Safety instructions

DANGER!

Risk of injury from high pressure in the equipment.

▶Before loosening the pipes and valves, turn off the pressure and

vent the pipes.

Risk of injury due to electrical shock.

▶Before reaching into the system, switch off the power supply and

secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

WARNING!

Risk of injury from improper installation.

▶Installation may be carried out by authorized technicians only and

with the appropriate tools.

Risk of injury from unintentional activation of the system and an

uncontrolled restart.

▶Secure system from unintentional activation.

▶Following installation, ensure a controlled restart.

5.2 Before installation

Installation position: any, actuator preferably upwards.

Procedure:

→Check pipelines for dirt and clean.

→Install a dirt filter before the valve inlet (≤ 500 µm).

5.3 Installation

NOTE!

Caution risk of breakage.

▶Do not use the coil as a lifting arm.

→Hold the device with a open-end wrench on the body and screw

into the pipeline.

→Observe direction of flow:

The arrow on the body indicates the direction of flow.

english

5.4 Manual override (optional Type 6281,

Code HA 17)

To control the valve manually, the hand lever under the coil must be turned

into the vertical position.

NOTE!

Caution.

▶Do not overturn hand lever.

▶When the hand lever is actuated, the valve can no longer be switched

electrically.

Opened position

Closed position

Hand lever

5.5 Electrical connection of the cable plug

WARNING!

Risk of injury due to electrical shock.

▶Before reaching into the system, switch off the power supply and

secure to prevent reactivation.

▶Observe applicable accident prevention and safety regulations for

electrical equipment.

If the protective conductor contact between the coil and body is

missing, there is danger of electrical shock.

▶Always connect protective conductor.

▶Check electrical continuity between coil and body.

Procedure:

→Tighten cable plug (for permitted types see data sheet), observing

max. torque 1 Nm.

→Check that seal is fitted correctly.

→Connect protective conductor and check electrical continuity between

coil and body.

english

Note the voltage and current type as specified on the type label.

Authorized cable plug e.g. Type 2508

or other suitable cable plug in accor-

dance with DIN EN 175301-803

Form A

Seal

max. 1 Nm

Pulse version (optional, Code CF 16):

• Valve opens when current pulse min. 50 ms:

– on Pin 1, + on Pin 2

• Valve closes when current pulse min. 50 ms:

+ on Pin 1, – on Pin 2

6 MAINTENANCE, TROUBLESHOOTING

6.1 Safety instructions

WARNING!

Risk of injury from improper maintenance.

▶Maintenance may be carried out by authorized technicians only and

with the appropriate tools.

Risk of injury from unintentional activation of the system and an

uncontrolled restart.

▶Secure system from unintentional activation.

▶Following maintenance, ensure a controlled restart.

6.2 Installation of the coil

WARNING!

Electric shock.

▶Before reaching into the system, switch off the power supply and

secure to prevent reactivation.

▶During installation ensure that the coil is situated firmly on the body

cover so that the protective conductor connection of the coil is con-

nected to the valve body.

▶Check protective conductor contact after installing the coil.

english

Escaping medium.

When a sticking nut is loosened, medium may escape.

▶Do not tighten sticking nut any further.

Overheating, risk of fire.

Connection of the coil without pre-assembled valve will result in

overheating and destroy the coil.

▶Connect the coil with pre-assembled valve only.

Procedure:

→Connect coil body to the core guide pipe.

→Screw on coil with nut. Observe torque.

NOTE!

Device will be damaged if the wrong tools are used.

Always use a wrench to tighten nut. If other tools are used (e.g. pliers),

the device may be damaged.

→Check protective conductor.

Observe

torque for

fastening nut

(See table) !

Nut

O-ring

Core guide pipe

Locking pin

Torque for fastening nut:

Coil type Coil width Torque

AC10 32 mm resp. 40 mm 5 Nm

AC19 42 mm 10 Nm

english

Andere Handbücher für 6213 EV

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Burkert Steuereinheit Handbücher

Burkert

Burkert 6013 Bedienungsanleitung

Burkert

Burkert 0131 Bedienungsanleitung

Burkert

Burkert 8653 AirLINE Field Bedienungsanleitung

Burkert

Burkert 8630 Bedienungsanleitung

Burkert

Burkert 6520 NAMUR Bedienungsanleitung

Burkert

Burkert 6430 Bedienungsanleitung

Burkert

Burkert Type 2000 Bedienungsanleitung

Burkert

Burkert 2030 Bedienungsanleitung

Burkert

Burkert 2712 Series Bedienungsanleitung

Burkert

Burkert 2712 Series Bedienungsanleitung

Burkert

Burkert 2031 Bedienungsanleitung

Burkert

Burkert 6126 Bedienungsanleitung

Burkert

Burkert FieldConnect ME64 Bedienungsanleitung

Burkert

Burkert 8653 AirLINE Field Bedienungsanleitung

Burkert

Burkert 3360 Bedienungsanleitung

Burkert

Burkert 2000 INOX Bedienungsanleitung

Burkert

Burkert 6213 EV Bedienungsanleitung

Burkert

Burkert 2103 Series Bedienungsanleitung

Burkert

Burkert 6144 Bedienungsanleitung

Burkert

Burkert 2103 Series Bedienungsanleitung

Burkert

Burkert 219639 Bedienungsanleitung

Burkert

Burkert 0470 Bedienungsanleitung

Burkert

Burkert 8640 Bedienungsanleitung

Burkert

Burkert 2100 series Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
