Bushnell GOLF Launch Pro Bedienungsanleitung
User Manual
BUSHNELL GOLF
LAUNCH PRO USER MANUAL
01
Your pursuit of longer drives, more accurate carries and lower
scores requires knowing the critical data points of your swing. A
personal launch monitor will give you these data points, however,
not all launch monitors are created equal. With Launch Pro,
you get the combination of Tour-level accuracy and true-to-
life simulation to give you the most complete personal launch
monitor available.
Thanks to the advanced photometric technology inside, the
Launch Pro remains accurate and reliable both on the range and
in your home simulator. Combine it with the FSX performance
and gaming suite and enjoy hundreds of world-class courses,
skill-building games, and global leagues and competitions.
This user manual will help you better understand the proper
set-up, operation, and care of your Launch Pro.
Welcome to Launch Pro
02
WELCOME
LAUNCH PRO USER MANUAL
ACCURACY ABOVE ALL
TABLE OF CONTENTS
Table of contents
03
Getting Started
Registration
Subscriptions
Ball Placement & Hitting
Quick Settings
Club Tracking
Target Alignment
Storage & Maintenance
Specifications & Support
5
11
13
15
19
23
27
31
33
LAUNCH PRO USER MANUAL
A
B
C
D
E
F
A
B
F
Launch Pro Launch Monitor
Power Cord
A/C Power Adapter
USB-C Cable
28 Club Marker Pack
Alignment Stick
C
ED
05
GETTING STARTED
LAUNCH PRO USER MANUAL
WHAT’S IN THE BOX
06
Getting Started
WELCOME TO YOUR LAUNCH PRO
LAUNCH PRO USER MANUAL
07 08
FEATURE OVERVIEW
Bushnell Badge
LED Indicator Light
Touch Display
3 High-Speed Cameras
Power Button AC Adaptor Input
USB-C/Ethernet Port
Handle
Getting Started
GETTING STARTED
LAUNCH PRO USER MANUAL
LAUNCH PRO USER MANUAL
Plugging in the Launch Pro
You can use your Launch Pro right out of the box, but it is recommended that you plug in
your Launch Pro and allow the battery to fully charge before use.
To power on the Launch Pro, press and release the power button. You will see a flashing
blue indicator light. To power off the Launch Pro, press and release the power button again.
GETTING STARTED GETTING STARTED
Connect to the internet
The first time you power up your Launch Pro, you will be prompted to connect to the internet.
To connect with Wi-Fi, choose your network, then enter the password. Alternatively, you can
connect your Launch Pro to a PC using an Ethernet cable or the provided USB-C cable. You
can also connect it to mobile devices using Wi-Fi.
Note: To use all the functions of the Launch Pro, it must connect to the internet at least once every 45 days. You
will see a warning if you need to connect within 5 days. After 45 days, the Launch Pro will no longer connect
with any supporting apps or software and you will see a screen prompting you to connect to the internet to
restore all functions.
LAUNCH PRO USER MANUAL
LAUNCH PRO USER MANUAL
09 10
Once connected to the internet, you will see a Registration QR Code on the touch display. Simply
scan the code with your phone or tablet and follow the prompts to set up a login and register
your device.
The Launch Pro requires online registration renewal every 45 days. If the registration of your
device has expired, all data channels from the Launch Pro (USB, ethernet, Wi-Fi, and Bluetooth)
will be blocked until registration renewal is completed. The Launch Pro will continue to work as
a stand-alone device.
To find registration information, swipe down to access the QUICK SETTINGS screen and tap
ABOUT, then REGISTRATION.
REGISTRATIONREGISTRATION
Registration
REGISTER YOUR LAUNCH PRO
LAUNCH PRO USER MANUAL
LAUNCH PRO USER MANUAL
11 12
If you see the ADD A SUBSCRIPTION screen , scan the QR code with your phone or tablet and
follow the prompts to set up your subscription.
SUBSCRIPTIONS
Subscriptions
YOUR GAME, YOUR CHOICE
SUBSCRIPTIONS
LAUNCH PRO USER MANUAL
LAUNCH PRO USER MANUAL
13 14
BALL PLACEMENT & HITTING
Ball Placement & Hitting
To use your Launch Pro, place upright approximately 2 feet away from the hitting area. If you
are using a hitting mat, make sure the Launch Pro is raised to the same level as the hitting
surface.
Place the ball on the ground in fornt of your Launch Pro. If the ball is outside of the hitting
zone, you will see the MOVE BALL INTO HITTING ZONE screen. If there are multiple balls
in the hitting zone, you will see the MULTIPLE BALLS DETECTED screen. Once the ball is in
the hitting zone, the Launch Pro will display the READY screen and the blue LED indicator
light will change from blinking to solid.
LET’S SEE WHAT YOUR LAUNCH PRO CAN DO!
BALL PLACEMNT & HITTING
LAUNCH PRO USER MANUAL
LAUNCH PRO USER MANUAL
15 16
BALL PALCEMENT & HITTING BALL PLACEMENT & HITTING
After hitting the ball, the Launch Pro records your speed, launch angle, push/pull, spin, and
carry. To access previous shot data, swipe down to access the QUICK SETTINGS screen, then
go to SETTINGS, then SHOT SAVER.
Ball Data Explained
Speed The measurement of velocity just after impact. Ball speed is the main
component in generating distance.
The initial vertical angle of ascent relative to the ground measured in degrees.
The launch angle, combined with ball spin and speed, determines the ball
carry and total distance.
In right-handed mode, Push is when the horizontal direction of the ball is
greater than or equal to zero. The ball moves “in to out”, away from the hitter.
Pull is the opposite; the ball moves “out to in”, towards the hitter.
The total distance of flight.
The degree of sideways (horizontal) spin. A component of total spin that
defines ball curvature or shot shape. The more sidespin, the greater the ball
curvature.
The backward rotation of the ball. A component of total spin that defines ball
lift and trajectory. The more backspin, the greater the ball height.
Launch Angle
Push/Pull
Carry
Side Spin
Back Spin
LAUNCH PRO USER MANUAL
17 18
