Handling Shown Below is for Illustration Purposes Only
•Pull the injector out of the pouch by
holding the handling tab.
•Infuse the OVD into the injector
through the infusion port and fill up
the area indicated by the dotted lines
with the cannula pointed in a direction
perpendicular to the body.
•Press the release tabs, lift up and remove
the cover from the case.
Handling
tab
Case
Cover
•While fixating the injector body with the
thumb of one hand, advance the slider
with the other hand until it stops,
•After advancing the slider, implant the IOL
within 3 minutes.
•Remove the injector from the case.
•Verify leading haptic position.
•Make sure that the leading haptic
extends forward.
•Push the injector knob forward until
it stops.
•Slowly rotate the knob clockwise,
carefully observing that the rod tip pushes
the optic edge in the center and does not
override or slip under the optic.
•If no issues are observed, go immediately
to implantation Steps G through J.
Case
Screw
Slider
Step A Step B Step C
Step D Step E Step F
Fill with OVD
between
these lines
IPure®3-Piece IOL User Guide
Preloaded Injector Handling and Implantation Steps
BVI and all other trademarks (unless noted otherwise) are property of BVI. BVI ©2020
bvimedical.com
US Tel: 866-906-8080 Fax: 866-906-4304
Email: [email protected]
1575126-01
FOR COMPLETE PRODUCT INSTRUCTIONS, PLEASE REFER TO THE BVI IFU OR PRODUCT INSERT
•Slowly rotate the injector knob until
the leading haptic comes out from
the injector tip extending to the left.
•After the leading haptic goes
beneath the capsulorhexis, rotate the
body of the injector counterclockwise
to confirm that the IOL comes out
with the folded side down.
Implantation Steps
Step I
Step G Step H
Step J
•Make sure that the trailing haptic has
been released completely from the
injector tip, then pull out the injector
from the incision.
•Adjust the position of the lens, using
a hook or other instrument.
•Carefully insert the injector tip
into the eye through the incision,
keeping the slit of the tip in a
downward position to ensure
correct IOL orientation.
