Cabletron Systems 9F426-02 Bedienungsanleitung

SmartSwitch 9000

9F426-02

User’s Guide

9031692-03

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,

SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED

TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

35 Industrial Way

Rochester, NH 03867-5005

Printed in the United States of America

Order Number: 9031692-03

LANVIEW

is a registered trademark, and

SmartSwitch

is a trademark of Cabletron Systems, Inc.

CompuServe

is a registered trademark of CompuServe, Inc.

i960 microprocessor

is a registered trademark of Intel Corp.

Ethernet

is a trademark of Xerox Corporation.

Notice

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING:

Changes or modiﬁcations made to this device which are not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

VCCI Notice

This is a Class A product based on the standard of the Voluntary Control Council for Interference by

Information Technology Equipment (VCCI). If this equipment is used in a domestic environment,

radio disturbance may arise. When such trouble occurs, the user may be required to take corrective

actions.

DOC Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la class Aprescrites dans le Règlement sur le brouillage radioélectrique

édicté par le ministère des Communications du Canada.

iii

Notice

DECLARATION OF CONFORMITY

ADDENDUM

Application of Council Directive(s):

89/336/EEC

73/23/EEC

Manufacturer’s Name:

Cabletron Systems, Inc.

Manufacturer’s Address:

35 Industrial Way

PO Box 5005

Rochester, NH 03867

European Representative Name:

Mr. J. Solari

European Representative Address:

Cabletron Systems Limited

Nexus House, Newbury Business Park

London Road, Newbury

Berkshire RG13 2PZ, England

Conformance to Directive(s)/Product Standards:

EC Directive 89/336/EEC

EC Directive 73/23/EEC

EN 55022

EN 50082-1

EN 60950

Equipment Type/Environment:

Networking Equipment, for use in a

Commercial or Light

Industrial Environment.

We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with

this notice conforms to the above directives.

Manufacturer Legal Representative in Europe

Mr. Ronald Fotino Mr. J. Solari

____________________________________________________ ______________________________________________________

Full Name Full Name

Principal Compliance Engineer Managing Director - E.M.E.A.

____________________________________________________ ______________________________________________________

Title Title

Rochester, NH, USA Newbury, Berkshire, England

____________________________________________________ ______________________________________________________

Location Location

Notice

Safety Information

CLASS 1 LASERTRANSCEIVERS

The FPIM-05 and FPIM-07 are Class 1 Laser Products

The FPIM-05 and FPIM-07 use Class 1 Laser transceivers. Read the

following safety information before installing or operating these

adapters.

The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation

limits. This control loop eliminates the need for maintenance checks or adjustments. The

output is factory set, and does not allow any user adjustment. Class 1 Laser transceivers

comply with the following safety standards:

• 21 CFR 1040.10 and 1040.11 U.S. Department of Health and

Human Services (FDA).

• IEC Publication 825 (International Electrotechnical Commission).

• CENELEC EN 60825 (European Committee for Electrotechnical

Standardization).

When operating within their performance limitations, laser transceiver output meets the

Class 1 accessible emission limit of all three standards. Class 1 levels of laser radiation are not

considered hazardous.

CLASS 1

LASER PRODUCT

Notice

Safety Information

CLASS 1 LASERTRANSCEIVERS

Laser Radiation and Connectors

When the connector is in place, all laser radiation remains within the ﬁber. The maximum

amount of radiant power exiting the ﬁber (under normal conditions) is -12.6 dBm or 55 x 10

-6

watts.

Removing the optical connector from the transceiver allows laser radiation to emit directly

from the optical port. The maximum radiance from the optical port (under worst case

conditions) is 0.8 W cm

-2

or 8 x 10

W m

sr-1.

Do not use optical instruments to view the laser output. The use of optical instruments to

view laser output increases eye hazard. When viewing the output optical port, power must

be removed from the network adapter.

Notice

vii

Contents

Chapter 1 Introduction

Features...........................................................................................................................1-1

Related Manuals............................................................................................................1-4

Getting Help .................................................................................................................. 1-4

Chapter 2 Installing the SmartSwitch 9000 Module

Unpacking the Module.................................................................................................2-1

Installing an FPIM......................................................................................................... 2-1

User-Accessible Components......................................................................................2-2

Installing the Module into the SmartSwitch 9000 Chassis......................................2-5

The Reset Switch ........................................................................................................... 2-7

Chapter 3 Operation

System Management Buses .........................................................................................3-2

SMB-1 Bus...............................................................................................................3-2

SMB-10 Bus.............................................................................................................3-2

System Diagnostic Controller...................................................................................... 3-2

DC/DC Converter ........................................................................................................3-3

INB Interface..................................................................................................................3-3

SecureFast Switch.......................................................................................................... 3-3

i960 Core......................................................................................................................... 3-4

Chapter 4 LANVIEW LEDs

Chapter 5 Speciﬁcations

Technical Speciﬁcations.........................................................................................5-1

CPU...................................................................................................................5-1

Memory............................................................................................................5-1

Standards .........................................................................................................5-1

Network Interface...........................................................................................5-1

Safety .......................................................................................................................5-2

Service...................................................................................................................... 5-2

Physical....................................................................................................................5-2

Dimensions......................................................................................................5-2

Weight...............................................................................................................5-2

Environment....................................................................................................5-2

Contents

viii

Appendix A FPIM Speciﬁcations

FPIM-00 and FPIM-01..................................................................................................A-1

FPIM-02 and FPIM-04..................................................................................................A-2

FPIM-05 and FPIM-07..................................................................................................A-3
