Cabletron Systems FN10 Bedienungsanleitung

9031801-01 Page 1

Fast Network 10 (FN10) Quick Setup

Unpack the FN10 from the shipping carton. Be sure to save all shipping material.

Make sure the following items were included with the FN10:

Fast Network 10 User Guide

Fast Network 10 LCM Commands Reference Card

Fast Network 10 MIB Reference Guide

Console Cable Kit

AC power cord

Four stick-on feet (for desktop installation)

Two rack-mount brackets with fasteners

Examine the FN10 for any damage. If you suspect a problem, call Cabletron Systems

Technical Support.

If you are rack mounting the FN10, see

“Rack-mounting a FN10” in Chapter 2 of the

Fast

Network 10 User Guide

for rack mounting instructions.

If you are installing the FN10 on a

desktop, do not place a monitor on top of the unit.

To power up the FN10, plug the AC power cord into the AC power connector on the rear of

the FN10 chassis and plug the other end of the power cord into a three-prong grounded

outlet. The input voltage must be between 90 - 250

VAC

If you are going to manage the FN10 using the Local Console Monitor (LCM), connect your

ASCII terminal, or terminal emulator, to the out-of-band management RS232C port on the

front panel of the FN10 using a standard 9-pin serial cable (Only three of the nine wires are

necessary: Receive Data, Transmit Data, and Ground).

Be sure your terminal is set to the

following: 9600 baud, 8 data bits, 1 stop bit, and no parity.

Press the Enter key several times. If the FN10 is operational, the LCM prompt,

FN10>

, is

displayed on your terminal’s screen.

Step

9031801-01 Page 2

To manage the FN10 from one of its RJ45 ports, you will need to assign an IP (Internet

Protocol) address to the port that will be performing management functions. At the

FN10>

prompt, type:

ipaddr

[port number]

[IP address]

. For example:

ipaddr 6 192.138.217.40

For more information

Refer to the following chapters in the

Fast Network 10 User Guide

Topic Chapter

Product Description 1

Installation 2

Local Console Manager (LCM) 1 & 2

Enabling Bridging 3

Modifying MIB Variables 3

Statistics 4

Enabling/Disabling a Port 4

Setting up FN10 Filters 5

Power-up Diagnostics 6

Troubleshooting 6

Speciﬁcations Appendix A

Glossary Appendix B

Step

LCM command port # IP address
