READ THIS SUPPLEMENT AND YOUR

CANNONDALE BICYCLE OWNER’S MANUAL.

Both contain important safety information.

Keep both for future reference.

Owner’s Manual Supplement

SuperSix EVO

English

Safety Messages

In this supplement, particularly important information

is presented in the following ways:

Indicates a hazardous situation which, if

not avoided, may result in death or serious

injury.

NOTICE

Indicates special precautions that must

be taken to avoid damage.

Cannondale Help Center

Our online Help Center contains helpful

resources to consult about our bikes.

https://cannondale.zendesk.com/hc/en-us

Symbols:

Symbol Name Description

CRB-GEL

Carbon gel/friction paste Apply carbon gel (friction paste) KF115/

GREASE

NGLI2 synthetic grease Apply NGLI2 synthetic grease.

Loc 242

Medium-strength removable thread

lock Apply Loctite® 242 (blue) or equivalent.

CONTENTS

Safety Information.......................... 47

Technical Information................... 823

Replacement Parts......................2425

Notes ..................................................26

Cannondale Supplements

This manual is a “supplement” to your

Cannondale Bicycle Owner’s Manual.

This supplement provides additional and

important model speciﬁc safety, maintenance,

and technical information. It may be one of

several important manuals/supplements for

your bike; obtain and read all of them.

Please contact your Authorized Cannondale

Dealer immediately if you need a manual or

supplement or have a question about your

bike. You may also contact us using the

appropriate country/region/location

information.

You can download Adobe Acrobat PDF

versions of any manual/supplement from our

website: http://www.cannondale.com.

Contacting Cannondale

Cannondale USA

Cycling Sports Group, Inc.

1 Cannondale Way

Wilton, CT 06897 USA

1800726-BIKE (2453)

CSG Europe (Woudenberg)

Cycling Sports Group Europe B.V.

Geeresteinselaan 57

3931JB Woudenberg

The Netherlands

PH: 00.31.541.200374

International Distributors

Consult our website to identify the appropriate

Cannondale Dealer for your region.

Your Cannondale Dealer

To make sure your bike is serviced and

maintained correctly, and that you protect

applicable warranties, please coordinate all

service and maintenance through your

Authorized Cannondale Dealer.

NOTICE

Unauthorized service, maintenance, or

repair parts can result in serious damage

and void your warranty.

SuperSix EVO OMS

Safety Information

Important Composites Message

151901 Rev. 0 (09/22)

SAFETY INFORMATION

Important Composites

Message

Your bike (frame and components) is

made from composite materials also

known as “carbon ﬁber.”

All riders must understand a fundamental

reality of composites. Composite

materials constructed of carbon ﬁbers are

strong and light, but when crashed or

overloaded, carbon ﬁbers do not bend,

they break.

For your safety, as you own and use the

bike, you must follow proper service,

maintenance, and inspection of all the

composites (frame, stem, fork, handlebar,

seat post, etc.) Ask your Cannondale

Dealer for help.

We urge you to read PART II, Section D.

“Inspect For Safety” in your Cannondale

Bicycle Owner’s Manual BEFORE you

ride.

You can be severely injured, paralyzed

or killed in an accident if you ignore this

warning.

Inspection & Crash Damage

Of Carbon Frames/Forks

After A Crash Or Impact:

Inspect frame carefully for damage. See

PART II, Section D. Inspect For Safety in

your Cannondale Bicycle Owner’s Manual.

Do not ride your bike if you see any sign of

damage, such as broken, splintered, or

delaminated carbon ﬁber.

Any of the following may indicate a

delamination or damage:

• An unusual or strange feel to the

frame

• Carbon which has a soft feel or

altered shape

• Creaking or other unexplained

noises,

• Visible cracks, a white or milky color

present in carbon ﬁber section

Continuing to ride a damaged frame

increases the chances of frame failure,

with the possibility of injury or death of

the rider.

Safety Information

Intended Use

The intended use of all

models is

ASTM CONDITION 1,

High-Performance

Road.

Please read your Cannondale Bicycle

Owner’s Manual for more information

about Intended Use and Conditions 15.

Servicing

This supplement may include procedures

beyond the scope of general mechanical

aptitude.

Special tools, skills, and knowledge may

be required. Improper mechanical work

increases the risk of an accident. Any

bicycle accident has risk of serious injury,

paralysis, or death.

To minimize risk we strongly recommend

that owners always have mechanical

work done by an Authorized Cannondale

Dealer.

Disc Brakes on Road Bikes

Relative to conventional rim brakes, disc

brakes are less aected by water, do not

wear or heat the rims and therefore are

more consistent. Disc brakes also may be

more powerful.

To minimize risk of injury or accidents:

• Understand that road bikes have a

relatively small tire contact patch

(part of the tire that touches the

road). In order to apply the brakes

safely and eectively, you may need

more or less braking force in

dierent situations. You need to take

into account various road and

weather conditions that can aect

traction.

• Disc brakes are excellent, but not

some kind of magic. Take some time

riding your new disc brake road bike

in lower risk circumstances to get

used to the feel and performance of

the disc brakes and tires.

You can be severely injured, paralyzed

or killed in an accident if you ignore this

message.

SuperSix EVO OMS

Safety Information

Using a Trainer

151901 Rev. 0 (09/22)

Using a Trainer

Follow the trainer manufacturer instructions for the

use of any required adapters.

Be particularly cautious with a carbon frame or fork.

Carbon is relatively soft, not abrasion resistant. If

there is any relative movement, carbon will wear

quickly.

If you ride a trainer a lot, consider using an old bike:

Corrosion from sweat will take its toll. Weight is

irrelevant. Save wear on your expensive

components.

Ask you dealer for help with trainers, the right one

and the correct way to use it.

NOTICE

TRAINERS - Improperly mounting a bike in a

trainer, or using one that is not compatible with

your particular bike frame can cause serious

damage.

This kind of damage is not covered by the

Cannondale Limited Warranty.

See “2-in-1 Trainer Thru Axle Installation

Instructions 138252.pdf”

at www.cannondale.com

Water Bottles

Side impacts to a water bottle or cage can

result in damage to threaded inserts due to

the leverage on a very small area. In a crash,

certainly the last thing you should be worried

about is saving the threaded inserts in your

frame. However, when you are storing or

transporting your bike, take steps to prevent

situations where a water bottle may be hit or

bumped by a strong force that would cause

damage. Remove the bottle and cage when

you are packing your bike for travel.

Periodically check the attachment of the

bottle cage; tighten the cage bolts if

necessary. Don’t ride with a loose bottle

cage.

A loose cage will damage the insert and

possibly lead to the inserts pulling out.

It may be possible to repair a loose insert or

to install another insert only if the frame is

undamaged. Replacement requires the use

of a special tool. If you notice damage to the

threaded insert, please ask your Cannondale

Dealer for help.

NOTICE

An impact, crash, or loose bottle cage can result

in damage to your frame. This kind of damage

is not covered by the Cannondale Limited

Warranty.

Safety Information

Building Up A Frameset

Before building up a frameset, consult with

your Cannondale Dealer and the component

manufacturers and discuss your riding style,

ability, weight, and interest in and patience

for maintenance.

Make sure the components chosen are

compatible with your bike and intended for

your weight and riding style.

Generally speaking, lighter weight

components have shorter lives. In selecting

lightweight components, you are making a

trade-o, favoring the higher performance

that comes with less weight over longevity. If

you choose more lightweight components,

you must inspect them more frequently. If

you are a heavier rider or have a rough,

abusive, or “go for it” riding style, buy

heavy-duty components.

Read and follow the component

manufacturers warnings and instructions.

Tightening Torques

Correct tightening torques for the fasteners

on your bicycle (e.g., bolts, screws, and

nuts) are important for your safety and to

maintain the durability and performance of

your bicycle.

We urge you to have your dealer correctly

torque all fasteners using a torque wrench.

If you decide to torque fasteners yourself,

always use a torque wrench.

Find Tightening Torque Information :

The wide range of bicycle models and

components used means that a listing of

tightening torques would be out-of-date

by the time it was published. Many

fasteners should be installed with a thread

locking adhesive such as Loctite®.

To determine the correct tightening

torque and any adhesive application

for a fastener we ask you to check the

following:

• On-product torque markings.

• Torque specs in the component

manufacturer’s instructions shipped

with your bicycle.

• Torque specs listed on the websites

of component manufacturers.

• With your dealer. Dealers have

access to current data and have

experience with correct torques for

most fasteners.

SuperSix EVO OMS

Technical Information

Speciﬁcations

151901 Rev. 0 (09/22)

TECHNICAL INFORMATION

Speciﬁcations

Item Speciﬁcation

Head Tube UPR: 11/8in, LWR: 11/4in

Headset Integrated 11/8in-11/4in,

IS42 Top IS47 Bottom

Bottom Bracket: Type/Width BSA/68mm - Sleeve required

Front Derailleur Braze-on

Seat Post: 0mm Oset: K26062

20mm Oset: K26072

Seatbinder: K26002

Min. Seat Post Insert 65mm

Max. Seat Post Insert 44cm: 100mm 48cm: 140mm 51cm: 166mm

54cm: 190mm 56cm: 193mm 58cm: 205mm

61cm: 215mm

Tire Size x Max. Tire Width 700c x 30mm (measured)

Brakes: Mount Type / Min./Max. Rotor Dia. FT: Flat Mount/140mm/160mm

RR: Flat Mount/140mm/160mm

Axles: Type/Length FT: Syntace 100mmxM121.0P,

122mm Overall Length

RR: Syntace 142mmxM121.0P,

160mm Overall Length

Fork Oset Size 44cm-54cm: 55mm

Size 56cm-61cm: 45mm

Intended Use ASTM Condition 1: High-Performance Road

Max. Weight Limit: Total

(Rider+All Equipment)

285lbs/129kg

Serial Number

Use the 7-digit serial number label (1) located

on the bottom bracket to register your bike.

Product Registration

www.cannondale.com

Technical Information

Geometry

75mm

Geometry

Dimensions = centimeter

* = same spec.

Size 44 48 51 54 56 58 61

Wheel Size 700c 700c 700c 700c 700c 700c 700c

ASeat Tube Length 40.0 43.8 47.7 51.5 53.4 56.7 60.0

BTop Tube Horizontal 51.2 52.0 52.8 54.6 56.2 57.8 60.3

CTop Tube Actual 46.9 47.9 48.9 50.9 52.3 54.1 56.4

DHead Tube Angle 70.9° 71.2° 71.2° 71.2° 73.0° 73.0° 73.0°

ESeat Tube Angle Eective 74.3° 74.3° 74.3° 73.7° 73.3° 72.9° 72.3°

E’ Seat Tube Angle Actual 74.3° 74.3° 74.3° 73.7° 73.3° 72.9° 72.3°

F Standover 69.8 72.7 75.6 78.8 80.7 83.6 86.6

GHead Tube Length 10.0 11.4 13.0 15.4 16.5 18.8 22.0

H Wheelbase 98.1 98.7 99.6 101.0 99.4 100.7 102.4

I Front Center 58.2 58.9 59.8 61.1 59.4 60.7 62.4

J Chain Stay Length 41.0 41.0 41.0 41.0 41.0 41.0 41.0

K Bottom Bracket Drop 7.4 7.4 7.4 7.2 7.2 6.9 6.9

L Bottom Bracket Height 26.8 26.8 26.8 27.1 27.1 27.3 27.3

M Fork Rake 5.5 5.5 5.5 5.5 4.5 4.5 4.5

N Trail 6.0 5.8 5.8 5.8 5.8 5.8 5.8

O Stack 50.5 52.0 53.5 55.5 57.5 59.5 62.5

P Reach 37.0 37.4 37.8 38.4 38.9 39.5 40.3

SuperSix EVO OMS

Technical Information

Shimano Di2 Battery

151901 Rev. 0 (09/22)

Shimano Di2 Battery

1. BB plug

2. Tether

3. Di2 battery

4. O-ring, larger

5. O-ring, smaller

a. groove

Identiﬁcation

• The tethering assembly is compatible with

Shimano BT_DN110 Di2 battery.

• The tether is ﬁtted to the battery and secured

onto it by the O-rings. Be sure that the O-rings

are seated in the grooves.

• After the battery is inserted into the frame,

fold up the tether end loop and tuck it into the

opening. Insert the BB plug; make sure it is

inserted completely. The hole in the BB plug

is simply a drain to allow collected moisture to

exit.

NOTICE

Do not allow the tether to dangle outside

the frame opening.

Do not insert other objects into the frame

battery pocket.

Andere Handbücher für SuperSix EVO

Inhaltsverzeichnis

Andere Cannondale Fahrrad Handbücher

Cannondale

Cannondale Adventure Neo Allroad S 2023 Bedienungsanleitung

Cannondale

Cannondale Trigger 27.5/29 Konfigurationshandbuch

Cannondale

Cannondale Jekyll 27.5 Konfigurationshandbuch

Cannondale

Cannondale Jekyll Konfigurationshandbuch

Cannondale

Cannondale Rush 29 Bedienungsanleitung

Cannondale

Cannondale TRIGGER Konfigurationshandbuch

Cannondale

Cannondale Scalpel Konfigurationshandbuch

Cannondale

Cannondale Kinneto E-Series Bedienungsanleitung

Cannondale

Cannondale Slice Carbon Konfigurationshandbuch

Cannondale

Cannondale Kids with Training Wheels Bedienungsanleitung

Cannondale

Cannondale Moterra Neo Shimano DU-E7000 Konfigurationshandbuch

Cannondale

Cannondale Synapse Carbon Bedienungsanleitung

Cannondale

Cannondale CY22 SmartSense Bedienungsanleitung

Cannondale

Cannondale SuperSix EVO Bedienungsanleitung

Cannondale

Cannondale LEFTY OLIVER Konfigurationshandbuch

Cannondale

Cannondale LEFTY HYBRID Konfigurationshandbuch

Cannondale

Cannondale Tesoro Neo X Speed Konfigurationshandbuch

Cannondale

Cannondale Alloy Road Disc Bedienungsanleitung

Cannondale

Cannondale CY22 Mavaro Neo Konfigurationshandbuch

Cannondale

Cannondale Mavaro Neo Konfigurationshandbuch

Cannondale

Cannondale Alloy Road Rim Bedienungsanleitung

Cannondale

Cannondale Synapse Carbon Konfigurationshandbuch

Cannondale

Cannondale Adventure Neo Allroad 2023 Konfigurationshandbuch

Cannondale

Cannondale Topstone Neo Lefty Bedienungsanleitung

Beliebte Fahrrad Handbücher anderer Marken

RAMBO

RAMBO R1000X2M-FF-BFD Bedienungsanleitung

Vermeiren

Vermeiren SAFARI Bedienungsanleitung

Velec

Velec A2/36V Bedienungsanleitung

Coswheel

Coswheel A-ONE Bedienungsanleitung

Betzold

Betzold 97869 Bedienungsanleitung

Cervélo

Cervélo S3 2019 Bedienungsanleitung

Tenways

Tenways AGO X Bedienungsanleitung

Festo

Festo EGSC-BS-KF Stücklistenhandbuch

Gio Electric

Gio Electric H1 Volt Bedienungsanleitung

GOGOBEST

GOGOBEST GM30 Bedienungsanleitung

DAHON

DAHON CIAO - 2009 Bedienungsanleitung

Aprimatic

Aprimatic ONDA 500 Kurzanleitung

MV Agusta

MV Agusta Lucky Explorer GRAVEL Gebrauchsanweisung

Greyp

Greyp G6 Series Bedienungsanleitung

Babboe

Babboe Carve-E Bedienungsanleitung

Huka

Huka orthros Bedienungsanleitung

Xtracycle

Xtracycle Stoker 2021 Bedienungsanleitung

APRILIA

APRILIA DORSODURO 750 ABS 2015 Bedienungsanleitung
