Capricorn LABC-801 Bedienungsanleitung

Instruction Manual

rel. 1.

Step 0.1 Capricorn RC

- Symbols -

Made in Italy

This radio control model is not toy.

First time builders should seek the advice of experienced modellers before beginning assembly and/or if they do not fully

understand any part of the construction.We highly advise to read the instruction manual before assembly, and to always

keep it at hand for reference. Take care before operating this model; you are responsible for its assembly and safe

operation. The extreme performance of this model could be understimated by inexpert drivers and could damage objects

and/or people. Assembly this kit only in places out of children's reach!

CAPRICORN RC is not responsible for any damage or harm caused by improper use or assembly.

CAPRICORN RC and its distribution network are not responsible for any damage caused by shipping or handling.

Eventual parts missing from the kit or flawed must be reported within two weeks of purchase to your local hobby

shop or distributor. For best performance, we highly advise to only use original authentic CAPRICORN RC parts.

For customer support and service please contact your local hobby shop or agent from whom you purchased this item.

Contents of box may slightly differ from the pictures shown. Construction tools, body, fuel, radio system and servo,

engine, muffler and battery pack are NOT INCLUDED unless otherwise stated.

WARNING

L/R

Symmetrical

Mounting

Assemble as many

times as specified

1 2

3 4

Assemble in the

specified order

Note:

TEXT....

Be Careful

Step 0.2 Capricorn RC

- Tools & Equipment -

Made in Italy

Tools needed for assembly (NOT INCLUDED)

Parts for model completion and Start (NOT INCLUDED)

Exhaust System

Engine Air Filter & Oil Steering & Throttle

Servos

Receiver RX Battery Pack

Transmitter Battery Charger

Also required: Starting Box - Nitro fuel - Fuel bottle - Glower - Plycarbonat body

Hex Wrench

1,5/2/2,5/3mm Reamer Wrench Glowplug

& Cluthnut Cutter Pliers Adjustable Pliers

Box Wrench

5mm Glass or Vinyl

Tape

Step 0.3 Capricorn RC

- Screws Chart -

Made in Italy

Bag S

M2,5x8

M3x5

M3x6

M3x8

M3x12

M3x6

M3x8

M3x10

M3x12

M3x16

M2,5x10

Bag S

Bag D

Bag S

Bag P

Bag S

M3x8 Flanged

M3x12 Flanged

M3x3

M3x5

M3x8

M4x4

M4x6

M2,5 Nylon lock

M4 Nylon lock

E-Ring n3

E-Ring n8

C-Ring n14

Washer 8x11x0,5

Pin 3x9,8

Bag A

Bag S

Bag P

Washer 2,6x6,2x0,5 Bag D

C-Ring n12

M4x10

M2,5x3

Pin 3x19,8

Pin 3x21,8

Washer 12x15x0,5

Washer 3x6x2

M3x16

M4x8

M4x12

1 1 Cap171215 D

2 1 Cap16027 D

3 1 Cap 508 BOX

41Cap14030 D

Parts List

Rif. n° Code Bag

Step 1.1 Capricorn RC

- Shock absorbers -

Made in Italy

5 Initial Setting

8 Initial Setting

Front 2x

Rear 2x

Oil

Front

12x1,5

Rear

1 1 Cap 2023 P

2 1 Cap 2140 S

3 1 Cap 2103 O

4 1 Cap 2129 P

52Cap 2012 B

6 2 Cap 2002 W

Parts List

Rif. n° Code Bag

Step 2.0 Capricorn RC

- Rear solid axle -

Made in Italy

3x21,8 Pin

12x18x4

Z46

Parts List

Rif. n° Code Bag

1 1 Cap 2022 P

2 1 Cap 2101 O

3 1 Cap 2061 O

41Cap 2130 P

52Cap 2012 B

6 2 Cap 2057 R

72Cap 2117 C

8 2 Cap 2003 W

Step 3.0 Capricorn RC

- One way front axle -

Made in Italy

One way oil

12x18x4

Z23

One way oil

6x12x2

1 2 Cap 2119 E

2 1 Cap 2060 O

3 1 Cap 2099 O

4 2 Cap 2006 S

52Cap17010 S

6 1 Cap 2062 O

71Cap 2102 O

8 1 Cap16083 M

9 2 Cap16020 B

10 1 Cap16060 M

11 2 Cap17030 S

12 1 Cap 2021 P

13 1 Cap 2055 P

Parts List

Rif. n° Code Bag

Step 4.0 Capricorn RC

- Middle Shaft Holder -

Made in Italy

Initial Setting

REAR

FRONT

To tighten front belt To loosen front belt

6x13x5

M3x6

Thread Lock

Z18

Z29

M4x4

Thread Lock

Parts List

Rif. n° Code Bag

1 1 Cap 2020 C

2 2 Cap 2128 S

3 2 Cap 2068 R

4 2 Cap16011 C

52Cap16031 C

6 2 Cap17021 S

72Cap17006 S

Step 5.0 Capricorn RC

- 2 Speed gear -

Made in Italy

M2,5x10

Important Note:

adjust the M2,5x10 screws in equal mode

7M3x3

Note:

Tighten screw gently until just

before a small gap appears

between the clutch shoes.
