CareCo BA09023 Bedienungsanleitung

BA09023 – Bathboard with Swivel Seat

Thank you for purchasing the Bathboard and Swivel Seat from CareCo, we hope you are pleased

with your purchase.

ASSEMBLY

A 1x Bathboard

B 3x Plastic Bolt (Circular)

C 4x Plastic Bolt (Rectangular)

D 4x Bath board feet

E 4x Plastic Washer

F 1x Transfer Handle

G 1x Swivel Seat

1. Ensure all parts are present and remove all packaging

2. Push the red transfer handle into the two holes at the end of the

bathboard with the handle angled towards the bathboard.

F 1x G 1x

A 1x

B 3x C 4x D 4x E 4x

3. Using the rectangular plastic bolts and washers, secure the four feet to the underside

of the bathboard. The bolt goes through the surface of the bathboard, through a washer

on the underside and then screws into the feet.

4. Place the blue swivel disc into the hole in the middle of the bathboard. Whilst holding in

place, use the circular bolt to secure in place from the underside. Tighten until secured

in place but can still rotate. Do not over tighten as the disc will not swivel

Operation

Please Note

1. Secure the bathboard in the bathtub using the width adjustable feet on the underside of

the bathboard. If necessary, loosen the feet and retighten in desired position.

• Bathboards are used accross a bath width ways.

• Store in a dry and ventilated place.

• Wipe down the frame using a soft cloth at least once a week.

• Clean the seat upholstery using a mild soap solution, rinse and wipe dry.

• Do not use this product if defective.

• Observe the alignment; ensure you are happy with the t to the bath.

• Do not move under load i.e. with the person on Bathboard.

• If the user has limited mobility, please do not leave unattended for safety purposes.

• Max user weight of 150 kg (23.5 stone).

2. Place bottom in the centre of the swivel disc, raise legs up, and rotate until square in

the bath.

Be sure your Bathboard and Swivel Seat is in proper working order at all times.

Please contact CareCo for any repairs required.

Your CareCo branded product is under warranty to be free from defects in material and

workmanship for one year from date of purchase. This warranty expresses our condence in

workmanship and materials used for our products.

In the event of a defect covered by this warranty, CareCo will, at our discretion, replace the

wheelchair or provide parts to remedy. This warranty does not cover device failure due to

owner misuse or negligence, or due to normal wear and tear. The warranty does not extend to

non-durable parts, such as rubber accessories, castors, grips and arm pads, which are subject

to normal wear and tear and require periodic replacement.

If you have any queries please contact CareCo.

Warranty

CareCo, Hubert Road, Brentwood,

Essex CM14 4JE

www.careco.co.uk
