Chicago Electric 67089 Installationshandbuch

67089

SET UP AND OPERATING INSTRUCTIONS

Distributed exclusively by Harbor Freight Tools®.

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

contained herein may be reproduced in any shape or form without the express written consent of

Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein. Tools required for

assembly and service may not be included.

For technical questions or replacement parts, please call 1-800-444-3353.

12V 3/8” LITHIUM-ION CORDLESS

DRILL/DRIVER

SKU 67089 For technical questions, please call 1-800-444-3353. Page 2

SAVE THIS MANUAL

Keep this manual for the safety warn-

ings and precautions, assembly, operat-

ing, inspection, maintenance and cleaning

procedures. Write the product’s serial

number in the back of the manual near the

assembly diagram (or month and year of

purchase if product has no number). Keep

this manual and the receipt in a safe and

dry place for future reference.

IMPORTANT SAFETY

INFORMATION

In this manual, on the labeling,

and all other information provid-

ed with this product:

This is the safety alert

symbol. It is used to alert

you to potential personal

injury hazards. Obey all

safety messages that

follow this symbol to avoid

possible injury or death.

DANGER indicates

a hazardous

situation which, if not

avoided, will result in death or

serious injury.

WARNING

indicates a

hazardous situation which, if

not avoided, could result in

death or serious injury.

CAUTION, used

with the safety

alert symbol, indicates a

hazardous situation which, if

not avoided, could result in

minor or moderate injury.

NOTICE is used to

address practices

not related to personal injury.

CAUTION, without

the safety alert

symbol, is used to address

practices not related to

personal injury.

General Safety Warnings

WARNING Read all safety

warnings and instructions.

Failure to follow the warnings and

instructions may result in electric

shock, re and/or serious injury.

Save all warnings and

instructions for future reference.

The term ″power tool″ in the

warnings refers to your line-

operated (corded) power tool.

1. Keep Battery Pack (38) Dry.

Do not open, drop, short-

circuit, incinerate or expose

to temperatures greater

than 140°F.

Charge Battery Pack only according2.

to the instructions indicated in this

manual.

Inspect Battery Pack before every3.

use; do not use or charge if dam-

aged.

Work area safety4.

Keep work area clean and well lit.a.

Cluttered or dark areas invite acci-

dents.

Do not operate power tools inb.

explosive atmospheres, such as in

the presence of ammable liquids,

gases or dust. Power tools create

SKU 67089 For technical questions, please call 1-800-444-3353. Page 3

sparks which may ignite the dust or

fumes.

Keep children and bystandersc.

away while operating a power tool.

Distractions can cause you to lose

control.

Electrical safety5.

Power tool Plugs must match thea.

outlet. Never modify the Plug in

any way. Do not use any adapter

plugs with grounded power tools.

Unmodied plugs and matching out-

lets will reduce risk of electric shock.

Avoid body contact with groundedb.

surfaces such as pipes, radiators,

ranges and refrigerators. There is

an increased risk of electric shock if

your body is grounded.

Do not expose power tools to rainc.

or wet conditions. Water entering

a power tool will increase the risk of

electric shock.

Do not abuse the Power Cord.d.

Never use the Cord for carrying,

pulling or unplugging the power

tool. Keep Cord away from heat,

oil, sharp edges or moving parts.

Damaged or entangled cords in-

crease the risk of electric shock.

When operating a power tool out-e.

doors, use an extension cord suit-

able for outdoor use. Use of a cord

suitable for outdoor use reduces the

risk of electric shock.

If operating a power tool in a dampf.

location is unavoidable, use a

Ground Fault Circuit Interrupter

(GFCI) protected supply. Use of

a GFCI reduces the risk of electric

shock.

Personal safety6.

Stay alert, watch what you are do-a.

ing and use common sense when

operating a power tool. Do not use

a power tool while you are tired

or under the inuence of drugs,

alcohol or medication. A moment

of inattention while operating power

tools may result in serious personal

injury.

Use personal protective equip-b.

ment. Always wear ANSI-approved

safety goggles. Safety equipment

such as NIOSH-approved dust mask/

respirator, NIOSH-approved hear-

ing protection, and heavy duty work

gloves will reduce personal injuries.

Prevent unintentional starting.c.

Ensure the Power Switch is in the

off-position before connecting to

the power source or picking up or

carrying the tool. Carrying power

tools with your nger on the Power

Switch invites accidents.

Remove any adjusting key ord.

wrench before turning the power

tool on. A wrench or a key left at-

tached to an oscillating part of the

power tool may result in personal

injury.

Do not overreach. Keep propere.

footing and balance at all times.

This enables better control of the

power tool in unexpected situations.

Dress properly. Do not wear loosef.

clothing or jewelry. Keep your

hair, clothing and gloves away

from moving parts. Loose clothes,

jewelry or long hair can be caught in

moving parts.

SKU 67089 For technical questions, please call 1-800-444-3353. Page 4

Power tool use and care7.

Do not force the power tool. Usea.

the correct power tool for your ap-

plication. The correct power tool will

do the job better and safer at the rate

for which it was designed.

Do not use the power tool if theb.

Power Switch does not turn it on

and off. Any power tool that cannot

be controlled with the Switch is dan-

gerous and must be repaired.

Disconnect the Power Cord fromc.

the power source before making

any adjustments, changing acces-

sories, or storing the power tool.

Such preventive safety measures

reduce the risk of starting the power

tool accidentally.

Store idle power tools out of thed.

reach of children and do not allow

persons unfamiliar with the power

tool or these instructions to oper-

ate the power tool. Power tools are

dangerous in the hands of untrained

users.

Maintain power tools. Check fore.

misalignment or binding of moving

parts, breakage of parts and any

other condition that may affect the

power tool’s operation. If dam-

aged, have the power tool repaired

before use. Many accidents are

caused by poorly maintained power

tools.

Keep cutting accessories sharpf.

and clean. Properly maintained cut-

ting accessories with sharp cutting

edges are less likely to bind and are

easier to control.

Use the power tool and its acces-g.

sories in accordance with these

instructions, taking into account

the working conditions and the

work to be performed. Use of the

power tool for operations different

from those intended could result in a

hazardous situation.

Service8.

Have your power tool serviced bya.

a qualied repair person using

only identical replacement parts.

This will ensure that the safety of the

power tool is maintained.

Specic Safety Warnings

Maintain labels and nameplates on1.

the power tool. These carry impor-

tant safety information. If unreadable

or missing, contact Harbor Freight

Tools for a replacement.

Read and adhere to the instruction2.

manual of the included 67104 Bat-

tery Charger (49) for important safety

warnings and instructions on how to

properly operate the Lithium Battery

Charger.

Read and adhere to the safety warn-3.

ings for the included 67120 Lithium

Battery Pack (38).

Do not use this Drill Driver Tool with4.

any other Battery or Charger.

Hold power tools by insulated grip-5.

ping surfaces when performing

an operation where the tool may

contact hidden wiring. Contact with

a ″live″ wire will make exposed metal

parts of the tool ″live″ and shock the

operator.

Maintain labels and nameplates on6.

the tool. These carry important safety

information. If unreadable or miss-

ing, contact Harbor Freight Tools for a

replacement.

SKU 67089 For technical questions, please call 1-800-444-3353. Page 5

Avoid unintentional starting. Prepare7.

to begin work before turning on the

tool.

Do not lay the tool down until it has8.

come to a complete stop. Moving

parts can grab the surface and pull

the tool out of your control.

When using a handheld power tool,9.

maintain a rm grip on the tool with

both hands to resist starting torque.

Do not leave the tool unattended10.

when it is plugged into an electrical

outlet. Turn off the tool, and unplug it

from its electrical outlet before leav-

ing.

This product is not a toy. Keep it out11.

of reach of children.

People with pacemakers should12.

consult their physician(s) before use.

Electromagnetic elds in close prox-

imity to heart pacemaker could cause

pacemaker interference or pacemak-

er failure. In addition, people with

pacemakers should:

• Avoid operating alone.

• Do not use with power switch locked

on.

• Properly maintain and inspect to

avoid electrical shock.

• Any power cord must be properly

grounded. Ground Fault Circuit Inter-

rupter (GFCI) should also be imple-

mented – it prevents sustained elec-

trical shock.

Some dust created by power sand-13.

ing, sawing, grinding, drilling, and

other construction activities, contains

chemicals known [to the State of Cali-

fornia] to cause cancer, birth defects

or other reproductive harm. Some

examples of these chemicals are:

• Lead from lead-based paints

• Crystalline silica from bricks and ce-

ment or other masonry products

• Arsenic and chromium from chemi-

cally treated lumber

Your risk from these exposures var-

ies, depending on how often you do

this type of work. To reduce your

exposure to these chemicals: work in

a well ventilated area, and work with

approved safety equipment, such as

those dust masks that are specially

designed to lter out microscopic

particles. (California Health & Safety

Code § 25249.5, et seq.)

WARNING: Handling the cord on14.

this product will expose you to lead,

a chemical known to the State of

California to cause cancer, and birth

defects or other reproductive harm.

Wash hands after handling. (Califor-

nia Health & Safety Code § 25249.5,

et seq.)

The warnings, precautions, and in-15.

structions discussed in this instruction

manual cannot cover all possible con-

ditions and situations that may occur.

It must be understood by the operator

that common sense and caution are

factors which cannot be built into this

product, but must be supplied by the

operator.

Vibration Safety

This power tool vibrates during use.

Repeated or long-term exposure to

vibration may cause temporary or

permanent physical injury, particularly

to the hands, arms and shoulders. To

reduce the risk of vibration-related

injury:

SKU 67089 For technical questions, please call 1-800-444-3353. Page 6

Anyone using vibrating power tools1.

regularly or for an extended period

should rst be examined by a doctor

and then have regular medical check-

ups to ensure medical problems are

not being caused or worsened from

use. Pregnant women or people

who have impaired blood circulation

to the hand, past hand injuries, ner-

vous system disorders, diabetes, or

Raynaud’s Disease should not use

this tool. If you feel any medical or

physical symptoms related to vibra-

tion (such as tingling, numbness, and

white or blue ngers), seek medical

advice as soon as possible.

Do not smoke during use. Nico-2.

tine reduces the blood supply to the

hands and ngers, increasing the risk

of vibration-related injury.

Wear suitable gloves to reduce the3.

vibration effects on the user.

Use power tools with the lowest vi-4.

bration when there is a choice be-

tween different processes.

Include vibration-free periods each5.

day of work.

Grip the power tool as lightly as pos-6.

sible (while still keeping safe control

of it). Let the tool do the work.

To reduce vibration, maintain the7.

power tool as explained in this manu-

al. If any abnormal vibration occurs,

stop use immediately.

SAVE THESE

INSTRUCTIONS.

SPECIFICATIONS

Drill Speeds Variable; 0 - 500 RPM

Forward/Reverse

Chuck Type 3/8” Keyless

Torque Settings

23 Screwdriver

Settings + One Drill

Setting

Trigger Settings Forward/Reverse

Included Charger (67104)

Battery (67120)

UNPACKING

When unpacking, make sure that the

item is intact and undamaged. If any parts

are missing or broken, please call Harbor

Freight Tools at the number shown on the

cover of this manual as soon as possible.

INSTRUCTIONS FOR

PUTTING INTO USE

Read the ENTIRE IMPORTANT

SAFETY INFORMATION

section at the beginning of this

manual including all text under

subheadings therein before set

up or use of this product.

TO PREVENT

SERIOUS INJURY

FROM ACCIDENTAL

OPERATION:

Turn the Forward/Reverse

Switch of the tool to its center,

locked position and remove

the Battery Pack (38) before

assembling or making any

adjustments to the tool.

Note: For additional information regarding

the parts listed in the following pages,

refer to the Assembly Diagram near

the end of this manual.

SKU 67089 For technical questions, please call 1-800-444-3353. Page 7

Installing a Drill Bit

Remove the Battery Pack and slide1.

Direction Switch (43) to its mid-posi-

tion.

While holding Drill/Driver and the2.

Chuck sleeve (adjacent to the frame)

in one hand, turn the Chuck (26)

counterclockwise to open the jaws.

Insert the bit or a Hex bit/Driver-Drill3.

bit into the jaws and turn the Chuck

clockwise until secure.

OPERATING INSTRUCTIONS

Read the ENTIRE IMPORTANT

SAFETY INFORMATION

section at the beginning of this

manual including all text under

subheadings therein before set

up or use of this product.

TO PREVENT

SERIOUS INJURY

FROM ACCIDENTAL

OPERATION:

Turn the Direction Switch (43)

of the tool to its center neutral

position and remove the

Battery and any attachments

before performing any

inspection, maintenance, or

cleaning procedures.

Work Piece and Work Area Set Up

Designate a work area that is clean1.

and well-lit. The work area must not

allow access by children or pets to

prevent injury and distraction.

Secure loose work pieces using a2.

vise or clamps (not included) to pre-

vent movement while working.

There must not be hazardous ob-3.

jects, such as utility lines or foreign

objects, nearby that will present a

hazard while working.

4. WARNING! Verify that the sur-

face has no hidden utility lines before

drilling or driving screws.

General Operating Instructions

Mark the position of the hole to be1.

drilled with a center punch to prevent

the Drill from “walking”.

Attach the Battery to the bottom of2.

the handle, it will click when it locks

into place. Please Note: The Bat-

tery ts only in one position. Do not

force the Pack when inserting.

Press the Direction Switch (43) to3.

the desired position (Forward or

Reverse). See the forward/reverse

arrows on the sides of the Direction

Switch.

When working with screws, turn the4.

Torque Selector to any one of the rst

23 torque settings. Do not change

the torque setting while the drill is

moving. And always start from a

lower setting to prevent unnecessary

force.

When drilling a hole, set the Selector5.

to the “Drill” icon. Pull the Trigger to

start the Drill/Driver. Allow the drill to

come up to full speed, before, apply-

ing it to the work surface.

Hold the Drill rmly with both hands, 6.

as torque will cause the tool to twist.

When drilling through light gauge7.

metal or thin, soft wood, place a

wooden block behind the material to

prevent burr or splinter damage when

SKU 67089 For technical questions, please call 1-800-444-3353. Page 8

the bit exits the workpiece. Lubricate

the Drill Bit with cutting oil when drill-

ing iron or steel. Use a coolant when

drilling nonferrous metals such as

copper, brass, or aluminum.

When the hole is drilled, remove the8.

drill bit from the hole while the Drill is

still running. This prevents the Drill Bit

from getting caught in the hole and

causing damage.

Please Note:9. The Drill/Driver has an

LED light that shines on contact area.

Lightly tapping on the Trigger will

activate the LED light.

To prevent accidents, turn off the tool10.

and disconnect its power supply after

use. Clean, then store the tool in-

doors out of children’s reach.

MAINTENANCE AND

SERVICING

Procedures not specically

explained in this manual

must be performed only by a

qualied technician.

TO PREVENT

SERIOUS INJURY

FROM ACCIDENTAL

OPERATION: Turn Power

Switch of Tool to its “OFF”

position and remove Battery

Pack from tool performing any

inspection, maintenance, or

cleaning procedures.

TO PREVENT SERIOUS

INJURY FROM TOOL

FAILURE: Do not use

damaged equipment. If

abnormal noise or vibration

occurs, have the problem

corrected before further use.

Cleaning, Maintenance, and

Lubrication

BEFORE EACH USE,1. inspect the

general condition of the tool. Check

for loose screws, misalignment or

binding of moving parts, cracked or

broken parts, and any other condition

that may affect its safe operation.

AFTER USE,2. clean external surfaces

of the tool with clean cloth.

3. WARNING! Do not use if either

the Battery Pack or Charger are

damaged in any way.

SKU 67089 For technical questions, please call 1-800-444-3353. Page 9

Record Product’s Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only, and are not avail-

able individually as replacement parts.

Troubleshooting

Problem Possible Causes Likely Solutions

Tool will not start. Battery not charged. Charge Battery.

Performance

decreases over

time.

Accessory dull or damaged. Keep accessories sharp. Replace as needed.

Excessive noise

or rattling.

Internal damage or wear. Have technician service tool.

Tool chatters

when tightening

fasteners

Low Torque setting. Select higher Torque setting.

Overheating. Forcing tool to work too1.

fast.

Accessory dull or2.

damaged.

Blocked motor housing3.

vents.

Allow tool to work at its own rate.1.

Keep cutting accessories sharp. Replace2.

as needed.

Wear ANSI-approved safety goggles and3.

NIOSH-approved dust mask/respirator while

blowing dust out of motor using compressed

air.

Follow all safety precautions whenever diagnosing or servicing the

tool. Disconnect power supply before service.

SKU 67089 For technical questions, please call 1-800-444-3353. Page 10

PARTS LIST

Part Description Qty.

1 Self-Tapping Screw (ST3×14 Φ5.3) 1

2 Self-Tapping Screw (ST3×9 Φ5.3) 2

3 Rear Cover 1

4 Left Housing 1

5 Motor 1

6 Motor Pinion 1

7 Motor Holder 1

8 Spring Washer 2

9 Philip Pan Screw (black, M3x6) 2

10 Gear Housing Washer 1

11 Top Stair Small Gear 3

12 Central Gear 1

13 Lower Stair Small Gear 3

14 Inner Gear Sleeve 1

15 Spindle 1

16 Spindle Washer 3

17 Plastic Housing 1

18 Steel Ball 4 8

19 Pin4.0*9.6 8

20 Bear Sleeve 1

21 Steel Ball 3 15

22 Bearing Spring Circlip 12 1

23 Front Cover 1

24 Self-Tapping Screw (black, ST2.6*8) 4

25 Chuck Screw/Left Twist 1

PARTS LIST

Part Description Qty.

26 Chuck (10mm) 1

27 Self-Tapping Screw (black, ST3×20) 4

28 Torque Clamp Plate 1

29 Torque Spring Plate 2

30 Torque Spring Plate Holder 1

31 Torque Outer Metal Sleeve 1

32 Torque Selector 1

33 Bush 1

34 Torque Control Spring 1

35 Ring Washer (40×30.5×0.15mm) 1

36 Torque Washer (40*30.5*0.3mm) 1

37 Torque Washer (40*30.5*0.8mm) 1

38 Battery Pack 1

39 T-Contact 1

40 Contact Frame 1

41 Contact 2

42 Internal Variable Switch 1

43 Direction Switch 1

44 Discharge Security Circuit Board 1

45 Right Housing 1

46 Self-Tapping Screw (black, ST2.6X14) 4

47 Self-Tapping Screw (black, ST3×14 Φ5.3) 2

48 Self-Tapping Screw (black, ST2.2*10) 2

49 Charger 1

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND

ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE

MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY

OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS

TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF

THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN

BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER

ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE

ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR

HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Inhaltsverzeichnis

Andere Chicago Electric Bohren Handbücher

Chicago Electric

Chicago Electric 1/2" variable Speed Reversible HEAVY DUTY DRILL... Montageanleitung

Chicago Electric

Chicago Electric 3670 Bedienungsanleitung

Chicago Electric

Chicago Electric HARBOR FREIGHT TOOLS 98544 Installationshandbuch

Chicago Electric

Chicago Electric 66127 Installationshandbuch

Chicago Electric

Chicago Electric 68126 Installationshandbuch

Chicago Electric

Chicago Electric 46804 Bedienungsanleitung

Chicago Electric

Chicago Electric 97907 Installationshandbuch

Chicago Electric

Chicago Electric 45790 Bedienungsanleitung

Chicago Electric

Chicago Electric 94434 Bedienungsanleitung

Chicago Electric

Chicago Electric 93632 Installationshandbuch

Chicago Electric

Chicago Electric 68169 Installationshandbuch

Chicago Electric

Chicago Electric 97594 Installationshandbuch

Chicago Electric

Chicago Electric 47991 Installationshandbuch

Chicago Electric

Chicago Electric VARIABLE SPEED 18 VOLT CORD- LESS DRILL/HAMMER DRILL... Bedienungsanleitung

Chicago Electric

Chicago Electric 42564 Bedienungsanleitung

Chicago Electric

Chicago Electric ITEM 62427 Bedienungsanleitung

Chicago Electric

Chicago Electric 93449 Bedienungsanleitung

Chicago Electric

Chicago Electric 95877 Montageanleitung

Chicago Electric

Chicago Electric 1/2" variable Speed Reversible HEAVY DUTY DRILL... Montageanleitung

Chicago Electric

Chicago Electric 69360 Installationshandbuch

Chicago Electric

Chicago Electric Chicago 44849 Betriebsanleitung

Chicago Electric

Chicago Electric 65756 Installationshandbuch

Chicago Electric

Chicago Electric 98179 Montageanleitung

Chicago Electric

Chicago Electric 47991 Stücklistenhandbuch

Beliebte Bohren Handbücher anderer Marken

Makita

Makita BDF456 Bedienungsanleitung

Black & Decker

Black & Decker LDX220 Bedienungsanleitung

Hitachi

Hitachi DH 40MA Bedienungsanleitung

Challenge

Challenge JO Technisches Referenzhandbuch

Makita

Makita LXFD01 Bedienungsanleitung

Festool

Festool T18+3 Bedienungsanleitung

Milwaukee

Milwaukee M12 FPDX-202X Bedienungsanleitung

EINHELL

EINHELL TE-RH 32 E Bedienungsanleitung

Makita

Makita DHP484 Bedienungsanleitung

Makita

Makita FD05 Bedienungsanleitung

Bosch

Bosch PSB 530 RA Bedienungsanleitung

Maximum

Maximum 054-1359-4 Bedienungsanleitung

Makita

Makita HP332D Bedienungsanleitung

Raider

Raider RDP-HD31H Bedienungsanleitung

Bort

Bort BPM-1400x2 Bedienungsanleitung

Black & Decker

Black & Decker 7266 Bedienungsanleitung

KENT USA

KENT USA TRD1230 Bedienungsanleitung

Bosch

Bosch GSB 19-2 RE Bedienungsanleitung
