CHIEF RFWD-110 Bedienungsanleitung

WARNINGS

WARNING The maximum weight to be installed on the RFWD wall mount is 40 lbs. (18.1 kg).

WARNING The RFWD is designed to be installed using wall studs or supporting framework.

The structure to which the RFWD wall mount is anchored must be capable of

supporting five times the total weight of the mount and all attached equipment.

CAUTION To prevent damage to the RFWD, which could affect or void the Factory warranty,

and to the equipment that will be attached to it, thoroughly study all instructions

and illustrations before you begin the installation.

CAUTION If your monitor uses a longer screw size other than those included in the kit,

DO NOT use the screws provided with the mount. Use the screws provided with

your monitor or contact the manufacturer. Using the wrong screws could result in

damage to your monitor.

If you have any questions about this installation, contact Chief Manufacturing at:

1.800.572.1373 or 952.277.3901.

LCD T

INSTALLATION

INSTRUCTIONS

(RFWD-110)

DUAL Swing Arm

WALL MOUNT

80 70

ASSEMBLY DIAGRAM

LCD TV WALL MOUNT DUAL Swing Arm (RFWD-110)

30 or 50 (optional)

40 or 60

(

tional

)

110

100

Cable Mana

ement Slots

120

PART PART NAME QTY NOTES

10 SINGLE SWING ARM 1

20 SCREW, PHILLIPS PAN HEAD, M4 X 12MM 4

FLUSH

MOUNT

30 SCREW, PHILLIPS PAN HEAD, M4 X 20MM (USE WITH 40) * 4

40 3/8” SPACER 4

50 SCREW, PHILLIPS PAN HEAD, M4 X 30MM (USE WITH 60) ** 4

60 3/4” SPACER 4

RECESSED

MOUNT

70 WASHER 2

80 SCREW, WOOD 2

90 BRACKET, WALL 1

100 PLATE, COVER, CABLE MANAGEMENT 2

110 SCREW, COVER, CABLE MANAGEMENT 4

120 SCREW, SET 1

• *Use M4 x 20mm screws (30) with spacers (40) for recessed applications.

• **Use M4 x 30mm screws (50) with spacers (60) for recessed applications.

INSTALLATION INSTRUCTIONS

A. Determine the exact mounting location prior to installation,

considering screen size as well as the mount swing and extension

radius.

Step 1

B. Use the wall bracket (90) as a template and drill two 3/32” pilot

holes to a minimum depth of 1 1/2”.

C. Check wall bracket to ensure it is level and adjust to level if

necessary.

D. Use two wood screws (80) and two #10 washers (70) to secure the

wall bracket (90).

Flushed Mount or Recessed Mount

Step 2 NOTE: This manual contains two sets of Installation Instructions,

listed below. Choose the set of instructions that applies to the

type of installation you want.

• Flush Mount Applications do not use spacers. The monitor

is attached to the mount with four screws.

• Recessed Mount Applications use spacers. The monitor

is attached to the mount with four screws and four

spacers.

CAUTION: If monitor uses a screw size other than those included in the

kit, DO NOT use the screws provided. Using the wrong screws

could result in damage to your monitor.

Flushed Mount

A. Install two screws (20) in to the top mounting holes of your monitor.

B. Align the hole-pattern of your display with the screws installed on

the mount and hang the mount from the two screws.

C. Install two remaining screws (20) through the mount and into the

mounting holes of your display.

Recessed Mount

NOTE: Use one of the following screw and spacer combinations:

(30 with 40) or (50 with 60).

A. Select four screws (30 or 50) for the Flush application.

B. Select the four spacers (40 or 60) for the Flush application.

C. Set four spacers (40 or 60) over the four mounting holes on your

monitor.

D. Install two screws (30 or 50) in to the top mounting holes of your

monitor.

E. Align the hole-pattern of your display with the screws installed on

the mount and hang the mount from the two screws.

F. Install two remaining screws (30 or 50) through the mount and into

the mounting holes of your display.

CAUTION: Over-tightening adjustment bolt will

cause excessive wear and may

distort adjustment components.

To adjust the tension of the spherical movement,

the arm movement, and the lateral movement:

1. Slightly tighten or loosen the tension

adjustment bolt indicated at the right.

2. Check for desired tension.

3. Repeat as necessary.

INSTALLATION INSTRUCTIONS (Continued)

A. Place the top of the mount on top of the wall bracket (90) and push

the bottom onto the wall bracket.

Step 3

B. Secure your display to the wall by tightening the set screw (120).

Cable Connection CAUTION: Make sure your cables do not run through a pinch point.

Connect and secure power/audio/video cables, making sure to leave

sufficient slack to allow for movement of the display. Secure cables using

cover plates (100) and four screws (110).

TENSION ADJUSTMENTS

Lateral Tension

ustment Bolts

Spherical Movement

Tension Adjustment Bolt

THIS PAGE

INTENTIONALLY

LEFT BLANK
