Circutor Wallbox eNext Series Bedienungsanleitung
Wallbox eNext Series
INSTALLATION GUIDE
(M255A01-03-20A)
Wallbox eNext
Installation guide
2
CIRCUTOR, SA reserves the right to make modifications to the device or the unit specifi-
cations set out in this instruction manual without prior notice.
CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the de-
vice specifications and the most updated manuals.
www.circutor.com
Disclaimer
Revision log
Date Revision Description
05/19 M255A01-03-19A Initial Version
11/19 M255A01-03-19B
Changes in the following sections:
1.- 2.- 3.- 4. - 5.- 5.A. - 5.B.- 5.C. -
5.E. - 5.F. - 5.G. - 5.H. - 5.I. - 5.J. - 6.
02/20 M255A01-03-20A Changes in the following sections:
6.
Wallbox eNext
Installation guide 3
Wallbox eNext Series
Installation guide
COPYRIGHT INFORMATION
This document is copyrighted, 2019 by Circutor, S.A. All rights are reserved.
Circutor, S.A. reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual can be reproduced, copied, translated or transmitted in
any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate
and reliable. However, the original manufacturer assumes no responsibility for
its use, or for any infringements upon the rights of third parties at hat may result
from its use.
All other product names or trademarks are properties of their respective owners.
Wallbox eNext
Installation guide
4
Wallbox eNext
Installation guide 5
Here’s your guide
to install eNext.
Disclaimer ....................................................................................................................................................2
Revision log...................................................................................................................................................2
Here’s your guide to install eNext...........................................................................................................5
1.-So,hello!....................................................................................................................................................6
2.-Before the installation...........................................................................................................................8
3.- Overview................................................................................................................................................12
4.- Dimensions...........................................................................................................................................14
5.- Installation............................................................................................................................................16
A. Requirements....................................................................................................................................17
B. Opening................................................................................................................................................18
C. Positioning..........................................................................................................................................19
D. Fixing....................................................................................................................................................20
E. Wiring...................................................................................................................................................21
F. CirBEON................................................................................................................................................23
G. DC current leakage detector..........................................................................................................24
H. Welded contactor detector.............................................................................................................24
I. Remote control function...................................................................................................................25
J. Closing .................................................................................................................................................26
6.- Technical Data.....................................................................................................................................28
Need help?..................................................................................................................................................31
Guarantee....................................................................................................................................................31
Wallbox eNext
Installation guide
6
1
Wallbox eNext
Installation guide 7
This manual provides commissioning information about Wallbox eNext, which
has been designed and tested to allow electric vehicle charging, specified in
IEC 61851.
This document has dierent sections such as step-by-step installation
procedure and technical data.
ELECTRIC RISK
Necessary precautions shall be taken to prevent any electrical
risk while the operations are carried out within the unit.
Unit must be disconnected from any power source during
commissioning.
ATTENTION!
Indicates that the damage to property can occur if appropriate
precautions are not taken
So, hello!
THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
SAFETY INFORMATION IN THIS DOCUMENT
• Complies with IEC 61851, Electric vehicle conductive charging
system (IEC 61851-1:2017).
• Complies with IEC 62196, Plugs, socket-outlets, vehicle
couplers and vehicle inlets (IEC 62196-1 and IEC 62196-2).
• Standards: 2014/35/UE, LVD;2014/30/UE, EMC.
Wallbox eNext
Installation guide
8
A safe work environment is not enough to control all potential electrical hazards. It is
recommended to be very cautious and work safely. So, the safety rules shown below
could help to control risks of injury or death from workplace hazards.
• Avoid contact with energized
electrical circuits.
• Disconnect the power source before
servicing or repairing electrical
equipment. The only way to be sure.
• Use only tools and equipment with
non-conducting handles when
working on electrical devices.
Easier to check.
• Never use metallic pencils or rulers,
or wear rings or metal watchbands
when working with electrical
equipment. This rule is very easy
to forget, especially when you
are showing some electrical part
pointing with metallic pencil.
• Enclose all electric contacts and
conductors so that no one can
accidentally come into contact.
• When it is necessary to handle
equipment that is plugged in, be
sure hands are dry and, when
possible, wear nonconductive
gloves, protective clothes and shoes
with insulated soles.
• If it is safe to do so, work with only
one hand, keeping the other hand
at your side or in your pocket, away
from all conductive material. This
precaution reduces the likelihood
of accidents that result in current
passing through the chest cavity.
• Never handle electrical equipment
when hands, feet, or body are wet
or perspiring, or when standing on
a wet floor.
IMPORTANT ELECTRICAL SAFETY INSTRUCTIONS
Read carefully all the instructions before starting in
order to ensure properly handling of electrical parts.
2
Wallbox eNext
Installation guide 9
Before the
installation
The charge point is designed for installation in indoor and outdoor areas. For each of the
dierent conditions of installation, the unit must be installed safely and ensure adequate
protection.
• Charge point must not be installed
in areas where there is potential
risk of explosions.
• Do not install the charge point
where falling objects may damage
the equipment.
• The surface where the charge
point is placed must withstand the
mechanical forces.
• This unit is no shall be used for
anything other purpose than
electric vehicle charging modes as
are expected in IEC 61851.
• Do not modify this unit. If
modified, CIRCUTOR will reject all
responsibility and the warranty will
be void.
• Comply strictly with electrical
safety regulations according to your
country.
• Do not use any adapter, except those
approved by the EV manufacturer.
• Do not make repairs or
manipulations with the unit
energised.
• Only trained and qualified personnel
should have access to low-voltage
electrical parts inside the unit.
• Check the installation annually by
qualified technician.
• Remove from service any item that
has a fault that could be dangerous
for users (broken plugs, caps that
don’t close...).
• Use only CIRCUTOR supplied spare
parts.
• Do not use this product if the
enclosure or the EV connector is
broken, cracked, open, or shows any
other indication of damage.
Refer to TECHNICAL DATA section for more information about environmental
installation conditions.
IMPORTANT CHARGE POINT SAFETY INSTRUCTIONS
Read carefully all the instructions before starting in
order to ensure properly installation of the charge
point.
Wallbox eNext
Installation guide
10
ELECTRICAL WIRING CONSIDERATIONS
Take into consideration this section before starting
wiring connections of the charge point.
1 — ELECTRICAL PROTECTIONS
Charge point may not include elements of electrical protection.
If this equipment has internal electrical protections, are installed in each socket-outlet
for the protection of the user against an electrical failure, according to the international
standard IEC 61851-1:2017.
In order to guarantee the total protection of the users and the installation (power supply
line included) in front of any electrical hazard, it is mandatory to install a main circuit
breaker (MCB) and a residual current device (RCD) upstream of the charger.
These electrical protections and the rest of the installation have to be aligned with the
local and national rules. The selectivity of the protections has to be guaranteed at all
times.
2 — POWER SUPPLY LINE DIMENSIONING
The dimensioning of the input power supply line of the Charge Point must be checked by a
qualified electrician. Note that several factors such as cable length between distribution
board and Charge Point, maximum output current of the Charge Point may influence the
criteria of cable selection.
In such cases, increasing the cable cross-section it is required to adapt the temperature
resistance of the power supply line.
3 — MAXIMUM OUTPUT CURRENT
Please refer to the TECHNICAL DATA section to consult the default factory settings from
maximum output current of the charge point.
If the power supply is less than maximum output current and adjustment to a lower
nominal current needs to be performed, please refer to the INSTRUCTION MANUAL.
This value may vary depending on the model.
