WARNING: Read these instructions before using the machine
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0120 - ISS 1
ORIGINAL INSTRUCTIONS
PETROL DRIVEN POWER WASHER
MODEL NO: TIGER 2600A
PART NO: 7320206
2
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
INTRODUCTION
Thank you for purchasing this CLARKE Petrol driven power washer.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase. This guarantee is invalid if the product is found
to have been abused or tampered with in any way, or not used for the
purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
ACCESSORIES
The range of accessories listed below are available from your CLARKE dealer.
ITEM PAR T NUM B E R
5 Litres Detergent (Traffic Film Remover) 3050821
25 Litres Detergent (Traffic Film Remover) 3050820
5 Litres Wash ‘n’ Wax 3050815
3
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
GENERAL SAFETY RULES
1. DO NOT point the spray at other people, animals, electrical equipment or the
machine itself.
2. DO NOT hold your finger over the high pressure nozzle.
3. DO NOT let children or untrained personnel use this machine.
4. DO NOT operate the machine with any of the covers removed.
5. DO NOT try to repair this machine. Always refer to your CLARKE service
department for all repairs.
6. DO NOT supply any liquid other than water to the water inlet.
7. DO NOT use the detergent pickup facility to introduce flammable liquids/
solvents, e.g. paint thinners, petrol, oil as there is a risk of explosion.
8. ALWAYS release the remaining pressure in the system turn off the water supply
and operate the trigger before you remove hoses or accessories.
9. ALWAYS keep the machine dry and away from the water spray.
10. ALWAYS use protective clothing and safety glasses. Loose particles and other
items can be propelled at high speed by the water spray.
11. ALWAYS hold the gun securely and expect it to ‘kick’ when you pull the
trigger.
12. ALWAYS respect the requirements of the local water company. Pressure
washers may only be connected to the mains water supply if a system
separator (also known as a backflow preventer) is installed in the supply hose.
13. ALWAYS disconnect from the water supply, and make sure that you drain the
system when not in use. Keep in a cool dry location.
14. ONLY use detergents that are suitable for pressure washers, we recommend
that you use CLARKE Traffic Film Remover or CLARKE Wash and WAX
(available from your dealer).
15. WARN ING High pressure hoses, fittings and couplings are important for the
safety of the machine. Use only hoses, fittings and couplings recommended
by the manufacturer.
16. WARN ING Water that passes through a system separator (also known as a
backflow preventer) is not safe to drink.
17. DO NOT use the pressure washer if there is damage to the inlet/outlet hose or
the machine.
WARNING: Water at high pressure can be dangerous and can cause
damage if the operator is careless. Never allow anyone to operate this
pressure washer unless they are familiar with the safety precautions.
4
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
SAFETY SYMBOLS
WARNIN G: Do not direct discharge
stream at persons or animals. Keep
clear of nozzle.
WARNIN G: Never direct spray toward
any electrical device or electrical
outlet.
General Warning, indicates
that failing to follow these
instruction could result in
injury or damage to the
machine.
To reduce the risk of injury,
read the manual before
use.
ALWAYS wear safety glasses
when using this machine.
WARNING: No open flame,
open ignition source and
smoking is prohibited
WARNING: No smoking
DANGER: Risk to
breathing. Engine
exhaust fumes can kill.
For outdoor use only. Work
in a well ventilated area.
WARNIN G: Risk of injection
or severe injury. Do not
direct discharge stream at
persons or animals. Keep
clear of nozzle. This
machine is to be used
only by qualified operators.
WARNIN G: Risk of spray
injury. Spray can propel
objects. Always wear ANSI
approved Z87.1 Safety
Glasses.
WARNIN G: Risk of
chemical burn. Never
spray acids, corrosive or
toxic chemicals. Use only
cleaners formulated for
pressure washers.
WARNIN G: Risk of
electrocution. Never
direct spray toward any
electrical device or
electrical outlet.
WARNIN G: Risk of unsafe
operation. Keep
children away from this
equipment. Gun kicks
back. Hold with both hands.
WARNIN G: Risk of hot
surfaces.
Recycle unwanted
materials instead of
disposing of them as waste.
All tools, accessories and
packaging should be
sorted, taken to a recycling
centre and disposed of in a
manner which is compatible
with the environment.
5
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
OVERVIEW
NO DESCRIPTION NO DESCRIPTION
1 Fuel Tank Cap 11 Engine On/Off Switch
2 Fuel Tank 12 Oil Filler Cap
3 Spark Plug 13 Water Outlet
4 Choke 14 Detergent Tank
5 Gun Assembly 15 Water Inlet
6 Lance 16 Bypass Drain Hose
7 Air Filter Cover 17 Hose Holder
8 Recoil Pull Start 18 Lance Holder
9 Fuel Valve 19 Priming Bottle
10 Throttle
6
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
ASSEMBLY
Unpack your pressure washer and check to ensure the following items are
present.
Contact your CLARKE dealer immediately if any parts are missing or
damaged.
CONNECTING THE WHEELS
1. Slide the axles into the locating
tube as shown.
• Make sure the ball catch locks
into the small hole on the
bottom of the locating tube.
2. Add the 2 axle covers as shown.
•1 x Petrol Power Washer •1 x Gun Assembly
•2 x Wheel c/w Axle •1 x Lance / Nozzle Assembly
•1 x Upper Handle c/w fixings •1 x Spark Plug Box Spanner
•1 x Hose Bracket c/w fixings •1 x Tommy bar
•1 x Lance Bracket c/w fixings •1 x Engine Manual
•1 x Primer Bottle •1 x Primer Bottle Holder
•1 x Primer Bottle Bracket •2 x Rubber feet and fixings
•1 x Hose •1 x 3m Inlet water hose
•1 x Water Filter (may be supplied already fitted)
7
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
FITTING THE RUBBER FEET
1. Fit the rubber feet to the legs as
shown.
CONNECTING THE HANDLE
1. Slide the upper handle into
position as shown.
2. Secure using a bolt and
handwheel.
• The handwheel should be on
the outside.
FITTING THE WATER BOTTLE
NOTE: The water bottle is only used when using the drawing water from an
unpresurrised source such as a water butt. See page 16.
1. Fit the bracket to the frame as
shown using the bolts, nuts and
washers supplied.
2. Slide the bottle holder over the
bracket and place the bottle in
the holder.
8
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
FITTING THE LANCE/HOSE HOLDER
Fit the holders into the positions
shown and secure using the washers
and nuts provided.
CONNECTING THE HIGH PRESSURE HOSE
CONNECT THE HOSE TO THE GUN
1. Screw the high pressure hose onto
the gun assembly.
• Tighten the connector, hand
tight only. Do not use a
spanner.
NOTE: Make sure the connection is
secure.
CONNECT THE HOSE TO THE PRESSURE WASHER
1. Screw the hose on to the pressure
washer.
• Tighten the connector, hand
tight only, Do not use a
spanner.
NOTE: Make sure the connection is
secure.
ASSEMBLING THE LANCE
Connect the spray lance to the gun
assembly and tighten securely by
turning the locking ring.
9
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
CONNECTING THE WATER SUPPLY
Always follow the regulations of your local water supplier. The pressure washer
must never be connected to the drinking water supply without using a system
separator (also known as a backflow preventer) available from most
hardware stores.
NOTE: Water that has flowed through a system separator is considered non-
drinkable.
1. Connect a water supply hose (not
supplied) to the water inlet.
• Make sure that the water filter is
installed behind the hose
connector on the water inlet
NOTE: Use a good quality fibre-
reinforced water hose with a
standard coupling.
NOTE: This machine has the ability to
draw its own water, meaning
you can use water not under pressure such as rainwater collected in a
water butt. See page 16.
BEFORE USE
IMPORTANT: The engine is supplied without any oil in it and must be filled to
the correct level before use, see below.
ENGINE OIL
1. Turn the oil filler cap anticlockwise
and remove it from the engine,
wipe the integral dipstick with a
clean cloth.
WARNING: STAND THE PRESSURE WASHER ON LEVEL GROUND WITH THE
ENGINE SWITCHED OFF.
WARNING: TAKE CARE NOT TO TOUCH ANY HOT PARTS OF THE PRESSURE
WASHER WHEN CHECKING THE OIL LEVEL.
10
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
2. Insert the oil filler cap back into
place and then remove it again.
3. If the oil reads low on the dipstick,
add oil to the oil reservoir (Max
0.6L).
• We recommend the use of
SAE10W-30 oil.
• Do not overfill the oil reservoir.
4. Replace the oil filler cap.
NOTE: Running the engine with
insufficient oil will cause
engine damage.
FUEL
1. Remove the fuel tank cap.
• Just inside the fuel tank is a fuel
strainer, which should be
checked periodically and any
contaminants which have
accumulated must be
removed.
2. Pour unleaded petrol through the
fuel strainer and into the fuel tank.
• Do not fill above the fuel
strainer shoulder.
• Use unleaded petrol with a
pump octane rating of 86 or
higher.
3. Replace the fuel filler cap
securely.
WARNING: REFUEL IN A WELL-VENTILATED AREA, AWAY FROM ANY
SOURCES OF IGNITION.
WARNING: IF THE ENGINE HAS BEEN RUNNING, ALLOW IT TO COOL
BEFORE REFUELING.
WARNING: DO NOT LEAVE FUEL WITHIN THE REACH OF CHILDREN.
WARNING: REFUEL CAREFULLY TO AVOID SPILLING FUEL.
Inhaltsverzeichnis
Andere Clarke Hochdruckreiniger Handbücher
Clarke
Clarke JET 9000B Bedienungsanleitung
Clarke
Clarke HLS160 Bedienungsanleitung
Clarke
Clarke King 140 Hotwasher Installations- und Betriebshandbuch
Clarke
Clarke PLS130AH Installations- und Betriebshandbuch
Clarke
Clarke HLS130 Bedienungsanleitung
Clarke
Clarke Power Wash PLS265A Bedienungsanleitung
Clarke
Clarke KING 200 Bedienungsanleitung
Clarke
Clarke TIGER 1800A Bedienungsanleitung
Clarke
Clarke Power Wash EHD130 Installations- und Betriebshandbuch
Clarke
Clarke JET 9500B Bedienungsanleitung
Clarke
Clarke JETSTAR 1900 Installations- und Betriebshandbuch
Clarke
Clarke JETSTAR 1700 Installations- und Betriebshandbuch
Clarke
Clarke TIGER 3000A Bedienungsanleitung
Clarke
Clarke PLV100LT Installations- und Betriebshandbuch
Clarke
Clarke Power Wash ELS145 Installations- und Betriebshandbuch
Clarke
Clarke TIGER 2600 Bedienungsanleitung
Clarke
Clarke PLS195B Bedienungsanleitung
Clarke
Clarke Power Wash KING 135 Installations- und Betriebshandbuch
Clarke
Clarke JET 8000B Bedienungsanleitung
Clarke
Clarke CWG2 Installations- und Betriebshandbuch
