Instructions: PermaPRO™

WARNING!

Cover for storage use only.

Donot occupy the

RV while cover

is on

the RV.

Do not run the RV engine with the

cover on.

WARNING!

Installation is best done with two people

and on most RVs requires working from

the roof of the RV. Never install on a

windy day or when the roof is slippery or

wet. Please take care when you are on a

ladder or the roof.

Be sure that your helper does not pull the

cover while you are on top of the RV.

CAUTION

Installation and removal is safer and

easier when done by two people. Cover

or tape any sharp edges on your RV that

could wear against your RV cover. Be sure

to lower any roof antennas.

Tools

Some radio antennas may need to be

unscrewed; usually with a Phillips head

screwdriver. Your cover will fit over flexible

or flat antennas and AC units.

Installation

1.With another person lift the cover to

the roof.

2.Carefully climb up on the roof and take

your cover out of its storage bag (Fig.

1). Place the rolled-up cover at the front

center of the roof and unroll down the

center of the RV toward the back (Fig. 2).

3a. Starting at the front, unfold your

cover from the center outwards. Continue

unfolding the cover as you work toward

the back, letting it fall over the sides of

your RV (Fig. ). Make sure the corners of

the cover are at the corners of your RV.

3b. For travel trailer, 5th wheel and

toy hauler RVs finish by zipping all the

panels closed on your cover then pull

the elasticized corners down over the

bumper(s)

of your RV.

4a. For class A and class C RVs

Your cover is equipped with triple zipper

pulls on the front side panels (Fig. 4).

These extra zipper pulls allow the cover

to fit RVs with mirrors that do not fold

against the RV. Zip all three zipper pulls

down to the mirror height, then zip the

bottom zipper to the bottom of the cover.

Create an opening at the mirror height

by zipping the top zipper up slightly

and the center zipper down slightly. Slip

the opening over the mirror and close

the top and bottom zippers around the

mirror post. Finish by zipping all the

panels closed on your cover then pull

the elasticized corners down over both

bumpers

of your RV.

4b. For 5th wheel RVs

Connect and loosely tighten the tension

panel strap across the bottom front of

the nose of your 5th wheel (Fig. 5). Then

connect the rip-and-grip tabs that fold

in on either side just under the nose of

your 5th wheel (Fig. 6). Adjust and tighten

straps as necessary for a snug fit.

4c. For toy hauler RVs

If your Toy Hauler is a trailer type skip to

step 5. If your Toy Hauler is a 5th wheel

type, Unzip the second zipper from the

front up to the bottom of the overhang on

both sides. Buckle a strap to the upper

tension panel (Fig. 7) (A) on the side of the

overhang and bring it across to the other

side and buckle. Repeat with the lower

tension panels (Fig. 7) (B).

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

5.For all RVs

Included with your cover is a toss bag

to help you attach the straps under your

RV. Before you begin fill your toss bag

with rocks or something of equal weight

equivalent. Clip the toss bag to the buckle

strap attached to the tension panel (Fig

8). Now toss the bag under your RV to

the buckle on the opposite side (Fig 9).

Unclip the strap from the bag and buckle

the bag to the next strap. Repeat with the

remaining straps.

6.Adjust the strap length on the tension

panels across the front and back to fit

your RV. Don’t over tighten—the straps

should be snug, not drum tight.

The sides of your cover can be unzipped

for access to the doors. The panels can

be rolled up and held in place with the

rip-and-grip straps toward the top of each

panel.

Your cover is equipped with extra long

zipper pulls. To secure the zipper pulls so

that they do not drag on the ground bring

the ends of the zipper pulls up and tuck

them into the rip-and-grip closure located

at the base of the zipper along the hem

(Fig. 10).

Use and Storage

A handy storage bag is provided.

The bottom of your bag unzips and

expands to make packing easier.

Note: For easier packing and re-installing

fold and roll tightly before packing in

storage bag.

Never store a wet cover in the storage

bag or confined area as the cover can be

damaged by mildew.

Care

Spot clean with water, a mild soap and

a sponge. Don’t use abrasive cleaners

or brushes.

Fig.10

Fig.8

Fig.9

Instructions PermaPRO™

do not

pack wet

do not iron

line dry

water

resistant

do not

use soap

A. RV Cover

Parts List

Before you begin please check that you have all your parts.

Your package should contain one of the following covers.

description

quantity

Class A

Class C

5th Wheel

Travel Trailer

Toy Hauler

A. Storage Bag

Parts List

Your package should contain one of the following storage bags.

part number

description

model

quantity

PRT-80-001 Medium Bag

Class A

Class C

5th Wheel

Travel Trailer

Toy Hauler

A. Toss Bag

Parts List

part number

description

quantity

PRT-80-003

Class A

Class C

5th Wheel

Travel Trailer

Toy Hauler

Your package should contain one of the following toss bags.

A. Straps

Parts List

Locate your cover below for the total quantity of straps included.

part number

description

model

quantity

PRT-80-004

Class A

3-5

6-8

Class C

2-3

4-7

5th Wheel

2-3

4-6

Travel Trailer

2-4

5-8

Toy Hauler

1-5 7
