Claypaky TAMBORA LINEAR 100 Bedienungsanleitung

IN TRUCTION MANUAL

Congratulations on choosing a Claypaky product!

We thank you for your custom.

Please note that this product, as all the others in the

rich Claypaky range, has been designed and made with

total quality to ensure excellent performance and best

meet your expectations and requirements.

INDEX

ENGLI H

Page Contents

2 1. afety information

3 2. Unpacking and preparation

3 3 Installation and start-up

3 3.1 Fixture overview

4 3.2 nstalling the fixture

5 3.3 Connecting to mains supply

5 3.4 Connecting the control signal line: DMX / Art-Net

6 3.5 Switching on the fixture and basic SetUp

7 4. Maintenance

7 4.1 Fuses replacing

8 4.2 Periodical cleaning & Caution

9 4.3 Battery removal

10 5. pecifications

10 6. Cause and solution of problems

CL2019

TAMBORA LINEAR 100

AFETY INFORMATION

MPORTANT: Claypaky recommends you carefully read and keep the safety information on this product, also

available in digital format at the following link:

www.claypaky.com

Ref: F S02C – Safety nformation Tambora Linear 100

INFORMAZIONI DI ICUREZZA

MPORTANTE: Claypaky raccomanda di leggere accuratamente e conservare le informazioni di sicurezza relative

a questo prodotto, sempre reperibili in versione digitale al seguente link:

www.claypaky.com

Rif: F S02C – Safety nformation Tambora Linear 100

INFORMATIONEN ZUR ICHERHEIT

W CHT G: Claypaky empfiehlt, die Sicherheitsinformationen bezüglich dieses Produkts genau zu lesen und

aufzubewahren. Sie sind in Digitalversion immer unter folgendem Link auffindbar:

www.claypaky.com

Ref: F S02C – Safety nformation Tambora Linear 100

INFORMACIONE DE EGURIDAD

MPORTANTE: Claypaky recomienda leer detenidamente y conservar la información de seguridad relativa a este

producto. Además, está disponible una versión digital de la misma en el siguiente enlace:

www.claypaky.com

Ref: F S02C – Safety nformation Tambora Linear 100

CON IGNE DE ÉCURITÉ

MPORTANT: Claypaky recommande de lire attentivement et de conserver les informations de sécurité relatives

à ce produit, disponibles en version digitale au lien suivant:

www.claypaky.com

Réf. : F S02C – Safety nformation Tambora Linear 100

ИНСТРУКЦИЮ ПО ТЕХНИКЕ БЕЗОПАСНОСТИ

ВАЖНО: Claypaky рекоменд ет внимательно прочитать и сохранить инстр кцию по технике безопасности

данного изделия, которая всегда дост пна в электронном формате по след ющей ссылке:

www.claypaky.com

Наименование: F S02C - Safety nformation Tambora Linear 100

1. AFETY INFORMATION

TAMBORA LINEAR 100

Packing contents - Fig. 1

2. UNPACKING AND PREPARATION

Neutrik PowerCON

TRUE1 (IN/OUT)

LCD Display

User buttons

Safety loop

5pin DMX IN/THRU

Ethernet

Fuse

Fan

Handle

Fan

3. IN TALLATION AND TART-UP

3.1 Fixture overview

Continue ‘

TAMBORA LINEAR 100

Projector installation - Fig. 3

The projector can be installed on the floor resting on specific rubber feet, on a truss, on the ceiling or wall.

WARNING: the safety chain must be installed except when the projector rests on the floor. (Code 105041-003 available upon request).

This must be secured to the projector support structure and then hooked to the fastening point at the centre of the fixture.

3.2 Installing the fixture

TAMBORA LINEAR 100

Continue ‘

Connections to the power mains - Fig. 5

Power

Supply

Connecting and disconnecting the power cord - Fig. 4

DMX 512

SIGNAL

SCREEN

DMX 512

5 PIN

SIGNAL

Ethernet

Connections to the control signal line (DMX) - Fig. 6

Use a cable conforming to specifications E A RS-485: 2-pole twisted, shielded, 120Ω characteristic impedance, 22-24 AWG, low capacity. Do not use

microphone cable or other cable with characteristics differing from those specified. End connections must be made using XLR type 5-pin male/female

connectors. A terminating plug must be inserted on the last projector with a resistance of 120 (minimum 1/4 W) between terminals 2 and 3.

IMPORTANT: The wires must not make contact with each other or with the metal casing of the connectors. The casing must be connected to the

shield braid and pin 1 of the connectors.

NB: connecting one

Tambora Linear 100 to the mains,

it is possible to connect up to a maximum

of 5 @200-240Vac - 1 @100-120Vac

Tambora Linear 100 in parallel

at the same time Max 2400W.

3.3 Connecting to mains supply

3.4 Connecting the control signal line: DMX / Art-Net

TAMBORA LINEAR 100

witching on the projector - Fig. 7

Switch-on the fixture. The projector starts resetting the effects. At the same time, the following information scrolls on the display:

Model Firmware Dmx Address xxx ystem errors

Tambora Version X.X.X .........................

Linear 100 Date - Hour .........................

The control panel (Fig. 7) has a display and buttons for the complete programming and management of the projector menu. The display can be in one

of two conditions: rest status and setting status. When it is in the rest status, the display shows the projector’s DMX address.

During menu setting status, after a wait time (about 30 seconds) without any key having been pressed, the display automatically returns to rest status.

t should be noted than when this condition occurs, any possible value that has been modified but not yet confirmed with the

key will be cancelled.

Dmx Address

War ning Message

3.5 witching on the fixture and basic etUp

Reversal of the display - Fig. 8

To activate this function, press UP

and DOWN

keys simultaneously while the display is in the rest mode. This status will be memorised and

maintained even for the next time it will be switched on. To return to the initial state, repeat the operation all over again.

etting the projector starting address

On each projector, the starting address must be set for the control signal (addresses from 1 to 512).

The address can also be set with the projector switched off.

Functions of the buttons - Using the menu

Confirms the displayed value, or activates the displayed function, or enters the successive

menu.

Decreases the value displayed (with auto-repetitions) or passes to the next item in the menu.

ncreases the value displayed (with auto-repetitions) or passes to the previous item in a menu.

Return to the top level

Enters the successive menu

DOWN

LEFT

R GHT

TAMBORA LINEAR 100

Fuse replacing - Fig. 9

Each Tambora Linear 100 has 1 fuse 10AT 250V, associated with the main power cord connection.

10AT 250V

Continue ‘

4. MAINTENANCE

4.1 Fuses replacing

etting addresses and options with the projector disconnected

The projector’s DMX address, as well as other possible operating options, can also be set when the appliance is disconnected from the electricity

supply. All that is needed is to press

R GHT

to momentarily activate the display and thus access the settings. Once the required operations have

been carried out, the display will switch off again after a wait time of 30 seconds.

U ING THE MENU:

1) Press LEFT

once – “Main Menu” appears on the display.

2) Use the UP

and DOWN

keys to select the menu to be used:

• Setup (Setup Menu): To set the setting options.

• Option (Option Menu): To set the operating options

• nformations ( nformations Menu): To read the counters, software version and other information.

• Manual Control (Manual control Menu): To trigger the test and manual control functions.

• Test (Test Menu): To check the proper functionning of effects

• Advanced (Advanced Menu): Access to the "Advanced menu" is recommended for a trained technical personnel.

3) Press

to display the first item in the selected menu.

4) Use the UP

and DOWN

keys to select the MENU items.

WARNING:

no alcohol

TAMBORA LINEAR 100

CAUTION:

•To ensure optimal operation and performance for a long time it is essential to periodically clean the parts subject to dust and grease deposits. The

frequency with which the following operations are to be carried out depends on various factors, such as the amount of the effects and the quality

of the working environment (air humidity, presence of dust, salinity, etc.).

t is recommended that the projector undergoes an annual service by a qualiﬁed technician for special maintenance involving at least the

following operations:

- General cleaning of internal parts.

- General visual check of the internal components, cabling, mechanical parts, etc.

- Electrical, photometric and functional checks; eventual repairs.

Cleaning the LED cover

Only use neutral soap and water to clean the LED cover, then dry it carefully with a soft, non-abrasive cloth. (WARN NG: the use of alcohol or any other

detergent could damage the LED cover).

4.2 Periodical cleaning & Caution

Parts requiring frequent cleaning.

Light collimation system

This product contains internal light

collimation system. Avoid intense

light from any angle.

TAMBORA LINEAR 100

This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the

regulation in force.

4.3 Battery removal

(2.91")

Rotating angle

1000

(39.37")

172

(6.77")

180°

5. DIMEN ION

TAMBORA LINEAR 100

THE PROJECTOR W LL NOT SW TCH ON

TROUBLE

ELECTRON CS NON-OPERAT ONAL

DEFECT VE PROJECT ON

REDUCED LUM NOS TY

POSSIBLE CAUSES CHECKS AND REMEDIES

No power supply.

LED burnt out or defective.

Signal transmission cable faulty or disconnected.

ncorrect addressing.

Fault in the electronic circuits.

Optic fault.

Dust or grease deposits.

Check the power supply voltage.

Call an authorised technician.

Replace the cables.

Check addresses (see instructions).

Call an authorised technician.

Clean (see instructions).

6. CAU E AND OLUTION OF PROBLEM
