Commell MP-954GPS Bedienungsanleitung

MP-954GPS

User’s Manual

Edition 1.1

2009/10/23

MP-954GPS User Manual

The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners.

Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at TUhttp://www.commell.com.twUT.

MP-954GPS User Manual

Packing List:

Hardware:

MP-954GPS Mini-PCI Card x1

Cable kit:

Com port cable (OALES-BKU2) x 2

CD Content::

Drivers & User’s Manual

MP-954GPS User Manual

1.0 <Product Specification>

General Specification

Form Factor Mini-PCI Type III B with 124-pin interface

Controller OXFORD OXuPCI954

Features Three 16C950 High performance UART channels

First channel for GPS

GPS Chipset SiRF Star III

GPS Features Tracking Sensitivity: -159dBm

Support NMEA 0183 and SiRF binary protocol

GPS Baud Rate 4,800 bps

1.1 <Connector Assignment>

JRX

CN_COM

JTX

MP-954GPS User Manual

Connector: CN_COM

Type:20-pin (10x2 pitch=1.27x2.54mm) header

Pin Description Pin Description

1 DCD1- 2 RX1-

3 TX1- 4 DTR1-

5 GND 6 DSR1-

7 RTS1- 8 CTS1-

9 RI1 10 NC

11 DCD2- 12 RX2-

13 TX2- 14 DTR2-

15 GND 16 DSR2-

17 RTS2- 18 CTS2-

19 RI2 20 NC

Connector: JRX

Type:3-pin (3x1 pitch=2.0mm) header

Pin Description Pin Description Pin Description

1 VCC 2 RX 3 GND

Connector: JTX

Type:3-pin (3x1 pitch=2.0mm) header

Pin Description Pin Description Pin Description

1 VBAT 2 TX 3 GND

Connector: RF

Type:MCX connector

Pin Description Pin Description

1 RF receive 2~5 RF GND

MP-954GPS User Manual

1.3 <Driver Setting>

1. Copy the CD Driver folder to disk, Ex: C:\ , D:\ …

2. Please choose “Device Manager”

3. You can see other devices ”Other PCI Bridge Device”

and “PCI Serial Port”

MP-954GPS User Manual

4. Please choose “Other PCI Bridge Device” then press

Update Driver

5. Please choose ”NO, not this time“

MP-954GPS User Manual

6. Install software for ”Other PCI Bridge Device” Please

choose ”Install from a list or specific location”

7. Please choose “Search for the best driver in these location”

Check “Include this location in the search” then press

“Browse”

MP-954GPS User Manual

8. Please select the file location

”C:\Driver\MP-954GPS\windows\2000&XP&Vista\32bit”

9. Hardware Installation ”Serial Bus Adapter” Press

“Continue Anyway”

MP-954GPS User Manual

10. Completing the hardware update wizard

11. Please choose “PCI Serial Port” then press

Update Driver step same as 5. ~ 9.
