QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 1

Overview

What's New

•

Intel



Pentium



processors

•

Intel



845 chipset

•

New Evo industrial design

with carbon and silver color

•

Front audio and USB ports

At A Glance

•

Intel



Pentium



processorswith400-MHz

Front Side Bus

•

Available in Convertible

Minitower form factor

•

Pre-loaded Microsoft Office

onD300s

•

Energy Star compliant with

energy-saving features

•

Windows XP Ready

•

Protected byCompaq

Services, includinga 1-1-1

limited warranty. Certain

restrictionsandexclusions

apply.

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 2

Standard Features – Select Models

Compaq Evo Desktop D300s Series with 845 chipset

Model Key

Example: D3Ms/P1.5/20j/2/128c6E

D3Ms = Evo D300s Convertible Minitower

Pre-Configured Models

P1.5 = Pentium 4 1.5-GHz processor

20 = Hard Drive, 5400rpm

j = 845 chipset

8 = Microsoft Windows 98 SE

2 = Microsoft Windows 2000 SP2

k = Microsoft Windows XP Professional

128 = Memory, PC133 SDRAM

c = 48X CD-ROM

6 = NVIDIA Vanta 16-MB 4X AGP graphics

g = NVIDIA MX200 16-MB 4X AGP graphics

E = Microsoft Office XP Small Business

470023-466 D3Ms/P1.7/40j/8/256c6E

470023-467 D3Ms/P1.7/40j/2/256c6E

470031-669 D3Ms/P1.8/20j/8/128c6E

470023-794 D3Ms/P1.8/40j/k/256cgE

470031-671 D3Ms/P2.0/40j/k/256c6E

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 3

Standard Features – Custom Components

Compaq Evo Desktop D300s Series with 845 chipset

Processor and Speed Intel Pentium 4 Processors Standard L2 Cache 256-KB Integrated ECC

One of the following 1.7-GHz Front Side Bus 400-MHz

1.8-GHz Maximum Memory 3-GB

2.0-GHz*

2.2-GHz*

Note. Intel Pentium 4 processors with speeds of 2.0-GHz or above have 512-KB L2 cache.

Note: Compaq Evo D300v Series Microtower with 845 chipset contains three DIMM slots, but can onl

be up

raded to a maximum of 3-GB when 1-GB PC133

SDRAM are available.

20-GB 7200 rpm Quiet Seek and Idle SMART IIII Ultra ATA/100Hard Drives

One of the following 20-GB 5400 rpm Quiet Seek and Idle SMART IIII Ultra ATA/100

40-GB 7200 rpm Quiet Seek and Idle SMART III Ultra ATA/100

40-GB 5400 rpm Quiet Seek and Idle SMART III Ultra ATA/100

60-GB 7200 rpm Quiet Seek and Idle SMART III Ultra ATA/100

1.0-GB SDRAM (PC133) (2 x 512MB)

Standard Memory

One of the following 512-MB SDRAM (PC133) (1 x 512MB)

256-MB SDRAM (PC133) (1 x 256MB)

128-MB SDRAM (PC133) (1 x 128MB)

Removable Storage 1.44-MB Diskette Drive

Zip 250 Drive including one disk

Optical Storage 48X CD-ROM Drive

16X/40X DVD-ROM Drive (with DVD-RAM disc read capability)

16X/10X/40X CD-RW Drive

8X/4X/32X DVD/CD-RW Combo Drive

Keyboard/Mouse Easy Access Keyboard

2-Button Scroll Mouse

Audio Integrated AC’97 Audio with Internal Speaker

NIC Integrated Intel PRO/100 VM Network Connection

Modem Lucent V90 56K PCI Modem (V.92 upgradable)

NVIDIA Vanta 16-MB 4X AGPGraphics NVIDIA GeForce2 MX200 16-MB 4X AGP

NVIDIA GeForce2 MX400 32-MB 4X AGP

Matrox Millennium G450 Dual-Head 32-MB 4X AGP

Operating System Microsoft Windows XP Professional

One of the following Microsoft Windows XP Home

Microsoft Windows 2000 Professional SP2

Microsoft Windows 98 SE

Productivity Software on D300s Microsoft Office XP Small Business with Publisher 2002

One of the following Microsoft Office XP Professional with Publisher 2002

Antivirus Software Norton Antivirus 2002

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 4

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

Intelligent Manageability Yes

Expansion Capability Memory Expansion Slots 3 DIMMs

Slots PCI 3 (3 on PCA) (slot occupied by video card)

AGP 1 (1.5V AGP 4X)

Bays Internal (2) HDD

External (2) 5.25" 1/2 ht

(1) Floppy

Dimensions (H x W x D) Inches 17.65 x 6.6 x 16.8 inches

Centimeters 44.8 x 16.8 x 42.7 centimeters

Weight System Weight 26.0 lbs / 11.8 kg

Weight Supported 100 lb / 45.5 kg

System Memory Type/Speed SDRAM DIMM - PC133 Only

Current Maximum Memory 1.5-GB

Maximum Memory 3-GB (when 1-GB PC133 SDRAM are available)

Memory Parity Not Supported

ECC Memory Supported (Intel 845 chipset does not support mixing of

Non-ECC and ECC PC133 memory)

Serial Presence Detect Support Mandatory as part of PC133 Spec

Supported Features Processor Intel Socket 478

CPU Bus Speed Supported 400-MHz

Memory Type Supported SDRAM

Memory Speed Supported PC133 Only

SPD Support Yes

Hard Drive Interfaces Supported SMART Ultra ATA/100/66/33

Hard Drive Controller (PCI) Interfaces Supported SMART Ultra ATA/100/66/33

Intel



Pentium



4 Coprocessor Yes

CPU Socket Type/Number Surface Mount ZIF Socket - 478 Pins

CPU Package mPGA478B, FC-PGA2

Front Side Bus Speed 400-MHz

Standard L2 Cache 256K

L2 Cache Architecture / Speed Advanced Transfer Cache on Die with 8-way associativity

and Error Correcting Code (ECC) / Full Speed of Processor

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 5

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

System Board Architecture P4 / PCI / AGP 4X

Chipset Intel 845 Chipset

I/O Controller Super I/O 3

System Board Form Factor Standard uATX

Processor Socket - 478 Pin ZIF Yes

DIMM Connectors Yes (3)

AGP Connector Yes (1)

AGP Integrated No

PCI Connectors 3 standard

Flash ROM Yes

Audio (ADI 1885 - AC97) Yes

CD ROM IN (Audio) Yes

Clear CMOS Button Yes

CPU Fan Header Yes

Chassis Fan Header Yes

Chassis Speaker Header Yes

CMOS Battery Holder - Lithium Yes

NIC Yes

Wake-On-Lan

Yes

Alert-On-LAN

Yes

Power Supply Header Yes

Power Switch, Power LED &

HD LED Header Yes

Password Clear Header Yes

Reset Header (Not Installed) Yes

SCSI LED Header Yes

Speaker Header Yes

Boards that connect to

System Board Convertible Minitower Solenoid Lock PCB (Option) PCI Extender Board -

2 additional PCI Slots Front I/O Board (Option)

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 6

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

Dual Color Power and HD LED - To Indicate Normal Operations and Fault ConditionsServiceability Features of System

Board Blinking Diagnostic Keyboard LED Codes

Diagnostic LED Label under Hood Cover

User Diagnostic Software Support

Over-Temp Warning on Screen (Need Intelligent Manageability to work)

Compaq Software Restore CD

Flash ROM

3.3V Aux Power LED on System PCA

Dual Function 5V Aux Power LED (ON) /PS_ON LED (OFF) on System PCA

Processor Hot LED on System PCA

Diagnostic Power Switch LED

Clear Password Jumper

Clear CMOS Button

Convertible Minitower Chassis Color Silver/Carbon

System Board Form Factors Supported Standard uATX & Standard ATX

Cooling Solutions Supported (3 Fans) Variable Speed Power Supply Fan

Variable Speed Processor Fan Heatsink

Variable Speed Chassis Fan

Slots Supported 4 Full Length, Full Height Slots (1 AGP and 3 PCI)

Front I/O Front Headphone, Mic, and 2 USB (Option)

Rear I/O Standard ATX I/O Panel

Internal Speaker Yes

Custom Power Supply 250-Watt Enhanced ATX PS

Security Locks Supported Kensington Cable Lock

Security Module (Solenoid Hood Lock and Hood Sensor)

Compaq Lock Bracket – 173234 (chassis securement

only, hood lock required to secure hood)

Power Switch / LED Cable Yes

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 7

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

Serviceability Features of Chassis Dual Color Power and HD LED to Indicate Normal

Operations and Fault Conditions Yes

Diagnostic LED Label under Hood Cover Yes

Security Module (Smart Cover Lock and Hood Sensor) Optional

Front power switch Yes

Green Pull Tabs, and Quick Release Latches for easy

Identification Yes

System memory can be upgraded without removing the

system board or any internal components Yes

Tool-less Hood Removal Yes (with captive thumbscrew)

Tool-less Hard Drive, CD & Floppy Removal Yes

Tool-less System Board Removal No

Industry Standard CD Bay Yes

Towerable Yes (Can also Rotate Drives)

Universal Tower Stand No (Not needed)

Green Color Coded Latches & Cable Pull Tabs for Easy

Identification Yes

Interfaces I/O Chip Super IO 3

Serial Port / UART Type Yes (2) / SN75185

Parallel Port Yes

USB 2 USB 1.1 (Optional 2 Front USB)

Infrared Port No

Network RJ-45 (with integrated LEDs)

Keyboard Yes (PS/2)

Mouse Yes (PS/2)

Video Yes (AGP 4X 1.5V Bus)

Audio Yes

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 8

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

Power Supply Full Ranging Input (No Line Select Switch) Yes

Active Power Factor Correction (APFC)

(Input Current is nearly ½ a non-APFC PS) Yes

Operating Voltage Range 90 to 264VAC

Rated Voltage Range 100 to 240VAC

Rated Line Frequency 50-60 Hz

Rated Input Current 3.6A @ 100VAC

Maximum Rated Power 250W

Heat Dissipation Max: 1,313 BTU/hr

Nominal: 656 BTU/hr

Max: 331 kg-cal/hr

Nominal: 165 kg-cal/hr

Power Conservation ‘Energy Saver’ Energy Star Compliant Yes

Blue Angel Compliant (<5w in S5-Power Off) Yes

Power Consumption in ES Mode -Suspend to RAM

(S3) (Instantly Available PC) TBD

APM Support Yes

Screen Blanking Yes

Hard Disk ‘Idle’ Mode Yes

System Idle Mode Yes

Processor/Cache Memory Power-Down (S3) Yes

CD-Rom Spins Down when not in use Yes

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 9

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

ROM Features Instantly Available PC (Suspend to RAM - S3)

ROM Based F10 Setup

Remote System Installation via F12 (PXE)

Failsafe Boot Block ROM

Emergency ROM Flash Recovery with Video

CMOS Archive and CMOS Restore

Save and Restore CMOS Setup via Diskette

Auto Setup when New Hardware Installed

Serial, Parallel, USB Enable/Disable Port Control

Removable Media Write / Boot Control

Remote Boot from Server

Network Server Mode

Power-On Password

Setup Password

Memory Change Alert (Need IM to work)

Thermal Alert (Need IM to work)

Cover Removal Alert (Need IM to work)

Master Boot Record Security

Remote ROM Flash

Remote Wakeup

Power Management

ACPI Ready

DMI BIOS (Desktop Management Interface)

System Environmental Specs Operating Temperature 50° to 95°F/10°to 35° C (Derating of 1.0°C per 300m (1000ft) to

3000m (10,000ft), no direct sustained sunlight)

Non-operating Temperature -22° to 140° F-30° to 60° C (Maximum rate of change is 20°C/Hr.)

Relative Humidity (non-condensing)

Operating 10% to 90% (28°C maximum wet bulb temperature)

Relative Humidity (non-condensing)

Non-operating 5% to 95% (38.7°C maximum wet bulb temperature)

Max Altitude (unpressurized) Operating 10,000 ft 3,048 m (Maximum allowable altitude change rate is1500

ft/min)

Max Altitude (unpressurized) Non-operating 30,000 ft 9,144 m (Maximum allowable altitude change rate is 1500

ft/min)

Acoustics ENERGY SAVE MODE: LWAd = TBD Bels, Desktop Average

LpAm = TBD dBA

FIXED DISK - SCSI (Random write): LWAd = TBD Bels, Desktop

Average LpAm = TBD dBA

Shock (Operating) 5 G

Shock (Non-Operating) 20 G

10 G (positive and negative directions front to back on Small Form

Factor)

Vibration (Operating) Operating: Random vibration at 0.000215 G²/Hz, 10Hz to 300Hz,

(0.25G's nominal)

Vibration (Non-Operating) Random vibration at 0.0005 G²/Hz, 10Hz to 500Hz, (0.5G's

nominal).

QuickSpecs Compaq Evo Desktop D300/300s

DA-10948 NorthAmerica — Version 13 — May 9,2002 10

Standard Features – Base Unit Details

Compaq Evo Desktop D300s Series with 845 chipset

Software

Preinstalled Software Microsoft Windows 98 SE Yes

Microsoft Windows 2000 SP2 Yes

Microsoft Windows XP Pro Yes

Microsoft Windows XP Home Yes

Microsoft Windows XP Small Business Yes

Microsoft Windows XP Professional Yes

Norton Antivirus Yes

Computer Setup Utility via F10 (ROM Based) Yes

Diagnostics for Windows Yes

Microsoft Internet Explorer Yes

Intelligent Manageability Agent Yes

Plug and Play Ready Yes

Windows 98 Yes

Windows 2000 Yes

Windows XP Pro Yes

Windows XP Home Yes

Boot Support Local Diskette Boot Yes

Local CD Boot Yes

Remote Boot Yes

Network Boot Yes

Intelligent Manageability Information downloadable from: http://www.compaq.com/im

Initial Configuration and Deployment Intelligent Manageability Home Page

Altiris eXpress

PC Transplant / PC Transplant PRO

System Software Management

Novel ZenWorks 2.0

Insight Manager

Support Software CD

Compaq Software Restore CD

Asset Control Asset Tag

DIMM Serial Presence Detect

Hard drive serial number, model, & manufacturer

Monitor serial number, model & manufacturer

System serial number, model, & manufacturer

ROM revision levels

System board revision level

Compaq Fingerprint Identification Technology (Optional)

DMI BIOS

Memory Change Alert (Intelligent Manageability needed to work)

Ownership Tag

Smart Cover Lock (Optional)

Kensington Lock Support

Smart Cover Sensor (Optional)

Andere Handbücher für Compaq Evo Deskpro D300

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Compaq Desktop Handbücher

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Kurzanleitung

Compaq

Compaq Professional sp750 Installationsanleitung

Compaq

Compaq 3000R - ProLiant - 128 MB RAM Bedienungsanleitung

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Betriebsanleitung

Compaq

Compaq 5000 Series Montageanleitung

Compaq

Compaq 141536-002 - Deskpro EN - MT RAMBUS Handbuch

Compaq

Compaq 133756-004 - Deskpro EN - 6550 Model 6400 Bedienungsanleitung

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Installationsanleitung

Compaq

Compaq 470022-515 - Evo - D300 Bedienungsanleitung

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Referenzhandbuch

Compaq

Compaq 100eu - All-in-One PC Bedienungsanleitung

Compaq

Compaq Presario 6000 Series Bedienungsanleitung

Compaq

Compaq 500B MT Einrichtungshandbuch

Compaq

Compaq Deskpro 4000N - Desktop PC Bedienungsanleitung

Compaq

Compaq SR5450F - Presario - 2 GB RAM Anleitung zur Verwendung

Compaq

Compaq Presario All-in-One SG2-200 - Desktop PC Anleitung zur Verwendung

Compaq

Compaq Presario SR1700 - Desktop PC Technisches Datenblatt

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Referenzhandbuch

Compaq

Compaq Presario Series Handbuch

Compaq

Compaq CQ2009F - 1 GB RAM Bedienungsanleitung

Compaq

Compaq Presario CQ4000 - Desktop PC Bedienungsanleitung

Compaq

Compaq AlphaStation XP1000 Gebrauchsanweisung

Compaq

Compaq d338 - Microtower Desktop PC Bedienungsanleitung

Compaq

Compaq Deskpro Workstation AP230 Gebrauchs- und Pflegehandbuch

Beliebte Desktop Handbücher anderer Marken

HP m9060n - Pavilion - Elite Technisches Datenblatt

Asus

Asus E210 Series Bedienungsanleitung

Dell

Dell Inspiron 600m Bedienungsanleitung

Dell

Dell Inspiron 3662 Bedienungsanleitung

TotalFlow

TotalFlow uFLO Bedienungsanleitung

HP Presario SV7000 - Desktop PC Bedienungsanleitung

HP ProDesk 400 G5 Handbuch

Logitech

Logitech MK320 Bedienungsanleitung

Dell

Dell XPS 730 H2C Bedienungsanleitung

Sony

Sony Vaio Series Bedienungsanleitung

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Bedienungsanleitung

Alto

Alto MD 250 Bedienungsanleitung

Lenovo

Lenovo ThinkCentre Edge 72 Handbuch

Lenovo

Lenovo ThinkStation D20 Handbuch

Arbor Technology

Arbor Technology FPC-7800 Series Bedienungsanleitung

Sony

Sony VAIO VGX-TP1 Series Bedienungsanleitung

Asus

Asus Eee Box B204 Bedienungsanleitung

Dell

Dell Optiplex 9010 All In One Bedienungsanleitung
