Compaq Presario Series Bedienungsanleitung

End-User Replaceable Parts Program

Replacing the Hard Drive

Notice

COMPAQ and the Compaq logo Registered in U.S. Patent and Trademark Office.

Microsoft and Windows are trademarks of Microsoft Corporation.

All other product names mentioned herein may be trademarks or registered trademarks of their respective companies.

Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to

change without notice.

The information in this publication is subject to change without notice and is provided "AS IS" WITHOUT WARRANTY OF ANY

KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF THIS INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT

SHALL COMPAQ BE LIABLE FOR ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE OR OTHER

DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS,

BUSINESS INTERRUPTION OR LOSS OF BUSINESS INFORMATION), EVEN IF COMPAQ HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. THE FOREGOING SHALL APPLY REGARDLESS OF THE NEGLIGENCE OR OTHER

FAULT OF EITHER PARTY AND REGARDLESS OF WHETHER SUCH LIABILITY SOUNDS IN CONTRACT, NEGLIGENCE,

TORT, OR ANY OTHER THEORY OF LEGAL LIABILITY, AND NOTWITHSTANDING ANY FAILURE OF ESSENTIAL

PURPOSE OF ANY LIMITED REMEDY.

The limited warranties for Compaq products are exclusively set forth in the documentation accompanying such products. Nothing herein

should be construed as constituting a further or additional warranty.

Compaq Presario

First Edition (May 2001)

Part Number 238173-001

REPLACING THE HARD DRIVE 3

Replacing the Hard Drive

The hard drive is used to store programs and data on your computer.

If you have any problems replacing the hard drive, contact Compaq Support at 1-800-984-9350.

Introduction

Your Compaq Internet PC has an Easy Access panel that makes accessing the internal parts easy. This document

contains instructions for removing and replacing the hard drive (see Figure 1-1).

Figure 1-1

Note: The view shown may vary slightly by model.

mCaution: Dropping the hard drive may cause damage to the hard drive and/or loss of data.

Tools Needed

A Phillips screwdriver is needed to remove and replace the hard drive.

A QuickRestore CD with installation instructions is provided for configuring your computer after you install your

replacement hard drive.

The QuickRestore CD ships separately from the replacement hard drive. If you did not receive a QuickRestore CD

after your initial call to service, call 1-800-984-9350.

Special Recommendations

All upgrades and repairs should be performed on a hard, scratch-resistant surface. Upgrading and repairing your

computer on carpeted surfaces is not recommended due to static electricity.

Warranty Statement

Compaq provides these detailed instructions to ensure your safety and to keep your PC from being damaged.

Following these instructions also ensures that your PC remains warranted by Compaq.

Your replacement part is warranted for the longer of 90 days from the date the part was delivered to you, or the

original One Year Limited Warranty that came with your Compaq Presario.

4 REPLACING THE HARD DRIVE

I. reparing Your Computer For Disassembly

1. Remove any diskette or compact discs (CDs) from the computer.

2. To shut down your computer, click the Start button, and then click Shut Down. The Shut Down Windows

dialog box is displayed. Select Shut Down from the drop-down list and click OK to turn the computer off.

3. Disconnect all peripheral device cables from the computer.

4. Disconnect the power cord from the electrical outlet 1and computer 2(see Figure 1-2).

Figure 1-2

Failure to disconnect the power from the computer may result in personal injury.

Warning

REPLACING THE HARD DRIVE 5

II. Opening the Side Access Panel

1. Locate the latch 1on the back of the computer and press down on the lever to release the side panel. Grab the

handle on the side panel and slide the side panel from the chassis 2(see Figure 2-1).

Figure 2-1

mCaution: Before doing any work inside your computer, ground yourself by touching a metal part of the chassis.

Note: Should the latch fail to move

when pressed downward, check to

see if there is a shipping screw above

the latch. If so, remove the screw.

6 REPLACING THE HARD DRIVE

III. Removing the Hard Drive

To remove the hard drive, complete the following procedure.

1. Turn the computer on its side (open side facing up).

2. Locate the hard drive inside the chassis wall at the front of the computer.

Note: Your hard drive has icons and markings inside the chassis to make identifying parts easy. Look at the replacement part carefully to

help identify and locate the component to be replaced.

3. Disconnect the hard drive data cable 1and power cable 2using a gentle rocking motion (see Figure 3-1).

Note: The hard drive data cable has a blue pull tab to help you identify the cable.

Figure 3-1

If you leave the computer at any time during the removal and replacement procedure, remember to touch

some part of the metal chassis before resuming the procedure.

Warning

REPLACING THE HARD DRIVE 7

4. Remove the screw securing the hard drive to the chassis and save it for your replacement drive (see Figure 3-2).

Figure 3-2

Important: Keep the screw that secured the defective hard drive to the chassis. You will need it for your replacement drive.

5. Tilt out the side of the drive that was screwed to the chassis then lift out the entire drive (see Figure 3-3).

Figure 3-3

8 REPLACING THE HARD DRIVE

IV. Replacing the Hard Drive

To replace the hard drive, complete the following procedure.

Note: Save all the packing materials received with your replacement drive. You will need them to return the defective part.

mCaution: Dropping the hard drive may cause damage to the hard drive and/or loss of data.

1. Slide the three holes on the bottom of the replacement hard drive over the three tabs 1on the chassis. Ensure

that the center screw hole on the top side of the hard drive is aligned with the center bracket on the chassis 2and

push the drive into place flat against the chassis 3(see Figure 4-1).

Figure 4-1

2. Replace the screw securing the hard drive to the chassis (see Figure 4-2).

Figure 4-2

REPLACING THE HARD DRIVE 9

3. Reconnect the hard drive power cable 1and data cable 2to the replacement hard drive (see Figure 4-3).

Figure 4-3

V. Replacing the Side Access anel and Connecting the ower

1. Align the tabs on the top and bottom of the side access panel with the slots on the top and bottom edge of the

chassis and slide the side access panel 1into place. Connect the power cord to the computer 2and the

electrical outlet 3(see Figure 5-1).

Figure 5-1

10 REPLACING THE HARD DRIVE

VI. Checking To See If the Replacement art Is Installed roperly

1. Reconnect all peripheral devices to the computer.

2. Turn on the computer by pressing the Power button.

3. Run the QuickRestore CD (follow the instructions provided with the CD).

Note: You do not need to return the QuickRestore CD when returning your defective hard drive.

4. If the problem persists, repeat the Removing and Replacing procedures.

5. If you are still experiencing problems, contact Compaq Support: 1-800-984-9350.

VII. Returning the Defective art

Please refer to the Compaq Part Return Instructions that came with your replacement part for instructions on

returning the defective part.
