CE-DVISM DVI CAT5 Extender 1 in 1 out

User Manual

Please read this manual carefully before using this product.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate this equipment and

before connecting the power supply.

Please keep the following in mind as you unpack and install this equipment:

• Always follow basic safety precaution to reduce the risk of fire, electrical shock and injury to

persons.

• To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this product

near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any openings or empty slots in the

unit, as you may damage parts inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.

• Do not allow anything to rest on the power cabling or allow any weight to be placed upon it or

any person walk on it.

• To protect the unit from overheating, do not block any vents or openings in the unit housing that

provide ventilation and allow for sufficient space for air circulate around the unit.

ITEM NO.: CE-DVISM

The DVI CAT5 extender is to extend your PC DVI transmission distance up to 70 meters with

resolution 1024x768. With DVI Adaptors, users can transmit high quality digital video of PC

applications thru one cost effective CAT-5/5e to the remote monitor or projector, instead of using

short and expensive DVI cables. With embedded EDID inside the adaptor, your PC will continue to

send the digital video even when the monitor is not connected. The user can then disconnects the

monitor, place it in a remote location and reconnect it without rebooting the operating system.

CE-DVISM CAT5 Extender 70 Meters

Include DE01E transmitter, DE01ER receiver, used in pairs via one CAT5e/6 cable to send DVI signal.

DE01ER as active receiver for high performance.

No external power required.

Support high resolution up to 1920 x 1200.

Support long distance up to 70 meters at 1024x768.

Panel View:

DE01ERK

DE01E to DE01ER

Resolution Distance(Meter)

800 X 600 70

1024 x 768 65

1280 x 1024 50

1440 x 900 50

1600 x 900 50

1920 x 1200

Remark: The transmission distance will be affected from different PC/Monitor equipment

and cable quality.

Cable:

Video Link cable using hi quality CAT5E UTP or CAT6 UTP cable,

CAT6 cable enhances transmission range and signal stability.

RJ45 Pin Define:

Link Cable (TIA/EIA-568-B )

1. Orange-white TMDS DATA0 -

2. Orange TMDS DATA0 +

3. Green-white TMDS CLOCK -

4. Blue TMDS DATA1 -

5. Blue-white TMDS DATA1 +

6. Green TMDS CLOCK +

7. Brown-white TMDS DATA2 -

8. Brown TMDS DATA2 +

LED Indication:

Green Status Normal

Yellow Loss of Clock Signal

Caution:

1. The cabling must away from any equipment with electromagnetic wave, i.e.: microwave,

radio equipment, high voltage.

2. Working distance will be variety based on different equipment.

3. The picture may come with noise under the resolution 640 x 480

4. HDCP not supported.

Specification:

ITEM NO. CE-DVISM CE-DVISM

Video Bandwidth 1.65 Gbps ( DVI 1.1)

Resolution Up to 1600x1200 Up to 1920 x 1200 @60hz

Input TMDS Video Signal

1.2 volts p-p

Input DDC Signal

5 volts p-p (TTL)

Link Cable Distance 25M@1024x 768

10M@1920x1200 65M@1024x768

50M@1920x1200

DVI Connector

DVI-D 29 pin

Link Connector RJ-45 Shielded x 1

Power Supply X

Temperature Operation: 0 to 55℃, Storage: -20 TO 85℃, Humidity: up to 95%

DIMENSIONS W x H x D mm

50 x 40 x 20

40 × 56 × 24.5

Weight g 45g 50g
