CoolGear USBG-4U3ML Bedienungsanleitung

USB 3.0 4-Port Industrial

Hub Metal Case

Product Manual

Coolgear, Inc.

Version 1.1

September 2017

Model Number: USBG-4U3ML

www.coolgear.com

2 USBG-4U3ML – Product Manual

www.coolgear.com

Revision History

Revision Date Author Comments

1.0 07/14/2015 Coolgear Original format

1.1 09/27/2017 Coolgear New Manual Format

About this document

This product manual outlines installation and features of the USBG-4U3ML USB 3.0 4-

Port Industrial Hub Metal Case.

Scope

The scope of this manual is to give the user of the product an understanding of its use

with detailed diagrams and verbiage. The manual allows the users to apply the product

to their application.

Intended Audience

This product is intended for use in numerous industries including but not limited to

applications such as; Automotive, Machine Equipment, Kiosk, Office, and others.

Product Support

[email protected]

USBG-4U3ML – Product Manual 3

www.coolgear.com

Table of Contents

1. Introduction.........................................................................................................4

1.1 Features .................................................................................................................. 4

1.2 Connector Layout.................................................................................................... 4

1.3 Hardware Installation ............................................................................................. 5

1.4 Checking the Hub Installation................................................................................. 6

1.5 Environmental Specifications ................................................................................. 7

2. Notes, Tips, Warnings, and Safety.........................................................................8

3. Supporting References .........................................................................................9

Table of Figures

Figure 1 – Connector Layout…………………………………………………………………………………………..4

Figure 2 – Screw Lock Mechanisms…………………………………………………………………………………5

Figure 3 - Mounting Illustration..........................................................................................6

Figure 4 – Device Manager……………………………………………………………………………………………..6

Figure 5 – Input Power Diagram…………………………………………………………………………………..…9

4 USBG-4U3ML – Product Manual

www.coolgear.com

1. Introduction

Super-Speed 4-port USB 3.0 hub providing an ideal solution to expand 4 USB 3.0 ports

from one single USB 3.0 host port. It provides a wide range self power source

(+12~24VDC from 2-pin Terminal Blocks) to supply enough power on USB 3.0 buses.

WEIGHT 1.1 lbs

DIMENSIONS (14.25 x 6.52 x 2.62 cm)

UPC 729440690540

WARRANTY 1 year from date of purchase

COLOR Black

DOWNSTREAM PORTS 4 USB 3.0 Type-A Ports

UPSTREAM PORTS 1 USB 3.0 Type-B Port

1.1 Features

•Compliant with USB Specification

Revision 3.0

•Rigid and Wall-mountable Metal Case

•Provides 4 Downstream USB 3.0 Facing

Ports

•Supports 5Gbps (Super-Speed),

480Mbps (High-Speed), 12Mbps (Full-

Speed), and 1.5Mbps (Low-Speed)

speed

•

Supports 350-Watt Surge Protection

for each Port

•Multi Transaction Translators (TT) per

Hub

•Supports USB Battery Charging: CDP

and DCP modes

•Supports USB Screw-Lock Cable

Mechanism

•Supports DIN RAIL Mounting Kit

1.2 Connector Layout

Figure 1

USBG-4U3ML – Product Manual 5

www.coolgear.com

USB 3.0 Upstream Port USB 3.0 Downstream Port Self Power Input

Type-B connector from

upstream USB3.0 port. It is

connected from host or

another USB3.0 hub.

Supports both normal and

screw-lock type USB cables.

There are 4 Type-A

connectors for USB3.0,

USB2.0 or USB1.1 devices.

They support both normal

and screw-lock type USB

cables.

This 2-pin (one pin for

positive voltage and the

other pin is GND) terminal

block connector is used to

connect strong power to

self-power the hub; the

voltage can be in the range

from +7V to 24VDC.

Figure 2

1.3 Hardware Installation

1. Use static electricity discharge precautions. Remove possible static

discharge potential from any objects that the hub may come in contact with

before installation. This can be accomplished by touching a bare metal

chassis rail after you have turned off the power.

2. Apply DC power (range from +7V to 24V) to the 2-pin Terminal Block

Connector. The hub was self-powered by this connector.

3. Connecting USB Host cables: The host cable could be either a standard A-to-

B USB 3.0 cable or an optional A-to-B USB 3.0 screw-lock cable. Please

connect the type-A end connector of the cable to your PC’s host USB 3.0

port, then insert the type-B end connector to this hub. Since the USB hub is

plug-and-play, you don’t have to turn off your host computer when installing

the hub.

4. Connect the USB Devices to the downstream ports of this hub.

5. Mount your hub on the wall or DIN RAIL if required.

6 USBG-4U3ML – Product Manual

www.coolgear.com

Figure 3

1.4 Checking the Hub Installation

To check the USB hub installation in Windows device manager, please follow the

following steps:

1. Click Start

2. Click Control Panel

3. Click System

4. Click Device Manager

button

5. Double Click Universal

Serial Bus Controller

6. Double click Generic

USB Hub, the

message will show

that this device is

working properly

Figure 4

USBG-4U3ML – Product Manual 7

www.coolgear.com

1.5 Environmental Specifications

Specification Data

Operating Temperature: 0-55°C (32 to 131°F)

Operating Humidity: 5 to 95% RH

8 USBG-4U3ML – Product Manual

www.coolgear.com

2. Notes, Tips, and Warnings

Note N/A

Tip N/A

Warning

Please make sure the polarity of the input power should be correctly

matched with the terminal block pins to function properly.

Figure 5

Safety

•Read the entire Product Manual before implementing this product for

your application. This manual contains important information about

electrical connections that must be followed for safe and proper

operation.

•Inspect the product closely for visual defects before putting it to use.

•Keep away from areas where moisture builds, this product contains

electrical components that can be damaged by moisture build up, this

can adversely affect your equipment connected to it.

•Do not disassemble the product. Handling the product’s internal

components can expose it to ESD (Electro-Static Discharge) hazards

that can affect the function of the device.

•If this product is not functioning properly, email our support team at

[email protected].

USBG-4U3ML – Product Manual 9

www.coolgear.com

3. Supporting References

Document Link

Website Product Page https://www.coolgear.com/product/usb-3-0-

4-port-industrial-hub-metal-case

and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject

to change without notice.
